I N S T A L L A T I O N I N S T R U C T I O N S
WM-210SI
WM-220SI
WM-240SI
WM-230SI
Dual Stud Short Throw Wall Mounts
Spanish Product Description
German Product Description
Portuguese Product Description
Italian Product Description
Dutch Product Description
French Product Description
WM210-220-230-240S/SI
WM210-220-230-240AUS/AUSI

Advertisement

loading
Need help?

Need help?

Do you have a question about the WM-210SI and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CHIEF WM-210SI

Summary of Contents for CHIEF WM-210SI

  • Page 1 I N S T A L L A T I O N I N S T R U C T I O N S WM-210SI WM-220SI WM-240SI WM-230SI Dual Stud Short Throw Wall Mounts Spanish Product Description German Product Description...
  • Page 2 The short throw projector mounts are designed to be mounted to an 8" concrete, 8"x8"x16" concrete Chief® is a registered trademark of Milestone AV Technologies. block, 2" x 4" wood studs (16" on center), or 2" x 4"-25ga All rights reserved.
  • Page 3 Installation Instructions TABLE OF CONTENTS WM2XXSI/WM2XXAUSI INTERACTIVE MOUNT ..14 Disclaimer ......2 Installing Mount Covers .
  • Page 4 Installation Instructions DIMENSIONS WM2XXS/WM2XXAUS (Standard Model) 240S, TRAVEL 37.2" - 65.6" 16.00 210S, TRAVEL 12.75" - 19.5" 3.96 7.25 7.25 10.81 11.53 3 OF 5.64 5.36 19.63 1.42 1.09 CABLE CHANNEL DIMENSIONS THRU ARM DIMENSIONS: INCHES WM2XXSI/WM2XXAUSI (Interactive Model) 240SI, TRAVEL 37.2" - 65.6" 19.06 406.40 8.69...
  • Page 5 Installation Instructions LEGEND Pencil Mark Tighten Fastener Marcar con lápiz Apretar elemento de fijación Stiftmarkierung Befestigungsteil festziehen Marcar com lápis Apertar fixador Segno a matita Serrare il fissaggio Potloodmerkteken Bevestiging vastdraaien Marquage au crayon Serrez les fixations Drill Hole Loosen Fastener Perforar Aflojar elemento de fijación Bohrloch...
  • Page 6 Installation Instructions TOOLS REQUIRED FOR INSTALLATION 5/32" 3/16" (included) (included) (security) 5/32" - 6" long (included) 1/2" (12.7mm) 1/2" (12.7mm) (security) 3/8" (9.5mm) 7/32" (5.6mm) PARTS (WM2XXS/WM2XXAUS (WM2XXAUS/AUSI Models Only) All Models Models Only) X (1) [RSM] AJ (1) A (1) [Upper cover] [Short throw wall mount] (WM220 shown as example only)
  • Page 7 Installation Instructions SITE REQUIREMENTS - Steel Stud Structure (All Models) WARNING: IMPROPER INSTALLATION CAN LEAD TO EQUIPMENT FALLING CAUSING SERIOUS PERSONAL INJURY OR DAMAGE TO EQUIPMENT! The figure below identifies the minimum requirements for installation of display mounts onto a steel stud structure.
  • Page 8 • The maximum active capture area supported is: 4 ft x 7 ft or up to 94 inches diagonal measure. The Chief Interactive Mount (WM2XXSI/WM2XXAUSI) works • The minimum active capture area supported is: with standard projectors and Windows® and Macintosh®...
  • Page 9 The projection image should start a minimum of 1 inch from the base of the top frame of the whiteboard. • The projection image should be positioned within the fan area extending from the Chief Interactive Dual Mount. This fan area should not exceed 140 degrees. Whiteboard Constraints •...
  • Page 10 Installation Instructions INSTALLATION - (All Models) The WM2XXS/SI/AUS/AUSI short throw projector mounts can (L) x 4 be mounted to concrete, concrete block, wood studs or steel (M) x 4 studs. They can be mounted to 2" x 4" wood studs 16" apart. (K) x 4 WARNING: ELECTRICAL SHOCK HAZARD! CUTTING...
  • Page 11 Installation Instructions Install four 5/16 x 2-1/2" hex head lag screws (L) through Hold metal channel on anchor (P) flat alongside plastic four 5/16" washers (M), holes of wall bracket and into drilled straps and slide channel through hole. (See Figure 9) holes.
  • Page 12 Installation Instructions 10. Place wall bracket over anchors and align mounting holes Slide lower plate onto cross bracket on mounting bracket. in display mount with holes in anchors. (See Figure 12) (See Figure 14) 11. Insert 1/4-20 x 1-3/4" Phillips pan head screws (N) through 1/4"...
  • Page 13 (See through RSM holes and into projector mounting plate. (See Table 1) Figure 19) NOTE: UL Listed Chief projector interfaces RPM, RPA and RSA are sold separately. RSM (X) is included with WM2XXAUS/WM2XXAUSI models. (bottom view) Mounting plate...
  • Page 14 Installation Instructions UL Listed RPA Installation Line up mounting holes on RPA mount with corresponding IMPORTANT ! : Complete the installation by holes on projector mounting plate. (See Figure 17) proceeding to WM2XXSI/WM2XXAUSI Interactive Mount section or WM2XXS/WM2XXAUS Standard Install four 1/4-20 x 3/8" Phillips pan machine screws (G) through RPA holes and into projector mounting plate.
  • Page 15 Installation Instructions Lower the upper cover (X) onto the wall mount and lower Remove and save two 8-32 x 3/8" Phillips pan head screws cover, and fasten with two 8-32 x 3/8" Phillips pan head (AB) from lower cover. (See Figure 26) screws (AB).
  • Page 16 Installation Instructions NOTE: Cables may be routed from below and up wall bracket channel, or from above and down behind and into wall (view from front) mount. Cables • Routing Cables from Below (Steps 6 and 7) Open cable clips along bottom edge of wall bracket. (See Surface Mount Figure 28) Cable Accessory...
  • Page 17 Installation Instructions 10. (Optional) Cables can be tied to inside of mount’s front Installation of Wall Bracket Covers cover using cable ties (not included). Route cables near front cover and wrap cable tie through slots on front cover NOTE: If security screws are going to be used, use the security and around cables.
  • Page 18 Installation Instructions Adjustments Return outer covers to the mount following instructions in Installing Mount Covers section. Pitch Adjustment Extension Adjustment IMPORTANT ! : The mount covers need to be removed Loosen two bolts holding stop bracket in place on underside before proceeding with pitch adjustment.
  • Page 19 Installation Instructions Security Screw Installation (Optional) Mount Covers Remove two 8-32 x 3/8" Phillips pan head screws (AB) from Wall Bracket Covers upper cover. (See Figure 42) Remove eight #8-32 x 1/2" Phillips pan machine screws (F) Raise and remove the upper cover from the mount. (See from wall bracket covers.
  • Page 20 Installation Instructions Install two 8-32 x 3/8" button head security screws (AA) into lower cover. (See Figure 44) Stop bracket (AA) x 2 Figure 46 Install two 1/4-20 x 1/2" button head security screws (T) through holes in stop bracket and into holes in sliding nuts. (See Figure 47) Figure 44 Replace upper cover and install two 8-32 x 3/8"...
  • Page 21 Installation Instructions Remove one of four bolts from adapter plate. (See Figure 48) WM2XXS/WM2XXAUS STANDARD MOUNT Installing Mount Covers Raise the lower cover (AK) to wall mount and hold in place. (See Figure 50) Adapter plate x 4 (one at a time) Figure 48 (AK) Install one 1/4-20 x 3/4"...
  • Page 22 Installation Instructions Cable Management (Optional) Remove cable management covers (if necessary) from short throw projector arm. (See Figure 54) In most cases, cable management covers will NOT need to be removed in order to route cables from projector to the wall (bottom view) mount.
  • Page 23 Installation Instructions • Routing Cables from Above (Step 7) (Optional) Cables can be tied to inside of mount’s front cover using cable ties (not included). Route cables near Thread cables down through a surface mount cable front cover and wrap cable tie through slots on front cover accessory (not included), then behind and into the wall and around cables.
  • Page 24 Installation Instructions Place wall bracket top caps (C) over top of each wall bracket Adjustments arm. (See Figure 61) Pitch Adjustment IMPORTANT ! : The mount covers need to be removed before proceeding with pitch adjustment. NOTE: Remove mount covers from the mount following (C) x 2 instructions in Removing Mount Covers section.
  • Page 25 Installation Instructions Extension Adjustment Security Screw Installation (Optional) Loosen two bolts holding stop bracket in place on underside Wall Bracket Covers of short throw projector mount. (See Figure 65) Remove eight #8-32 x 1/2" Phillips pan machine screws (F) Adjust mount to desired extension length. (See Figure 65) from wall bracket covers.
  • Page 26 Installation Instructions Mount Covers Remove two #8-32 x 1/2" Phillips pan machine screws (F) Stop bracket holding mount covers on projector arm. (See Figure 69) Install two #8-32 x 1/2" button head security screws (V) into holes on mount cover. (See Figure 69) (F) x 2 Figure 70 Install two 1/4-20 x 1/2"...
  • Page 27 Installation Instructions Adapter Plate Bolts Remove projector from short throw projector mount according to projector interface instructions. Adapter plate NOTE: For most projectors, it will be necessary to remove projector prior to installing four security screws to Plastic spacer projector bracket. For ease of installation, it is recommended to remove projector prior to performing the following steps.
  • Page 28 Europe A Franklinstraat 14, 6003 DK Weert, Netherlands P +31 (0) 495 580 852 F +31 (0) 495 580 845 Chief Manufacturing, a products division Asia Pacific A Office No. 1 on 12/F, Shatin Galleria of Milestone AV Technologies 18-24 Shan Mei Street...
