  • Page 3 © 2001–2005 Plantronics, Inc. All rights reserved. Plantronics, the logo design, Plantronics and the logo design combined, and Quick Disconnect are trademarks or registered trademarks of Plantronics, Inc. Patents U.S. 5,259,780; 5,835,852 and Patents Pending Printed in U.S.A. 69096-01 (2•05)
  • Page 4 Cordless Telephone Headset Amplifier Model CA10 User Guide...
  • Page 5 Power Talk Charge TALK TALK CHANEL MUTE VOLUME Power Talk TALK Charge CHANEL MUTE VOLUME TALK Power Talk TALK Charge CHANEL MUTE VOLUME TALK CHANEL MUTE VOLUME...
  • Page 6 DIAGRAM...
  • Page 7 DIAGRAM KEY Remote Unit In-Use Indicator Light Talk Button Headset Jack Mute Indicator Light Channel Button Headset Cable Retainer Antenna Ringer ON/OFF [for use with optional Lifter] Mute Button Listen Volume Control Headset Adapter Cable (P/N 43446-02) [not included with CS10 model] Base Unit (Front) Headset Holder/Antenna...

  • Page 8: Warranty And Service

    We may use functionally equivalent reconditioned/refurbished/ remanufactured/pre-owned or new Products or parts. • To obtain service in the U.S. contact Plantronics at (800) 544-4660 and in Canada call (800) 540-8363. If you need additional information, please contact our service centers at the numbers provided.
  • Page 10 WEL CO ME Thank you for selecting the CA10 Cordless Telephone Headset Amplifier from Plantronics. This User Guide will help you install your CA10 Amplifier and learn its basic operation. The headset is described in a separate guide which should be read prior to...

  • Page 11: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following: 1. Read and understand all instructions. 2. Follow all warnings and instructions marked on the product.
  • Page 12 IMPORTANT SAFETY INSTRUCTIONS 9. Never push objects of any kind into this product through base unit slots as they may touch dangerous voltage points or short out parts that could result in a risk of fire or electric shock. Never spill liquid of any kind on the product. 10.
  • Page 13 17. Use caution when installing or modifying telephone lines. 18. This product is intended to be supplied by a Listed Class 2 Direct Plug-In Power Unit rated 9VDC 800mA. Plantronics Part No. 45669-01, rated at an input voltage of 120 VAC, 60Hz and an output voltage of 9 VDC at 800mA.
  • Page 14 IMPORTANT SAFETY INSTRUCTIONS CAUTION: To reduce the risk of fire or injury to persons, read and follow these instructions. 1. Use only the battery pack supplied with this product. 2. Do not dispose of battery pack in a fire. The cells may explode. Check with local codes for possible disposal instructions.
  • Page 15 STEP 1 SETUP Connect the CA10 Amplifier to your telephone using the illustrations on page ii. Unplug the telephone handset from the jack on your telephone base and insert into the Handset Jack CA10 Base Unit. Using the Short Cord CA10 Telephone Jack handset jack.
  • Page 16 Note: Remote Unit must remain in the Base for 5 seconds to establish a communications link before the system can function. Prior to first use, the Battery must charge for 8 hours before the Remote will operate away from the Base. You may, however, use the Remote while it is in the Charging Well.

  • Page 17: Placing A Call

    STEP 2 PLACING A CALL With your headset in position, place the handset off-hook. Press the Talk Button on either the Remote The In-Use Indicator Lights will light and you will hear a dial tone. If you do not hear a dial tone, move the Configuration Switch to the opposite setting (A or B).

  • Page 18: Receiving A Call

    STEP 3 RECEIVING A CALL With your headset in position, when your telephone notifies you of an incoming call, place the handset off-hook. Press the Talk Button on either the Remote The In Use Indicator Lights Replace the handset upon completion of the call and press the Talk Button on either the Remote Indicator Lights or the Base Unit...

  • Page 19: Page Function

    STEP 4 PAGE FUNCTION If someone at the Base Unit needs to summon you, pressing the Page Button momentarily causes the Remote to emit two long, loud beeps. If you have misplaced the Remote, press the Page Button for 3 seconds and the Remote will emit a steady alert.
  • Page 20 AUDIO VISUAL PROMPTS VISUAL REMOTE Talk (In-Use) — Green LED. On only when Remote or Base Unit TALK button is activated. Flashes in time with telephone ringer when optional Handset Lifter (see Accessories) is used. Mute — Red LED. On only when transmit audio is “muted.” BASE Power —...

  • Page 21: Troubleshooting

    TROUBLESHOOTING I CANNOT HEAR A DIAL TONE Make sure your Remote Battery Pack is securely seated in the Charging Well and/or fully charged. The Battery Pack must charge for 8 hours prior to first use. Check that all cords are correctly connected and firmly in place. Pay special attention that Handset and Telephone cords are properly connected.
  • Page 22 I CAN HEAR OTHER CORDLESS DEVICE USERS Press the Channel Button Ensure Manual Channel If others are using a CA10 Amplifier in your immediate vicinity, call Plantronics for instructions on adjusting the channel control settings. I NEED MORE TALK TIME A second Battery Pack may be held in the Charging Well while the Remote Unit is in use.

  • Page 23: And Accessories

    On Line Indicator [OLI] (P/N 46656-01) Alerts co-workers that you are on the phone. Plugs into the Accessory/Lifter jack. INFORMATION ON SUPPLIES AND ACCESSORIES Call Plantronics at 1-800-544-4660 or visit our website at www.plantronics.com. See also Diagram Key for additional part numbers.

  • Page 24: Fcc Registration Information

    FCC REGISTRATION INFORMATION FCC REQUIREMENTS—PART 15 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation.
  • Page 25 FCC REGISTRATION INFORMATION FCC REQUIREMENTS—PART 68 This equipment complies with Part 68 of the FCC rules and the requirements adopted by ACTA. On the exterior of this equipment is a label that contains a product identifier in the format US:AAAEQ##TXXXX. If requested, this information must be provided to your telephone company.
