- Page 1 Table Top Stand and Hinge Assembly, CX, Black Kit Instructions 7772-K931 Issue A © 2024 NCR Voyix. All rights reserved. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 2 NCR Voyix, therefore, reserves the right to change specifications without prior notice. All features, functions, and operations described herein may not be marketed by NCR Voyix in all parts of the world. In some instances, photographs are of equipment prototypes. Therefore, before using this document, consult with your NCR Voyix representative or NCR Voyix office for information that is applicable and current.
- Page 3 Table of Contents Copyright Table Top Stand and Hinge Assembly, CX, Black Kit Contents Installation Procedure Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
-
Page 4: Revision Record
Revision Record Issue Date Remarks Oct 2023 First Issue Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions. -
Page 5: Kit Contents
1. Lay the Display face down on a flat surface. Always use a soft material (cloth, foam) to protect the display screen when placing the terminal face down. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions. - Page 6 Remove the two (2) screws that secure the Cable Cover to the Back Cover. b. Rotate and unhook the Cable Cover from the Back Cover. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 7 Remove the Ethernet Cable from the Cable Management Hook then disconnect the Cable. 4. Loosen the two (2) captive screws that secure the Back Cover to the Display. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 8 5. Rotate the Back Cover away from the Display and unhook the Back Cover Tabs. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 9 6. Remove the four (4) screws securing the Display Back Cover to the hinge of the Base. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 10 Insert the Back Cover Tabs into the openings in the back of the Display, then rotate the Back Cover onto the Display. b. Secure the Back Cover with two (2) captive screws. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 11 8. Install the Stand on the back of the Display (4 screws). 9. Connect the Cables on the back of the Display. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 12 10. Route the Cables through the Stand as shown. 11. Secure the Cables on the bridge lance using the Cable Management Strap. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
