- Page 1 HPE Aruba Networking 9004 Gateway Installation Guide Published : October 2024 Revision 3...
- Page 2 Hewlett Packard Enterprise Company. To obtain such source code, please check if the code is available in the HPE Software Center at https://myenterpriselicense.hpe.com/cwp-ui/ software but, if not, send a written request for specific software version and product for which you want the open source code.
- Page 3 Contacting Support ....................5 ............................ 5 HPE Aruba Networking 9004 Gateway ..........7 Package Checklist ..................... 7 HPE Aruba Networking 9004 Gateway Components ........... 8 Front Panel LEDs....................8 DC Power Connector ..................9 Reset Switch ....................... 9 Ethernet Ports ....................10 Micro-USB Console Port..................
- Page 4 | Installation Guide HPE Aruba Networking 9004 Gateway...
- Page 5 Preface This document describes the hardware features of the HPE Aruba Networking 9004 gateway. It provides a detailed overview of the physical and performance characteristics of the gateway and explains how to install the gateway and its accessories. Guide Overview Chapter 1, “HPE Aruba Networking 9004 Gateway”...
- Page 6 | Preface | Installation Guide HPE Aruba Networking 9004 Gateway...
- Page 7 HPE Aruba Networking 9004 Start-up Guide (Printed) Adapter cable saddle Optional accessories are available for use with the HPE Aruba Networking 9004 gateway and are sold separately. Contact your HPE Aruba Networking sales representative for details and assistance. | Installation Guide...
- Page 8 The front panel LEDs show the System, WAN, and LAN status including various other features. These front panel LEDs provide basic monitoring information of the overall status of the HPE Aruba Networking 9004 gateway. The following table describes the LED indicators and their...
- Page 9 Red (Blinking) Hardware Failure. USB Failure. Unsupported USB Device Attached. DC Power Connector The AC-DC adapter kit with the following specification is used to power the HPE Aruba Networking 9004 gateway: 12V/2.5A power interface Center-positive 2.1/5.5 mm circular plug, 9.5 mm length ...
- Page 10 Link at 100 Mbps Micro-USB Console Port The HPE Aruba Networking 9004 gateway is equipped with a Micro-USB (type B) connector that provides console access for direct local access. If both Micro-USB and RJ-45 console ports are connected, the Micro-USB connection takes precedence over the RJ-45 console connection.
- Page 11 The CONSOLE port is compatible only with RS-232 devices. Non-RS-232 devices, such as APs, are not supported. Do not connect the Console port to an Ethernet switch or a PoE power source. This may damage the gateway. | Installation Guide HPE Aruba Networking 9004 Gateway | HPE Aruba Networking 9004 Gateway...
- Page 12 DB-9 Ground USB Port The HPE Aruba Networking 9004 gateway is equipped with a USB 3.0 interface. A USB storage device can be used to save and upload configurations to the gateway. Kensington Lock Slot The HPE Aruba Networking 9004 gateway is equipped with a Kensington security slot for additional security.
- Page 13 Use 3/4 inch long #6 pan head wood screws with plastic screw anchor #6-8 x 1 inch on dry wall or concrete wall. Required quantity: 2 screws per unit Figure 6 Mounting Using the Integrated Wall-Mounting Slots HPE Aruba Networking 9004 Gateway | Installation Guide Installation |...
- Page 14 2. Align the mounting slots on the bottom of the gateway over the screws and slide the unit into place. See Figure 7 Figure 7 Wall Mounting HPE Aruba Networking 9004 Gateway 3. Align the cable saddle with the slot on the side of the gateway and push the cable saddle into the unit to secure it. See...
- Page 15 Figure 9 Securing a cable | Installation Guide Installation | HPE Aruba Networking 9004 Gateway...
- Page 16 | Installation | Installation Guide HPE Aruba Networking 9004 Gateway...
- Page 17 HPE Aruba Networking gateways must be installed by a professional installer. The professional installer is responsible for ensuring that grounding is available and it meets applicable local and national electrical codes. RF Radiation Exposure Statement: This equipment complies with RF radiation exposure limits. This equipment should be installed and operated with a minimum distance of 7.874 inches (20cm) between the radiator and...
- Page 18 undesired operation. Changes or modifications to this unit not expressly approved by HPE Aruba Networking could void the user’s authority to operate this equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
- Page 19 There is a risk of explosion if battery is replaced by an incorrect type, so dispose used batteries according to the instructions. Thailand Regulatory Model Name The regulatory model name for the HPE Aruba Networking 9004 Gateway is ARCN9004. | Installation Guide Specifications, Safety, and Compliance | HPE Aruba Networking 9004 Gateway...
- Page 20 Proper Disposal of HPE Aruba Networking Equipment Waste of Electrical and Electronic Equipment HPE Aruba Networking products at end of life are subject to separate collection and treatment in the EU Member States, Norway, and Switzerland and therefore are marked with the symbol shown at the left (crossed-out wheelie bin). The treatment...
- Page 21 ※ 經型式認證合格之低功?射頻電機，非經許可，公司、商號或使用者均?得擅自 變頻、加大功或變原設計之特性及功能。 第十四條 ※ 低功射頻電機之使用?得影響飛航安全及干擾合法通信；經發現有干擾現象時，應即停用，並改善至無干擾時方得繼 續使用。 - 前項合法通信，指依電信法規定作業之無線電通信。 - 低功射頻電機須忍受合法通信或工業、科學及醫?用電波?射性電機設備之干擾。 支援 5G 功能則必須補上 " 應避免影響附近雷達系統之操作 " 不具備外接或替換天線時須加註： " 高增益指向性天線只得應用於固定式點對點系統。 第十二條 經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻率、加大功率或變 更原設計之特性及功能。 第十四條 低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即停用，並改善至 無干擾時方得繼續使用。 前項合法通信，指依電信法規定作業之無線電通信。 低功率射頻電機須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。 1. 應避免影響附近雷達系統之操作。 | Installation Guide Specifications, Safety, and Compliance | HPE Aruba Networking 9004 Gateway...
- Page 22 3. 電磁波暴露量 MPE 標準值 1 mW/cm2, 送測產品實測值為 : 0.46mW/cm2 Нормативные требования Евразийского Экономического Союза Russia HPE Russia: ООО "Хьюлетт Паккард Энтерпрайз" Российская Федерация, 125171, г. Москва, Ленинградское шоссе, 16А, стр.3, Телефон: +7 499 403 4248 Факс: +7 499 403 4677 'HPE Belarus': ИООО...
