- Page 1 INSTALLATION GUIDE Bellucci Granite Workstation Retrofit Top Mount Farmhouse Kitchen Sinks KGTF1-33WH KGTF2-33MBL www.kraususa.com I Toll Free: 1.800.775.0703 I © 2024 Kraus USA Plumbing LLC I REV. October 7, 2024...
- Page 2 Congratulations on the purchase of your new Kraus plumbing fixture! Please keep the box and packaging materials until your product is completely installed. If you have any questions, require technical assistance or have any problems with your product: STOP DO NOT RETURN TO STORE Please contact our Customer Service Team 1-800-775-0703 / customerservice@kraususa.com...
- Page 3 Toll-Free: 800-775-0703 or customerservice@kraususa.com While these step-by-step instructions are intended to assist in the safe installation of a Kraus sink, this product is likely to perform best when installed by a licensed professional. The failure to follow these instructions or to hire a professional when needed may result in personal injury or property damage and may void the warranty.
- Page 4 Screwdriver Closed Toe Shoes Hammer Hole Saw NOTE: Specialized tools may be necessary to install Kraus Quartz Composite Kitchen sinks with countertop materials other than wood, marble or granite. Important Instructions may vary depending on countertop material. Read all ·...
- Page 5 Parts List KGTF1-33WH · Cut-Out Template · Mounting Hardware Strainer PST1-WH · · Cutting Board KCB-WS103AC KGTF2-33MBL · Cut-Out Template · Mounting Hardware · Strainer PST1-BL · Cutting Board KCB-WS103AC Dimensions Ø 1 3/8" (35mm) 3 1/2" (90.7mm) 5" (127mm) R 1 3/8"...
- Page 6 Kit for Top Mount Installation Replacement parts list KP31045 - Top Mount Clips (6 hooks) V2...
- Page 7 Step 1. Position Template · Check the cut-out template against the actual sink to ensure a proper sized cut-out. · Place the cut-out template in the desired location on the countertop. NOTE: Make sure clearance is suitable for backsplash, faucet, and plumbing for the sink. Step 2.
- Page 8 Step 3. Cut Countertop · Cut the opening in the countertop by carefully following the traced line. ! CAUTION - To avoid the risk of personal injury, wear safety glasses and cut resistant gloves with non-slip grip when cutting. NOTE: Please use the appropriate saw that best fits your countertop material.
- Page 9 Step 4. Cut Cabinet Front · Measure height of apron front. Add 1/16" to the dimension when you mark base cabinet front cutout. Use jigsaw to cut. ! CAUTION - To avoid the risk of personal injury, wear safety glasses and cut resistant gloves with non-slip grip when cutting.
- Page 10 Step 5. Add Additional Faucet Holes (Optional) · Determine the location of the faucet. · Place the sink upside down on a suitable flat surface. Using the 35mm (1 3/8”) diamond hole saw at high power (1500tr. per break through in the desired location. ·...
- Page 11 Step 6. Attach Mounting Hardware · Insert the anchors (pre-attached to the mounting hardware) into the sink holes with flat side against the sink and tighten the screws.
- Page 12 Step 7. Install Sink · Clean and dry the surface around the opening of the sink. · Verify that the sink fits correctly in the opening. The edge of the sink must sit on the counter. · Turn the unit upside down to apply sealant. Apply silicone-based sealant (not included) underneath the edge of the sink.
- Page 13 Step 7. Install Sink - continued SINK SILICONE BASED SEALANT SINK COUNTER...
- Page 14 Step 8. Install Plumbing Fixtures · Connect drain to sink. Connect trap to drain. Connect water supply connections to faucet according to manufacturer’s instructions. Run water into sink and check for leaks. ·...
- Page 15 Kraus warrants the structure and finish of the Kitchen Sink to be free from defects in material and workmanship under normal usage for as long as the original purchaser resides in the residence in which the sink was Kitchen Sink was first installed.
- Page 16 TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS WARRANTY DOES NOT COVER, AND KRAUS USA PLUMBING, LLC SHALL NOT BE LIABLE FOR, ANY SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES (INCLUDING LABOR CHARGES TO REPAIR, REPLACE, INSTALL OR REMOVE THIS PRODUCT), WHETHER ARISING OUT OF BREACH OF ANY EXPRESS OR IMPLIED WARRANTY, BREACH OF CONTRACT, TORT, OR OTHERWISE.
- Page 17 IMPORTANT Register Your Kraus Product Activate Your Warranty Access Premium Customer Support Get Product Information REGISTER TODAY http://www.kraususa.com/registration www.kraususa.com...
