- Page 1 EN - INSTRUCTIONS FOR USE F900E Last update: V1 - 15/02/2024 90 N.m 630 Wh 250 W 50 80 km...
- Page 2 CONTENTS INTRODUCTION ..........................2 SAFETY INFORMATION ........................2 YOUR PRODUCT ..........................4 ASSEMBLY ............................5 BEFORE EACH USE ........................11 CONNECTIVITY ..........................12 GENERAL OPERATION ........................12 ELECTRIC OPERATION ........................13 CHARGING ............................14 ERROR CODES ..........................18 MAINTENANCE ..........................20 ACCESSORIES ..........................
- Page 3 In case of contact with skin and/or eyes, rinse thoroughly, remove solid particles and contaminated clothing. Seek medical assistance. If the battery leaks, put on gloves and place the battery in a plastic bag. Return the battery to your Decathlon store immediately.
- Page 4 YOUR PRODUCT Rear light Integrated lock MOTOR Display Charging port Battery Front light This bike refers to category 1 of the EN 17406 standard. It is not intended for uses in categories 2, 3, 4, 5 and 6 of this same standard.
- Page 5 To ensure the handlebars, stem, seat, seat post and wheels are correctly attached, it’s best to use the appropriate tools and tighten each component to its specific torque value (in Nm). Please follow the bicycle assembly instructions to avoid any safety risks. If you have a problem, contact a Decathlon workshop to have your bike checked. BOX CONTENTS...
- Page 6 FRONT SEAT ASSEMBLY: Undo the velcro that holds the seat up and place the brackets outwards. Pull the seat down. Replace the brackets under the seat, taking care to insert them into the locking tabs until they click. WINDSHIELD ASSEMBLY: 2 x M8 x 30mm Position the windshield at 45°...
- Page 7 CANOPY ASSEMBLY (PART TWO): Unzip the canopy cover and unfold it entirely along both the hoops. Secure the canopy by passing the tabs through the elastics on the sides of the cargo and hooking them onto themselves. Warning: do not wedge the canopy between the hoop and the windshield. REAR WINDSHIELD ASSEMBLY: Unzip the rear windshield cover and deploy it along the hoop (the contour of the windshield is magnetic).
- Page 8 SADDLE ADJUSTMENT: Adjust the seat height according to your own height: To work this out, sit on the bike with your heel resting on the pedal in the low position. The crank arm should be parallel to the seat post. When your leg is almost straight with a slight bend in the knee, the saddle height is correct.
- Page 9 INTEGRATED LOCK SYSTEM The bike is equipped with an integrated lock. Turn the key clockwise to unlock it and anticlockwise to lock it. Note : do not forget to remove your key from the lock. STORAGE Your bike is equipped with easily reachable storage : an open compartment and a lockable one.
- Page 10 Is it really sunny and hot ? Ride your hair in the wind! Fold the rear windshield back in its cover. Fold the canopy cap and put the entire canopy back to its cover. Note : To prevent the windshield from slamming on the hoop, use the elastic provided for this purpose to attach the windshield to the hoop. TORQUE SETTINGS Component Tightening torque...
- Page 11 For your safety, check the front and rear brakes before each use of your bike. They must be in perfect condition. Check all brake mounting components regularly. Disc brakes should be checked regularly. In the event of a brake fluid leak, action is required. Get in touch with a Decathlon workshop.
- Page 12 To activate your bike, dowload the Deacthlon Geocover app. This bike is connected and equipped with a GPS tracking system. It allows you, via the Decathlon Geocover application (to download for free on your smartphone), to view the position of the bike in real time and to have a certain amount of information concerning your journeys and the state of health of the bike, for example.
- Page 13 Long press : (2 seconds) Activate/deactivate the walk mode ASSISTANCE LEVELS The F900E is an electrically assisted bike and can be used with or without assistance by operating the handlebar located remote and selecting modes OFF-ECO-TOUR-SPORT. The selected mode will be displayed with a color code on your display.
- Page 14 NAVIGATION THROUGH SCREENS During your journey, the screen will display several data fields on 5 pages. You can scroll through these pages using the buttons Hour Distribution of power delivered by the motor and the rider Battery level Assistance level Speed Screen mark Remaining battery life with current battery level and assistance mode...
- Page 15 CHARGE LEVELS 71-100% 41-70% 11-40% <3% <3% RANGE The battery life of the electric bike depends on numerous factors: • The weight on the bike: Overloading the bicycle will reduce the battery life (panniers, baby carrier etc.) • Use: Based on the human effort put in when pedalling, the battery life will be shorter or longer. •...
- Page 16 INSERTING THE BATTERY To insert the battery again, process the opposite way. First put the battery in its base. Then, push it into place until you hear a click. Finally, put the rear seat back in place. CHARGING (REMOVING THE BATTERY) You can charge the battery removing it from the bike.
- Page 17 CHARGING (PLUG THE BIKE) 100% Open the hatch located behind the cargo. Plug the charger into a power outlet, then into the bike’s charging socket. The LED appears red at the start of charging. A full charge will take 4 hours. The LED appears green at the end of charging. You can unplug the charger from the bike and the power outlet. Never leave the charger plugged into a power outlet alone.
- Page 18 ERROR CODES ERROR CODE Meaning Solutions Check the connections. If the problem persists, please take the bike to a Decathlon MOTOR_ERROR workshop. Restart the bike. If the problem persists, please take the bike to a Decathlon OVER_CURRENT_PROTECTION workshop. Error in the HMI-ECU communication. Check the connections. Go to MODE COMM_HMI_ECU_ERROR 0 assistance level.
- Page 19 ERROR CODE Meaning Solutions Power sytem error. If the problem persists, please take the bike to a Decathlon POWER_STAGE_ERROR workshop. Motor controller sensors error. If the problem persists, please take the bike to a ANALOG_INPUT_ERROR Decathlon workshop. MC_UNDER_TEMP Motor controller under temperature. Go to a warmer place.
- Page 20 • If the wheels are tubular, refer to the manufacturer’s instructions for gluing the tubulars to the rim. • Regularly check the wheels, especially the rims (excessive wear, deformation, dents and cracks). Feel free to contact a Decathlon workshop for a wheel analysis and part replacement if necessary.
- Page 21 When changing batteries, remember to return them to a collection point for recycling. Your bicycle is equipped with electrical components that cannot be disposed of in your household waste. Contact a Decathlon store for recycling (battery, screen, lighting, etc.).
- Page 22 https://www.decathlon.com.tr/...
