Plantronics CA10 User Manual

Plantronics CA10 User Manual

Cordless telephone headset amplifier
Hide thumbs Also See for CA10:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
CA 10_1
12/12/01
3:46 PM
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CA10 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Plantronics CA10

Summary of Contents for Plantronics CA10

  • Page 1 CA 10_1 12/12/01 3:46 PM Page 1...
  • Page 2 CA 10_1 12/12/01 3:46 PM Page 2...
  • Page 3 345 Encinal Street Santa Cruz, California 95060 800.544.4660 © 2001 Plantronics Inc. All rights reserved. Plantronics, www.plantronics.com the logo design, and the Plantronics and logo design combined are registered trademarks of Plantronics Inc. Patents U.S. 5,259,780 and 5,835,852 Printed in USA.

  • Page 4: User Guide

    CA 10_1 12/12/01 3:46 PM Page 4 Cordless Telephone Headset Amplifier Model CA10 User Guide...
  • Page 5 CA 10_1 12/12/01 3:46 PM Page 5 TALK CHANEL MUTE VOLUME Power Talk TALK TALK Charge Power CHANEL MUTE Talk CHANEL MUTE Charge VOLUME VOLUME TALK TALK Power Talk TALK Charge CHANEL MUTE VOLUME...
  • Page 6 CA 10_1 12/12/01 3:46 PM Page 6 DIAGRAM MUTE VOLUME 1 2 3...
  • Page 7 CA 10_1 12/12/01 3:46 PM Page 7 DIAGRAM KEY Remote Unit In-Use Indicator Light Battery Charge Light Talk Button Talk Volume Control Headset Jack Page Button Mute Indicator Light Talk Button Channel Button Remote Unit Charging Well Base Unit (Rear) Headset Cable Retainer Antenna Transmit Level Switch...

  • Page 8: Warranty And Service

    Try our Fax-on-Demand Information Services at: Tel. (800) 544-4660 (Prompt #4) The name Plantronics and the Plantronics logo are registered trademarks of Plantronics, Inc. Quick Disconnect is a trademark of Plantronics, Inc.
  • Page 9 CA 10_1 12/12/01 3:46 PM Page 9...
  • Page 10 CA 10_1 12/12/01 3:46 PM Page 10...
  • Page 11 CA 10_1 12/12/01 3:46 PM Page 11 WEL CO ME Thank you for selecting the CA10 Cordless Telephone Headset Amplifier from Plantronics. This User Guide will help you install your CA10 Amplifier and learn its basic operation. The headset is described in a separate guide which should be read prior to installing the Amplifier.

  • Page 12: Important Safety Instructions

    CA 10_1 12/12/01 3:46 PM Page 12 IMPORTANT SAFETY INSTRUCTIONS When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following: 1. Read and understand all instructions. 2.
  • Page 13 CA 10_1 12/12/01 3:46 PM Page 13 IMPORTANT SAFETY INSTRUCTIONS 10. Never push objects of any kind into this product through base unit slots as they may touch dangerous voltage points or short out parts that could result in a risk of fire or electric shock. Never spill liquid of any kind on the product.
  • Page 14 19. This product should be intended to be supplied by a Listed Class 2 Direct Plug-In Power Unit rated 9VDC 800mA. Plantronics Part No. 45669-01, rated at an input voltage of 120 VAC, 60Hz and an output voltage of 9 VDC at 800mA.
  • Page 15 CA 10_1 12/12/01 3:46 PM Page 15 IMPORTANT SAFETY INSTRUCTIONS CAUTION: To reduce the risk of fire or injury to persons, read and follow these instructions. 1. Use only the battery pack supplied with this product. 2. Do not dispose of battery pack in a fire. The cells may explode. Check with local codes for possible disposal instructions.
  • Page 16 3:46 PM Page 16 STEP 1 SETUP Connect the CA10 Amplifier to your telephone using the illustrations on page ii. Unplug the telephone handset from the jack on your telephone base and insert into the Handset Jack on the underside of the CA10 Base Unit.
  • Page 17 CA 10_1 12/12/01 3:46 PM Page 17 Note: Remote Unit must remain in the Base for 5 seconds to establish a communications link before the system can function. Prior to first use, the Battery must charge for 8 hours before the Remote will operate away from the Base.

  • Page 18: Placing A Call

    CA 10_1 12/12/01 3:46 PM Page 18 STEP 2 PLACING A CALL With your headset in position, place the handset off-hook. Press the Talk Button on either the Remote or the Base Unit The In-Use Indicator Lights on the Remote and Base Unit will light and you will hear a dial tone.

  • Page 19: Receiving A Call

    CA 10_1 12/12/01 3:46 PM Page 19 STEP 3 RECEIVING A CALL With your headset in position, when your telephone notifies you of an incoming call, place the handset off-hook. Press the Talk Button on either the Remote or the Base Unit The In Use Indicator Lights will go on.

  • Page 20: Page Function

    CA 10_1 12/12/01 3:46 PM Page 20 STEP 4 PAGE FUNCTION If someone at the Base Unit needs to summon you, pressing the Page Button momentarily causes the Remote to emit two long, loud beeps. If you have misplaced the Remote, press the Page Button for 3 seconds and the Remote will emit a steady alert.
  • Page 21 CA 10_1 12/12/01 3:46 PM Page 21 AUDIO VISUAL PROMPTS VISUAL REMOTE Talk (In-Use) — Green LED. On only when Remote or Base Unit TALK button is activated. Flashes in time with telephone ringer when optional Handset Lifter (see Accessories) is used. Mute —...

  • Page 22: Troubleshooting

    CA 10_1 12/12/01 3:46 PM Page 22 TROUBLESHOOTING I CANNOT HEAR A DIAL TONE Make sure your Remote Battery Pack is securely seated in the Charging Well and/or fully charged. The Battery Pack must charge for 8 hours prior to first use. Check that all cords are correctly connected and firmly in place.
  • Page 23 Press the Channel Button until you get a clear signal. Ensure Manual Channel Settings are “0/0”. If others are using a CA10 Amplifier in your immediate vicinity, call Plantronics for instructions on adjusting the channel control settings. I NEED MORE TALK TIME A second Battery Pack may be held in the Charging Well while the Remote Unit is in use.
  • Page 24 On Line Indicator [OLI] (P/N 46656-01) Alerts co-workers that you are on the phone. Plugs into the Accessory/Lifter jack. INFORMATION ON SUPPLIES AND ACCESSORIES Call Plantronics at 1-800-544-4660 or visit our website at www.plantronics.com. See also Diagram Key for additional part numbers.
  • Page 25 CA 10_1 12/12/01 3:46 PM Page 25 FCC REGISTRATION INFORMATION FCC REQUIREMENTS—PART 15 NOTE: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference, and This device must accept any interference received, including interference that may cause undesired operation.
  • Page 26 (“Warranty Period”). The obligation of Plantronics under this warranty shall be limited to repair or replacement, at Plantronics’ option, without charge, of any part or unit that proves to be defective in material or workmanship during the Warranty Period.
