- Page 1 Oven HB317GB.0Y User manual and installation instructions Register your product on My Siemens and discover exclusive ser- vices and offers. siemens-home.bsh-group.com/welcome The future moving in. Siemens Home Appliances...
- Page 2 en Safety Futher information and explanations are available online: ¡ Keep the instruction manual and the Table of contents product information safe for future refer- ence or for the next owner. ¡ Do not connect the appliance if it has been USER MANUAL damaged in transit.
- Page 3 Safety en Hot steam may escape when you open the 1.4 Safe use appliance door. Steam may not be visible, de- Always place accessories in the cooking com- pending on the temperature. partment the right way round. ▶ Open the appliance door carefully. → "Accessories", Page 8 ▶...
- Page 4 en Preventing material damage ▶ Do not let children play with small parts. If the appliance or the power cord is dam- aged, this is dangerous. 1.5 Halogen bulb ▶ Never operate a damaged appliance. WARNING ‒ Risk of burns! ▶ Never pull on the power cord to unplug the The bulbs in the cooking compartment get appliance.
- Page 5 Environmental protection and saving energy en 3 Environmental protection and saving energy 3.1 Disposing of packaging When baking multiple dishes, do so in succession or in parallel. The packaging materials are environmentally compat- ¡ The cooking compartment is heated after baking ible and can be recycled. the first dish.
- Page 6 en Familiarising yourself with your appliance 4.2 Buttons and display You can use the buttons to set various functions for your appliance. The display shows the settings. If a function is active, the corresponding symbol lights up in the display. The clock symbol only lights up when you change the time.
- Page 7 Familiarising yourself with your appliance en Symbol Function Oven light Illuminate the cooking compartment without heating. → "Lighting", Page 7 Programme Use programmed setting values for various types of food. → "Programme", Page 12 4.4 Temperature and setting levels There are different settings for the types of heating and functions. Note: For temperature settings above 250 °C, the appliance reduces the temperature to approx.
- Page 8 en Accessories 5 Accessories Use original accessories. These have been made espe- The accessories supplied may differ depending on the cially for your appliance. appliance model. Note: Accessories may become deformed if they get hot. Deformation has no effect on function. As the ac- cessory cools down, it will regain its original shape.
- Page 9 In so doing, the wire rack is on your appliance in our brochures and online: top of the upper guide rod. www.siemens-home.bsh-group.com Accessories vary from one appliance to another. When Wire rack purchasing accessories, always quote the exact on univer- product number (E no.) of your appliance.
- Page 10 en Rapid heating Changing the type of heating Tips ¡ The most suitable type of heating for your food can You can change the type of heating at any time. be found in the description of the type of heating. Use the function selector to set the required type of ▶...
- Page 11 Time-setting options en is highlighted on the display. Press the button repeatedly until is highlighted Requirement: in the display. Use the button to reset the timer duration to zero. ▶ Press the button. a After a few seconds, the appliance applies the a The display shows the calculated end time.
- Page 12 en Programme 10 Programme The programmes help you to use your appliance to Cookware made from the following material is not prepare different dishes by selecting the optimum set- suitable: tings automatically. ¡ Bright, shiny aluminium ¡ Unglazed clay ¡ Plastic or plastic handles 10.1 Cookware for programmes You should therefore use heat-resistant cookware that is suitable for temperatures up to 300 °C.
- Page 13 Childproof lock en No. Food Cookware Weight setting Add liquid Shelf Information posi- tion Roasting dish with Weight of meat Cover the Do not sear the meat 08 Leg of lamb, well- bottom of the beforehand done Boned, seasoned roasting dish, and add up to 250 g ve- getables if re-...
- Page 14 en Basic settings 12 Basic settings You can configure the basic settings for your appliance to meet your needs. 12.1 Overview of the basic settings Here you can find an overview of the basic settings and factory settings. The basic settings depend on the features of your appliance.
- Page 15 Cleaning and servicing en Remove all food remnants from the cooking com- Using oven cleaner in a hot cooking compartment ▶ partment and the appliance door before you next damages the enamel. heat up the appliance. Never use oven cleaner in the cooking compartment ▶...
- Page 16 en cleaning assistance humidClean 13.2 Cleaning the appliance WARNING ‒ Risk of fire! Loose food remnants, fat and meat juices may catch In order to avoid damaging the appliance, you must fire. clean your appliance only as specified, and with suit- Before using the appliance, remove the worst of the able cleaning products.
- Page 17 Appliance door en Pull the whole rail to the front and remove it. ¡ For both rails, ensure that the curved rods are at the front. First, push the rail into the middle of the rear socket until the rail rests against the cooking compartment wall, and then push this back ...
- Page 18 en Appliance door Close the appliance door fully . Grab hold of the Open the locking levers on the left- and right-hand appliance door with both hands (on the left and hinges . right) and pull it upwards and out . a The locking levers are open.
- Page 19 Appliance door en If necessary, you can remove the condensate Slide the intermediate pane into the left- and right- trough for cleaning. hand retainers . Open the appliance door. ‒ Tilt the condensate trough upwards and remove ‒ Push the intermediate pane upwards until it is in the left- and right-hand retainers ...
- Page 20 en Troubleshooting Close the locking levers on the left- and right-hand Close the appliance door. hinges . Note: Do not use the cooking compartment again until the door panes have been correctly fitted. a The locking levers are closed. The appliance door is secured and cannot be detached.
- Page 21 Disposal en Fault Cause and troubleshooting A message with ap- Electronics fault pears in the display, Press the button. e.g. If required, reset the time. ‒ a If the fault was a one-off, the error message disappears. If the error message appears again, call the after-sales service. Quote the exact error message and the E no.
- Page 22 en Customer Service 19 Customer Service If you have any queries on use, are unable to rectify 19.1 Product number (E-Nr.) and production faults on the appliance yourself or if your appliance number (FD) needs to be repaired, contact Customer Service. You can find the product number (E-Nr.) and the pro- Detailed information on the warranty period and terms duction number (FD) on the appliance's rating plate.
- Page 23 How it works en ¡ Place the food to be grilled on the wire rack. In ad- Cookware with lid dition, slide the universal pan in at least one shelf ¡ Place the cookware onto the wire rack. position lower, with the slanted edge facing the ap- ¡...
- Page 24 en How it works Food Accessories/cookware Shelf pos- Type of Temperature Cooking ition heating in °C/grill time in mins setting Fillet of beef, medium, 1 kg Wire rack 210-220 40-50 Universal pan Pot-roasted beef, 1.5 kg Cookware with lid 200-220 140-160 Sirloin, medium, 1.5 kg Wire rack 200-220 60-70...
- Page 25 Installation instructions en Position baking tins/dishes either next to one another or offset on different shelves so that they are not dir- ectly one above the other in the cooking compartment. Recommended settings for baking Food Accessories/cookware Shelf pos- Type of Temperature in Cook- ition...
- Page 26 en Installation instructions ¡ Wear protective gloves so that you do not cut yourself. Parts that are accessible dur- ing installation may have sharp edges. ¡ Dimensions of the figures in mm. WARNING ‒ Risk of fire! It is dangerous to use an extended power 21.1 General installation instructions cord and non-approved adapters.
- Page 27 Installation instructions en ¡ To ventilate the appliance, the intermediate floor ¡ Ensure that air exchange is guaranteed in accord- must have a ventilation cut-out. ance with the diagram. ¡ In combination with induction hobs, the gap between the worktop and appliance must not be sealed using additional strips.
- Page 28 en Installation instructions ¡ Contact protection must be guaranteed by the in- Screw the appliance into place. stallation. Electrically connect the appliance with the protective contact plug Note: The appliance must only be connected to a pro- tective contact socket that has been correctly installed. Insert the plug into the protective contact socket.
- Page 32 BSH Hausgeräte GmbH Carl-Wery-Straße 34 81739 München, GERMANY www.siemens-home.bsh-group.com Manufactured by BSH Hausgeräte GmbH under the trademark licence of Siemens AG *9001575202* 9001575202 (020114)
