NCR VOYIX 7371-K902 Kit Instructions

Remote scale display mount
Hide thumbs

Advertisement

Quick Links

Download this manual
Kit Instructions
Remote Scale Display Mount
7371-K902
Issue A
© 2024 NCR Voyix. All rights reserved. Confidential and proprietary information of NCR Voyix.
Use and disclose solely pursuant to company instructions.

Advertisement

loading
Need help?

Need help?

Do you have a question about the 7371-K902 and is the answer not in the manual?

Questions and answers

Related Manuals for NCR VOYIX 7371-K902

Summary of Contents for NCR VOYIX 7371-K902

  • Page 1 Kit Instructions Remote Scale Display Mount 7371-K902 Issue A © 2024 NCR Voyix. All rights reserved. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 2 All features, functions and operations described herein may not be marketed by NCR Voyix in all parts of the world. In some instances, photographs are of equipment prototypes. Therefore, before using this document, consult with your NCR Voyix representative or NCR Voyix office for information that is applicable and current.
  • Page 3 Revision Record Issue Date Remarks Jul 2024 First issue. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 4 The Scale Display is supplied by the customer. This publication provides procedures for installing the Remote Scale Display Mount on either of the following Self-Checkout units: NCR Voyix SCO Hardware (7371) Full Function (Fixed) NCR Voyix SCO Hardware (7371) Full Function (Hybrid) NCR Self-Checkout Hardware - Card Only Self-Checkout (7372) Confidential and proprietary information of NCR Voyix.
  • Page 5 Screw, M6 x 25 mm Pan head Zinc-Plated (2 pcs) *497-0423108 Instructions Kit (Reference Sheet) * Items marked with an asterisk are not called out on the image. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 6 "Installing the Remote Scale Display Mount for Flag 7879 Scale Display" page 9. "Installing the Remote Scale Display Mount for 7895 Scale Display" on page 20. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 7 Opening the Tower Cabinet To open the Tower Cabinet, follow these steps; 1. Unlock the Rear Cover of the Tower Cabinet, as shown in the image below. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 8 2. Remove the Rear Cover from the Tower Cabinet. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 9 "Removing the Remote Scale Display Mount for Flag 7879 Scale Display" on page 18. 2. Attach the Handheld Scanner Arm to the Tower using two (2) M6 hex screws, as shown in the image below. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 10 Scale Display Bracket. b. Secure the 7879 Scale Display on the Scale Display Bracket using two (2) M6 pan head screws, as shown in the image below. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 11 4. Attach two (2) M4 hex screws on the two (2) screw holes of the Handheld Scanner Arm, as shown in the image below. Note Ensure not to tighten the screws to leave a gap. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 12 Align and insert the two (2) slots into the gaps of the two (2) loose screws. b. Tighten the two (2) screws to secure the assembly in place. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 13 6. Route the Remote Scale Display cable. For more information, refer to "Routing the 7879 Scale Display cable" on the next page Note The Remote Scale Display and its cable are not included in the kit. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 14 Set aside the Rear Cover assembly for reinstallation. 4. Do the following: a. Route the cable under the Handheld Scanner arm and then into the cable access hole of the Tower Cabinet. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 15 5. Lift the front handle of the Scanner/Scale and then push the back of the Scanner/Scale to the front to remove it from the Scanner Bucket, as shown in the image below. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 16 6. Route and secure the cable along with the cable bundle on the bridge lance on the Tower Cabinet, as shown in the image below. Note Ensure that the length of the cable bundle is measured 22 cm. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 17 From the back of the Scanner Bucket, measure 90 cm to the cable connector. b. Connect the cable to the Scale Display port of the 7879 Scanner/Scale, as shown in the image below. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 18 3. Disconnect the Scale Display cable from the 7879 Scanner/Scale. 4. Loosen two (2) M4 hex screws to detach the Scale Display Bracket from the Handheld Scanner Arm, as shown in the image below. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 19 The 7879 Scale Display is supplied by the customer. 6. Remove two (2) M6 hex screws to detach the Handheld Scanner Arm, as shown in the image below. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 20 Remote Scale Display Mount for 7895 Scale Display" page 32 . 2. Attach the Handheld Scanner Arm to the Tower using two (2) M6 hex screws, as shown in the image below. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 21 3. Install the Adapter Plate for 7895 Scale Display on the Scale Display Bracket using two (2) M4 thread locking screws, as shown in the image below. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 22 Adapter Plate. b. Secure the 7895 Scale Display on the Adapter Plate using two (2) M4 pan head screws, as shown in the image below. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 23 5. Attach two (2) M4 hex screws on the two (2) screw holes of the Handheld Scanner Arm, as shown in the image below. Note Ensure not to tighten the screws to leave a gap. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 24 Align and insert the two (2) slots into the gaps of the the two (2) loose screws. b. Tighten the two (2) screws to secure the assembly in place. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 25 7. Route the Remote Scale Display cable. For more information, refer to "Routing the 7895 Scale Display cable" on the next page Note The Remote Scale Display and its cable are not included in the kit. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 26 Set aside the Rear Cover assembly for reinstallation. 4. Do the following: a. Route the cable under the Handheld Scanner arm and then into the cable access hole of the Tower Cabinet. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 27 Grasp the front of the Scanner/Scale and the back of the Scanner/Scale through the Tower Cabinet rear opening, as shown in the image below. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 28 Lift the front handle of the Scanner/Scale and then push the back of the Scanner/Scale to the front to remove it from the Scanner Bucket, as shown in the image below. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 29 7. Route and secure the cable along with the cable bundle on the bridge lance on the Tower Cabinet, as shown in the image below. Note Ensure that the length of the cable bundle is measured 16 cm. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 30 8. From the back of the Scanner Bucket, measure 90 cm to the cable connector and then connect it to the Scale Display port of the 7895 Scanner/Scale, as shown in the image below. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 31 2. Hold the front edge and the top of the Top Plate to lift it off the Scanner/Scale. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 32 3. Loosen two (2) M4 x 10 screws to detach the Scale Display Bracket from the Handheld Scanner Arm, as shown in the image below. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 33 The 7895 Scale Display is supplied by the customer. 5. Remove two (2) M4x6 screws to detach the Adapter Plate from the Scale Display Bracket, as shown in the image below. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 34 6. Remove two (2) M6 hex screws to detach the Handheld Scanner Arm, as shown in the image below. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
