Summary of Contents for Decathlon E-ACTV900
- Page 1 EN - INSTRUCTIONS FOR USE E-ACTV900 Last update: V1 - 10/05/2024 <150kg >1,55m/ 5ft 08in <2m/ <330.6lbs 6ft 6in...
-
Page 2: Table Of Contents
CONTENTS INTRODUCTION ..........................3 SAFETY INFORMATION ........................3 YOUR PRODUCT ..........................4 ASSEMBLY ............................5 BEFORE EACH USE .......................... 9 GENERAL OPERATION ........................10 ELECTRIC OPERATION ........................10 CHARGING ............................13 ERROR CODES ..........................15 MAINTENANCE ..........................16 ACCESSORIES ..........................17 TRANSPORT ............................ -
Page 3: Introduction
Never allow children to play with or handle the battery. Do not use the battery if the compliance indicator is broken. If so, bring your battery in for recycling. In case of battery leakage: put on gloves and place the battery in a plastic bag. Return your battery to a Decathlon store immediately. -
Page 4: Your Product
Failure to comply with such use may result in physical injury and/or material damage to your bike, as well as restriction to the warranty conditions. The E-ACTV900 is an electrically assisted bicycle and can be used with or without assistance. -
Page 5: Assembly
To ensure the handlebars, stem, seat, seat post and wheels are correctly attached, it’s best to use the appropriate tools and tighten each component to its specific torque value (in Nm). Please follow the bicycle assembly instructions to avoid any safety risks. If you have a problem, contact a Decathlon workshop to have your bike checked. BOX CONTENTS We advise that two people should take the bike out of its box. -
Page 6: Handlebar Assembly
HANDLEBAR ASSEMBLY : 1. Unscrew the two small screws on the side of the stem. 2. Position your handlebar so that they are perpen- dicular to your wheel. 3. Screw the two small screws on the side of the stem. 4. -
Page 7: Pedal Assembly
PEDAL ASSEMBLY : LEFT RIGHT The bike is equipped with a right pedal (marked R or Right) and a left pedal (marked L or Left). Tighten them firmly with the indicated tool. 10Nm 10Nm TORQUE SETTINGS : To ensure proper attachment of the handlebars, stem, saddle, seat post, and wheels, it is recommended to use appropriate tools and apply tightening force in accordance with the specific tightening torques for each of the components (in N.m). -
Page 8: Before Each Use
For your safety, check the front and rear brakes before each use of your bike. They must be in perfect condition. Check all brake mounting components regularly. Disc brakes should be checked regularly. In the event of a brake fluid leak, action is required. Get in touch with a Decathlon workshop. -
Page 9: General Operation
GENERAL OPERATION BRAKE OPERATION: The front brake is controlled by the left brake lever (or by the right brake lever in certain countries such as India, China, United Kingdom, etc.). The rear brake is controlled using the right-hand lever (or left in the countries listed above). Before using the bicycle, check which levers operate the front and rear brake. The brake lever must not come into contact with the handlebar. - Page 10 NAVIGATION THROUGH SCREENS : Bluetooth on/off User-generated power (in W) Current speed Current speed Light ON/OFF Average speed Current speed Maximum speed Time Trip Time Battery status Average electrical power (in W) Remaining autonomy in Km Average user-generated power (in W) Trip distance Burnt calories (in kcal) Electrical power (in W)
- Page 11 ASSISTANCE LEVELS : The electrically assisted bike can be used with or without assistance by pressing the e-shifters and switching between OFF-ECO-TOUR-SPORT-TURBO modes. The selected mode will be displayed on your display screen. The selectable OFF-ECO-TOUR-SPORT-TURBO assistance modes let you choose a power assist level in addition to the effort provided.
-
Page 12: Charging
>6’’ Download the Decathlon Ride app via Google Play or App Store. Activate your smartphone Bluetooth®. Press the indicated button of the remote to pair your smartphone with the display. You should see the Bluetooth® symbol enlight when it is activated. - Page 13 PRECAUTIONS FOR USING THE BATTERY AND CHARGER : Battery to be handled with care. Impact sensitive. Do not expose the battery to temperatures above 40°C in use. Charge your battery in a dry place at a temperature between 10°C and 40°C. To ensure the performance of your battery, store it between 30 and 60% charge.
-
Page 14: Charging Your Smartphone
CHARGING (PLUGGING THE BIKE) 4H30 1. Lift the cover of the charging socket and plug the charger into the charging socket. Then, plug it into the power outlet. Charge time: 4H30. The LED appears red at the start of charging. 2. -
Page 15: Maintenance And Lifetime (Warranty Conditions)
MAINTENANCE AND LIFETIME (WARRANTY CONDITIONS) Do not store the discharged battery (1 flashing blue LED) to avoid deep discharge, which may cause it malfunction. In cases of extended storage, recharge the battery once every 3 months. It can be stored up to 6 months without decreasing its capa- cities only if it’s 60% charged. -
Page 16: Maintenance
(derailleur, lever), suspension, brake levers as well as the chain. For more information on use, maintenance, after-sales services or if you have any questions, visit DECATHLON’s support website (www.support.decathlon.com) or visit a DECATHLON store. BRAKES: • Brake pads wear out with the different braking operations performed. Braking performance decreases over time, so you need to check your brakes regularly and replace them if necessary (lining <... -
Page 17: Accessories
Attaching a trailer is possible on this bike. Always use a trailer refering to the bike trailer standard - EN 15918 for Europe. We guarantee the compatibility with trailers branded Decathlon, Hamax, Croozer and Add-One. Other brands of trailers are not excluded but remember to check compatibility before your purchase (quick-release axle compatibility + support on base). - Page 18 https://www.decathlon.com.tr/...
