Summary of Contents for MSI PRO MP251W E2
- Page 1 PRO Series LCD Monitor PRO MP251W E2 (3PD4) User Guide...
- Page 2 Contents Getting Started ......................3 Package Contents ....................3 Installing the Monitor Stand ................... 4 Adjusting the Monitor ..................... 5 Monitor Overview ....................6 Connecting the Monitor to PC ................8 OSD Setup ........................9 Navi Key ........................9 Hot Key ........................9 OSD Menus........................
- Page 3 This chapter provides you with the information on hardware setup procedures. While connecting devices, be careful in holding the devices and use a grounded wrist strap to avoid static electricity. Package Contents Monitor PRO MP251W E2 Documentation Quick Start Guide Accessories Stand...
- Page 4 Installing the Monitor Stand 1. Leave the monitor in its protective packaging. Align and gently push the stand bracket towards the monitor groove until it locks in place. 2. Align and gently push the base towards the stand until it locks in place. 3.
- Page 5 Adjusting the Monitor This monitor is designed to maximize your viewing comfort with its adjustment capabilities. ⚠ Important Avoid touching the display panel when adjusting the monitor. -5° 20°...
- Page 6 Monitor Overview...
- Page 7 Power LED Lit in white after the monitor is turned on. If no signal input, the LED will turn into orange. Lit in orange when the monitor is in Stand-by mode. Power Button & Navi Key Power Jack Kensington Lock Cable Organizer DisplayPort Supports 1920x1080@120Hz as specified in DisplayPort 1.4a.
- Page 8 Connecting the Monitor to PC 1. Turn off your computer. 2. Connect the video cable from the monitor to your computer. 3. Connect the power cord to the monitor power jack. (Figure A) 4. Plug the power cord into the electrical outlet. (Figure B) 5.
- Page 9 OSD Setup This chapter provides you with essential information on OSD Setup. ⚠ Important All information is subject to change without prior notice. Navi Key The monitor comes with a Navi Key, a multi-directional control that helps navigate the On-Screen Display (OSD) menu. Up/ Down/ Left/ Right: ∙...
- Page 10 OSD Menus ⚠ Important The following settings will be grayed out when HDR signals are received: ∙ MPRT ∙ Contrast ∙ Low Blue Light ∙ Color Temperature ∙ HDCR ∙ sRGB Brightness ∙ Professional 1st Level Menu 2nd/3rd Level Menu Description Mode ∙...
- Page 11 1st Level Menu 2nd/3rd Level Menu Description MPRT ∙ MPRT is available when the refresh rate is over 85 Hz. ∙ Activating MPRT will affect: Affected Function Function Status » Brightness Unable to select » Response Time » HDCR Set to OFF »...
- Page 12 1st Level Menu 2nd/3rd Level Menu Description Screen Assistance None ∙ Users can adjust Screen Assistance in any mode. Screen Size Auto ∙ Users can adjust Screen Size in any mode, any resolution and any screen refresh rate. 16:9 Adaptive-Sync ∙...
- Page 13 1st Level Menu 2nd/3rd Level Menu Description HDCR ∙ HDCR enhances image quality by increasing the contrast of images. ∙ Activating HDCR will affect: Affected Function Function Status » Brightness Unable to select » MPRT Set to OFF Color Temperature Cool ∙...
- Page 14 Input Source 1st Level Menu 2nd Level Menu Description HDMI™ ∙ Users can adjust Input Source in any mode. D-Sub Auto Scan ∙ Users can use the Navi Key to select Input Source at below status: • While “Auto Scan” is set to “OFF” with the monitor at power saving mode;...
- Page 15 Settings 1st Level Menu 2nd/3rd Level Menu Description Language 繁體中文 ∙ Users have to press the Middle Button to confirm and apply the Language setting. English ∙ Language is an independent setting. Users’ own Français language setting will override the factory. When users set Reset to Yes, Language will not be Deutsch changed.
- Page 16 Specifications Monitor PRO MP251W E2 Size 24.5 inch Curvature Flat Panel Type Resolution 1920x1080 (FHD) Aspect Ratio 16:9 Brightness Typical SDR 300 nits 1500:1 Contrast Ratio Refresh Rate 120Hz 4ms (GtG) Response Time 1ms (MPRT) ∙ DisplayPort x1 ∙ HDMI™ Connector x1 ∙...
- Page 17 Monitor PRO MP251W E2 ∙ Plate Type: 100 x 100 mm ∙ Screw Type: M4 x 10 mm • Thread Diameter: 4 mm • Thread Pitch: 0.7 mm VESA Mounting • Thread Length: 10 mm ∙ VESA Screw Type: • Male Thread: M4 x 8 mm •...
- Page 18 Preset Display Modes ⚠ Important All information is subject to change without prior notice. Standard Default Mode Standard Resolution HDMI™ D-Sub 640x480 @60Hz @67Hz @72Hz @75Hz SVGA 800x600 @56Hz @60Hz @72Hz @75Hz 1024x768 @60Hz @70Hz @75Hz SXGA 1280x1024 @60Hz @75Hz WXGA+ 1440x900 @60Hz...
- Page 19 Troubleshooting The power LED is off. • Press the monitor power button again. • Check if the monitor power cable is properly connected. No image. • Check if the computer graphics card is properly installed. • Check if the computer and monitor are connected to electrical outlets and are turned on.
- Page 20 ∙ Place the power cord in a way that people are unlikely to step on it. Do not place anything on the power cord. ∙ If this device comes with an adapter, use only the MSI provided AC adapter approved for use with this device.
- Page 21 ∙ If any of the following situations arises, get the device checked by service personnel: • The power cord or plug is damaged. • Liquid has penetrated into the device. • The device has been exposed to moisture. • The device does not work well or you can not get it working according to the User Guide.
- Page 22 TÜV Rheinland Certification TÜV Rheinland Low Blue Light Certification Blue light has been shown to cause eye fatigue and discomfort. MSI now offers monitors with TÜV Rheinland Low Blue Light certification to ensure users’ eye comfort and well-being. Please follow the instructions below to reduce the symptoms from extended exposure to the screen and blue light.
- Page 23 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. MSI Computer Corp. 901 Canada Court, City of Industry, CA 91748, USA (626) 913-0828 www.msi.com...
- Page 24 Vietnam RoHS As from December 1, 2012, all products manufactured by MSI comply with Circular 30/2011/TT-BCT temporarily regulating the permitted limits for a number of hazardous substances in electronic and electric products.
- Page 25 Copyright and Trademarks Notice Copyright © Micro-Star Int’l Co., Ltd. All rights reserved. The MSI logo used is a registered trademark of Micro-Star Int’l Co., Ltd. All other marks and names mentioned may be trademarks of their respective owners.
