NCR VOYIX 7772-K030 Kit Instructions

Stand for cx7/cx5 (7772/7773) pos
Hide thumbs

Advertisement

Table of Contents

Stand, CX7
Kit Instructions
7772-K030
Issue C
© 2024 NCR Voyix. All rights reserved. Confidential and proprietary information of NCR Voyix.
Use and disclose solely pursuant to company instructions.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7772-K030 and is the answer not in the manual?

Questions and answers

Related Manuals for NCR VOYIX 7772-K030

Summary of Contents for NCR VOYIX 7772-K030

  • Page 1 Stand, CX7 Kit Instructions 7772-K030 Issue C © 2024 NCR Voyix. All rights reserved. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.

  • Page 2: Copyright

    NCR Voyix, therefore, reserves the right to change specifications without prior notice. All features, functions, and operations described herein may not be marketed by NCR Voyix in all parts of the world. In some instances, photographs are of equipment prototypes. Therefore, before using this document, consult with your NCR Voyix representative or NCR Voyix office for information that is applicable and current.

  • Page 3: Table Of Contents

    Table of Contents Copyright Stand, CX7 Kit Contents Installation Procedure Installing the Stand Installing the Integrated Power Supply Changing the Neck Covers Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 4 Revision Record Issue Date Remarks Sep 2021 First Issue Dec 2021 Added Warning statement Jan 2022 Updated routing for Power Supply Cable Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.

  • Page 5: Stand, Cx7

    Stand, CX7 This kit provides a Stand for the NCR CX7 All-in-One POS (7772) or NCR CX5 All-in-One POS (7773). Kit Contents Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 6 M4 x 0.70mm size, w/ ND Microspheres Thread Lock 006-8622885 Screw, M4–0.7 x 8mm Flat Head, Machine, Knurled Head, Steel, Black Oxide 497-0523791 Neck, Inner, Black (Front Neck Cover) Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.

  • Page 7: Installation Procedure

    1. Install the CX7 with Integrated I/O on the Bracket (4 screws). For clarity, the Neck Cover is not shown in the illustration. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 8 2. Remove the Neck Door. a. Loosen the two (2) thumbscrews on the Neck Door. b. Rotate the Door forward and pull out to remove. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 9 Hook the Neck Door on the Neck Cover. Position the Door so that the door standoffs (one on each side) sit on the hooks on the inside of the neck cover (one on each side). Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 10 Tighten the two (2) thumbscrews. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.

  • Page 11: Installing The Integrated Power Supply

    Disconnect the AC power cord from the AC outlet and wait 30 seconds before servicing the terminal. 1. Remove the Neck Door. a. Loosen the two (2) thumbscrews on the Neck Door. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 12 Rotate the Door forward and pull out to remove. 2. Slightly push the front side of the Base Cover, then pivot the cover open. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 13 3. Route the AC Cord up through the opening in the Base. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 14 4. Position the Power Supply in the recess on the Base. Note The Power Supply Cable comes bundled as shown. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 15 5. Set the Ferrite Bead in the small recess on the Base and secure the Cable under the Cable Management Hook. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 16 On the underside of the Base, pull the DC Connector such that the excess cable is under the Base. 7. Connect the AC Cord to the Power Supply. 8. Hook the Base Cover into the Stand, then snap into place. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 17 Hook the Neck Door on the Neck Cover. Position the Door so that the door standoffs (one on each side) sit on the hooks on the inside of the neck cover (one on each side). Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 18 Tighten the two (2) thumbscrews. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.

  • Page 19: Changing The Neck Covers

    1. Remove the Neck Door. a. Loosen the two (2) thumbscrews on the Neck Door. b. Rotate the Door forward and pull out to remove. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 20 2. Remove the Base Rear Foot (2 screws). 3. Remove the Neck Cover. a. Remove the two (2) Hex Standoffs from the Neck. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 21 Remove the two (2) screws that secure the Neck Cover to the Neck. c. Remove the Neck Cover. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 22 5. Install the Base Rear Foot (2 screws). Ensure the Neck Cover is captured under the Base Rear Foot. The Base Rear Foot serves to manage the cables and hold the bottom of the Neck Cover in place. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 23 7. Secure the Front Neck Cover to the Neck with two (2) screws. Use the appropriate screws: flat head screws for Base without Integrated Power Supply thumbscrews for Base with Integrated Power Supply Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
