- Page 1 Bracket, Wall Mount, Power Supply, Integrated Kit Instructions 7772-K325 Issue B © 2024 NCR Voyix. All rights reserved. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
-
Page 2: Copyright
NCR Voyix, therefore, reserves the right to change specifications without prior notice. All features, functions, and operations described herein may not be marketed by NCR Voyix in all parts of the world. In some instances, photographs are of equipment prototypes. Therefore, before using this document, consult with your NCR Voyix representative or NCR Voyix office for information that is applicable and current. -
Page 3: Table Of Contents
Table of Contents Copyright Bracket, Wall Mount, Power Supply, Integrated I/O Kit Contents Dimensions Installation Procedure Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions. - Page 4 Revision Record Issue Date Remarks Aug 2020 First Issue Mar 2021 Added Dimensions section Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
-
Page 5: Bracket, Wall Mount, Power Supply, Integrated I/O
Bracket, Wall Mount, Power Supply, Integrated I/O This kit provides a Wall Mount Bracket for the CX7 with Integrated I/O and Power Supply. Kit Contents Dimensions Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions. -
Page 6: Installation Procedure
For drywall, it is preferred, but not necessary, to mount one side of holes to a stud. 2. Install the Bracket on the back of the CX7 (4 screws). Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions. - Page 7 3. Position the Power Supply in the Bracket. 4. Wrap the Power Supply Cable around the Cable Management Hooks on the Bracket then connect the Cable to the I/O. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 8 5. Hook the Terminal to the Adapter. 6. Tighten the Thumbscrew to secure the Bracket. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 9 7. Connect the Power Cord to the Power Supply. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
