- Page 1 Tamper Resistant Cover, Remote I/O Kit Instructions 7772-K200 Issue A © 2024 NCR Voyix. All rights reserved. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 2 NCR Voyix, therefore, reserves the right to change specifications without prior notice. All features, functions, and operations described herein may not be marketed by NCR Voyix in all parts of the world. In some instances, photographs are of equipment prototypes. Therefore, before using this document, consult with your NCR Voyix representative or NCR Voyix office for information that is applicable and current.
- Page 3 Table of Contents Copyright Tamper Resistant Cover, Remote I/O Kit Contents Installation Procedure Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 4 Revision Record Issue Date Remarks Aug 2020 First Issue Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 5 This kit provides a Tamper Resistant Cover for the Remote I/O Chassis of the NCR CX7 All-in- One POS (7772) or NCR CX5 All-in-One POS (7773). Kit Contents Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 6 1. Install the Tamper Resistant Cover on the Remote I/O Chassis using two (2) screws. 2. Loosen the captive screws of the Tamper Resistant Cover and lift the Top Cover to open. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 7 Port Name RJ50 Serial (Enhanced UART) Dual USB 3.0 DisplayPort DB9 Serial (Standard UART) LAN In Connect to Ethernet Network LAN Out Connect to the CX Head Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 8 Callout Port Name USB-C 24V Power In USB 12V USB 24V Cash Drawer Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 9 Cash Drawer A Cash Drawer B DisplayPort LAN In Connect to Ethernet Network LAN Out Connect to the CX Head USB-C 24V Power In USB 24V USB 12V Dual USB 3.0 Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 10 Callout Port Name RJ45 Serial COM5 (Enhanced UART) COM6 (Standard UART) 4. Close the Top Cover and tighten the captive screws. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
