HB317GE.3Y
Oven
EN User manual and installation instructions
Register your appliance on My Siemens and
discover exclusive services and offers.
Siemens Home Appliances

Advertisement

loading
Need help?

Need help?

Do you have a question about the HB317GE 3Y Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Siemens HB317GE 3Y Series

  • Page 1 HB317GE.3Y Oven EN User manual and installation instructions Register your appliance on My Siemens and discover exclusive services and offers. Siemens Home Appliances...
  • Page 2 en Safety Further information and explanations are available online: Table of contents ¡ Do not connect the appliance if it has been damaged in transit. INFORMATION FOR USE 1.2 Intended use Safety ..............  2 This appliance is designed only to be built into kitchen units. Read the special installation Preventing material damage ......  4 instructions.
  • Page 3 Safety en WARNING ‒ Risk of fire! WARNING ‒ Risk of scalding! Combustible objects that are left in the cook- The accessible parts of the appliance become ing compartment may catch fire. hot during operation. ▶ Never store combustible objects in the ▶ Never touch these hot parts. cooking compartment.
  • Page 4 en Preventing material damage ▶ Call customer services. → Page 22 WARNING ‒ Risk of electric shock! Improper repairs are dangerous. WARNING ‒ Risk of suffocation! ▶ Repairs to the appliance should only be Children may put packaging material over carried out by trained specialist staff. their heads or wrap themselves up in it and ▶...
  • Page 5 Environmental protection and saving energy en Fruit juice dripping from the baking tray leaves stains Sitting or placing objects on the appliance door may that cannot be removed. damage it. When baking very juicy fruit flans, do not pack too Do not place, hang or support objects on the appli- ▶...
  • Page 6 en Familiarising yourself with your appliance Familiarising yourself with your appliance 4  Familiarising yourself with your appliance 4.1 Controls Buttons and display The buttons are touch-sensitive surfaces. To se- You can use the control panel to configure all functions lect a function, simply press lightly on the relev- of your appliance and to obtain information about the ant field.
  • Page 7 Familiarising yourself with your appliance en Symbol Type of heating What it's used for/how it works 3D hot air Bake or roast on one or more levels. The fan distributes the heat from the ring-shaped heating element in the back wall evenly around the cooking compartment. Hot air gentle Cook selected dishes gently on one level without preheating.
  • Page 8 en Accessories Heat-up indicator You can remove the shelf supports, e.g. for cleaning. → "Shelf supports", Page 20 The appliance indicates when it is heating up. When the appliance is heating, the ⁠   symbol lights up on the display. This symbol goes out when heating is paused.
  • Page 9 You will find a comprehensive range of products for pull-out rails and pull out the pull-out rails. your appliance in our brochures and online: siemens-home.bsh-group.com Accessories are appliance-specific. When purchasing accessories, always quote the exact product number (E no.) of your appliance.
  • Page 10 en Basic operation Press the  button. Set the type of heating and the temperature. → "Basic operation", Page 10 a The time that is set appears in the display. Type of heating 3D hot air 6.2 Cleaning the appliance before using it Temperature Maximum for the first time Duration 1 hour...
  • Page 11 Time-setting options en Press the button repeatedly until is highlighted Time-setting on the display. option Use the ⁠ or ⁠   button to set the time. Timer The timer can be set independently of the appliance when it is in opera- Button Default value tion.
  • Page 12 en Childproof lock Once the cooking time has elapsed: Requirement:  ⁠   is highlighted on the display. Press any button to end the signal prematurely. ‒ Reset the end time to the current time plus the set ▶ To set another cooking time, press the ⁠...
  • Page 13 Programmes en Display Basic setting Selection ⁠ ⁠ Childproof lock can be adjusted = no = yes Water hardness = softened = soft (up to 1.5 mmol/l) = medium (1.5 - 2.5 mmol/l) = hard (2.5 - 3.8 mmol/l) = very hard (above 3.8 mmol/l) Factory setting (may vary according to model) Only for appliance types with steam function To save the changes, press and hold the ⁠...
  • Page 14 en Programmes No. Food Cookware Weight setting Add liquid Shelf Information posi- tion Deep roasting dish Total weight As per recipe 2 Place the meat at the 04 Goulash Diced beef or pork, with lid bottom and cover with vegetables with vegetables Do not sear the meat beforehand Roasting dish with...
  • Page 15 Cleaning and servicing en To set a cooking time for further cooking, press When your food is ready, switch off the appli- ‒ ‒ button. The appliance continues to heat ance. using the programme settings. Cleaning and servicing 13  Cleaning and servicing Do not use cleaning products with a high alcohol To keep your appliance working efficiently for a long ▶...
  • Page 16 en humidClean Cooking compartment Area Suitable cleaning agents Hints Enamel surfaces ¡ Hot soapy waterHot Soak any heavily soiled areas and use a brush or steel wool. soapy water Leave the appliance door open to dry the cooking compartment ¡ Vinegar solution after cleaning it.
  • Page 17 Appliance door en Do not use distilled water. Requirement: The cooking compartment has cooled Use the function selector to set the Bottom heat- down. type of heating. ing  Wipe out the remaining water in the cooking com- Use the temperature selector to set 80 °C. partment using an absorbent sponge cloth.
  • Page 18 en Appliance door Close the appliance door fully  . Grab hold of the Open the locking levers on the left- and right-hand appliance door with both hands (on the left and hinges  . right) and pull it upwards and out  ⁠ . a The locking levers are open.
  • Page 19 Appliance door en Lift out the intermediate pane and set it down care- Place the condensate trough vertically into the re- fully on a flat surface. tainer  and turn it downwards. If necessary, you can remove the condensate Slide the intermediate pane into the left- and right- trough for cleaning.
  • Page 20 en Shelf supports Slide the inner pane into the left- and right-hand re- Put the door cover into position  and push down tainers  ⁠ . on it until you hear it click into place. Open the appliance door fully. Close the locking levers on the left- and right-hand hinges ...
  • Page 21 Troubleshooting en Troubleshooting 17  Troubleshooting You can rectify minor faults on your appliance yourself. WARNING ‒ Risk of electric shock! Read the troubleshooting information before contacting Improper repairs are dangerous. after-sales service. This will avoid unnecessary costs. Repairs to the appliance should only be carried out ▶...
  • Page 22 en Disposal Pull out the halogen bulb without turning it  ⁠ . Requirements ¡ The appliance is disconnected from the power sup- ply. ¡ The cooking compartment has cooled down. ¡ You must have a new halogen lamp to replace the old one.
  • Page 23 How it works en ¡ The temperature and cooking time depend on the ¡ The larger the poultry, meat or fish, the lower the amount of food and the recipe. Settings ranges are cooking temperature and the longer the cooking specified for this reason. Try using the lower values time.
  • Page 24 en How it works 20.4 List of foods Recommended settings for a variety of foods, sorted into food categories. Recommended settings for various types of food Food Accessory/cookware Height Type of Temperature in Cooking time in heating °C/grill setting mins Sponge cake, simple Ring-shaped tin 150-170 50-70...
  • Page 25 How it works en Food Accessory/cookware Height Type of Temperature in Cooking time in heating °C/grill setting mins Quiche Tart dish or tin 210-230 30-40 Black tray Quiche Tart dish or tin 190-210 25-35 Black tray Börek Universal pan 180-200 40-50 Bake, savoury, cooked ingredi- Ovenproof dish 200-220...
  • Page 26 en How it works 20.5 Test dishes Baking ¡ The setting values apply to food that is placed into a Baking tray: Shelf position 1 cold cooking compartment. – Baking tins on the wire rack: ¡ Take note of the information on preheating in the re- First wire rack: Shelf position 3 commended settings tables.
  • Page 27 Installation instructions en Installation instructions 21  Installation instructions Observe this information when installing the appliance.  21.1 General installation instructions Follow these instructions before you start in- stalling the appliance. ¡ The safe operation of this appliance can only be guaranteed if it has been installed ¡...
  • Page 28 en Installation instructions 21.3 Installation below a worktop 21.5 Installing two appliances on top of each other Observe the installation dimensions and the installation instructions when installing below a worktop. Your appliance can also be installed above or below another appliance. Observe the installation dimensions and the installation instructions when installing appli- ances on top of each other.
  • Page 29 Installation instructions en ¡ To ensure that the appliance door can be opened, Identify the phase and neutral conductors in the you must take the minimum dimensions into consid- socket. eration when installing in a corner. The dimension The appliance may be damaged if it is not connec- is dependent on the thickness of the unit front and ted correctly.
  • Page 30 en Installation instructions 21.9 For handleless kitchens with vertical bar handle strips: Attach a suitable filling piece on both sides in order to cover any sharp edges and to guarantee safe in- stallation. Secure the filling piece to the unit. Pre-drill the filling piece and the unit to establish a screw connection.
  • Page 32 EN Manufactured by BSH Hausgeräte GmbH under the trademark licence of Siemens AG BSH Hausgeräte GmbH Carl-Wery-Straße 34 81739 München, GERMANY siemens-home.bsh-group.com *9001908367* 9001908367  (040717)
