Summary of Contents for HPE Aruba Networking 9012
- Page 1 HPE Aruba Networking 9012 Gateway...
- Page 2 Hewlett Packard Enterprise Company. To obtain such source code, please check if the code is available in the HPE Software Center at https://myenterpriselicense.hpe.com/cwp-ui/software but, if not, send a written request for specific software version and product for which you want the open source code.
- Page 3 Overview....................... 5 Related Documentation................... 5 Contacting Support ....................5 ............................ 5 Package Checklist ..................... 7 HPE Aruba Networking 9012 Gateway Components ........... 8 Front Panel LEDs....................8 Kensington Lock Slot ..................10 Power Supply....................10 Reset Switch ..................... 11 Ethernet Ports ....................
- Page 4 | Installation Guide HPE Aruba Networking 9012 Gateway...
- Page 5 Preface This document describes the hardware features of the HPE Aruba Networking 9012 gateway. It provides a detailed overview of the physical and performance characteristics of the gateway and explains how to install the gateway and its accessories. Guide Overview Chapter 1, “9012 Gateway”...
- Page 6 | Preface | Installation Guide HPE Aruba Networking 9012 Gateway...
- Page 7 Chapter 1 9012 Gateway The HPE Aruba Networking 9012 gateway is a dual purpose gateway that supports both SD-WAN and wireless LAN capabilities. The wireless LAN connects, controls, and intelligently integrates wireless Access Points (APs), Managed Devices, and Air Monitors (AMs). The gateway has the ability to directly connect a branch to cloud, provide resilient connectivity from the cloud, and centralized control for policy management across all branches.
- Page 8 The rack mounting kit is available for use with the HPE Aruba Networking 9012 gateway and is sold separately. Contact your HPE Aruba Networking sales representative for details and assistance. HPE Aruba Networking 9012 Gateway Components This section introduces the different component and its location in the HPE Aruba Networking 9012 gateway.
- Page 9 Aruba Networking 9012 gateway. The following table describes the LED indicators and their corresponding status: Table 4 LED Status Function Indicator Status System System status Green (Solid) Powered and Operational Green (Blinking) Loading Software Amber (Solid) Critical Alarm Amber (Blinking)
- Page 10 Power Supply The HPE Aruba Networking 9012 Gateway is equipped with an integrated AC power supply of 185 W. The integrated power supply supports an input voltage of 100 V AC to 240 V AC. The HPE Aruba Networking 9012 gateway supports PoE (802.3af) and PoE+ (802.3at) to provide power to connected devices.
- Page 11 PoE+ (802.3at) and PoE (802.3af). The HPE Aruba Networking 9012 gateway supports up to four PoE+ Class 4 ports simultaneously, with a power supply of up to 30 W only. All the 6 PoE ports can support power up to 15.4 W simultaneously.
- Page 12 Link at 10/100 Mbps Micro-USB Console Port The HPE Aruba Networking 9012 gateway is equipped with a Micro-USB (type B) connector that provides direct local console access. If both Micro-USB and RJ-45 console ports are connected, the Micro-USB connection takes precedence over the RJ-45 console connection.
- Page 13 Ground USB Port The HPE Aruba Networking 9012 gateway is equipped with two USB 3.0 interfaces. A USB storage device can be used to save and upload configurations to the gateway. The HPE Aruba Networking 9012 gateway also provides support for USB LTE Modems. These modems can be connected to either USB Port 0 and Port 1.
- Page 14 The 9012 gateway provides support for two USB LTE Modems. You can use only one USB LTE Modem at a time. To use both modems simultaneously, it is recommended to use a USB extension cable. | 9012 Gateway | Installation Guide HPE Aruba Networking 9012 Gateway...
- Page 15 Installation of the device should be performed by a trained installation professional. This chapter describes how to install an HPE Aruba Networking 9012 Gateway using the many mounting options available. The 9012 gateway ships with an accessory kit that includes the equipment needed to install the gateway in a standard, 19-inch telco rack or on a wall.
- Page 16 3. Mount the gateway within your organization’s rack system using the four screws for the system rack mount (two per bracket) and a suitable screwdriver. See Figure | Installation | Installation Guide HPE Aruba Networking 9012 Gateway...
- Page 17 Installation Steps 1. Attach the rubber feet to the bottom of the gateway. See Figure Figure 8 Attaching Rubber Feet 2. Place the gateway in the location you have chosen. | Installation Guide Installation | HPE Aruba Networking 9012 Gateway...
- Page 18 4. Align the mounting bracket holes with the holes you created on the wall. See Figure 5. Use appropriate screws to secure the 9012 gateway. | Installation | Installation Guide HPE Aruba Networking 9012 Gateway...
- Page 19 Figure 10 Wall Mounting | Installation Guide Installation | HPE Aruba Networking 9012 Gateway...
- Page 20 | Installation | Installation Guide HPE Aruba Networking 9012 Gateway...
- Page 21 For additional specifications on this product, please refer to the data sheet. The data sheet can be found at www.arubanetworks.com Safety and Regulatory Compliance HPE Aruba Networking, a Hewlett Packard Enterprise company provides a multi-language document that contains country-specific restrictions and additional safety and regulatory information for all | Installation Guide Specifications, Safety, and Compliance |...
- Page 22 HPE Aruba Networking gateways must be installed by a professional installer. The professional installer is responsible for ensuring that grounding is available and it meets applicable local and national electrical codes. RF Radiation Exposure Statement: This equipment complies with RF radiation exposure limits. This equipment should be installed and operated with a minimum distance of 7.874 inches (20cm) between the radiator and...
- Page 23 There is a risk of explosion if battery is replaced by an incorrect type, so dispose used batteries according to the instructions. Thailand Regulatory Model Name The regulatory model name for the HPE Aruba Networking 9012 Gateway is ARCN9012. | Installation Guide Specifications, Safety, and Compliance | HPE Aruba Networking 9012 Gateway...
- Page 24 Proper Disposal of HPE Aruba Networking Equipment Waste of Electrical and Electronic Equipment HPE Aruba Networking, a Hewlett Packard Enterprise company products at end of life are subject to separate collection and treatment in the EU Member States, Norway, and Switzerland and therefore are marked with the symbol shown at the left (crossed-out wheelie bin).
- Page 25 Korean Taiwan 1. 應避免影響附近雷達系統之操作。 2. 高增益指向性天線只得應用於固定式點對點系統 3. 電磁波暴露量 MPE 標準值 1 mW/cm2, 送測產品實測值為 : 0.001mW/cm2 所有技術文件皆必須秀出廠牌 / 型號，而使用手冊必須再補上警語，其警語內容如下：依據低功電波射性電機管辦法 第十二條 經型式認證合格之低功率射頻電機，非經許可，公司，商號或使用者均不得擅自變更頻率、加大功率或變更原設計之特 性及功能。 第十四條 低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即停用，並改善至無干擾時方得 繼續使用。 前項合法通信，指依電信法規定作業之無線電通信。 低功率射頻電機須忍受合法通信或工業、科學及醫療用電波輻射性 電機設備之干擾。 | Installation Guide Specifications, Safety, and Compliance | HPE Aruba Networking 9012 Gateway...
- Page 26 Нормативные требования Евразийского Экономического Союза Russia HPE Russia: ООО "Хьюлетт Паккард Энтерпрайз" Российская Федерация, 125171, г. Москва, Ленинградское шоссе, 16А, стр.3, Телефон: +7 499 403 4248 Факс: +7 499 403 4677 'HPE Belarus': ИООО «Хьюлетт-Паккард Бел», Республика Беларусь, 220030, г. Минск, ул.
