Assa Abloy IKON eCLIQ N109 User Instructions

C
The EU Declaration of Conformity
ASSA ABLOY
0637 Sicherheitstechnik GmbH
Attilastr. 61 – 67
12105 Berlin
GERMANY
Tel. + 49 30 8106-0
berlin @ assaabloy.com
www.assaabloy.com/de
Disposal
The following applies to products marked with the symbol
dustbin):
The applicable environmental protection regulations must be observed. Do
not dispose of electrical devices in the household waste.
Packaging Packaging materials must be recycled. You can also give packaging material
to the distributor or trade professional for disposal free of charge at the
place of handover.
Batteries
The product contains disposable or rechargeable batteries. Batteries must be
N
removed from the product (see „Replacing the battery") and disposed of
separately.
Used batteries should not go in household waste and can be returned to any
local collection point free of charge. You are legally obliged to recycle used
Li
batteries.
Battery contains
Lithium
Product WEEE reg. no. DE 69404980
N
You must dispose of the product correctly as electronic scrap after use and
take it to a local collection point for recycling free of charge.
You have the following additional options for free disposal through the
distributor:
Return an old device with similar functions at the place where the new
device is delivered.
Return a maximum of three similar old appliances (max. edge lengths
25 cm) to a retail store with no obligation to purchase a new one.
The take-back obligation applies to distributors of electrical appliances with
a sales area of over 400 m² or to distributors of foodstuffs that offer
electrical appliances several times a calendar year or continuously with a
total sales area of 800 m². In the case of online providers, the total storage
and shipping areas for electrical appliances are considered retail space. For
further details, see German Electrical and Electronic Equipment Act Section
17 (1)(2) [ElektroG3 §17 (1)(2)].
Distributors using means of remote communication must, upon delivery,
collect or take away free of charge heat exchangers, screens, monitors and
devices containing screens with a surface area greater than 100 square
centimetres and devices in which at least one of the external dimensions is
greater than 50 centimetres. For lamps and smaller devices in particular,
they must ensure suitable return options at a reasonable distance.
is available in the download area of
N
(crossed out
eCLIQ
User instructions
N109
1. Your key is a high-quality electronic product. Protect the key from dirt and moisture.
2. Where malfunctions are due to wetness, only wipe the key dry.
3. On actuation of the cylinder, there is a release delay of
If the battery is low, this delay can be 0.3 seconds.
4. Battery life:
User key 100,000 locking operations over approximately 10 years
Beluga key 20,000 locking operations,
B1 = 7 years, B2/B3 = 5 years.
The battery in the BELUGA version cannot be replaced.
5. Key ambient temperature: –30 °C to +50 °C
6. Key featuring 'ATEX=II 2G Ex ib IIC T4 Gb' for use in potentially explosive areas of Zone 1
II 2G Ex ib IIC T4 Gb
IBExU14ATEX1125X
The key sends signals as soon as it is inserted into the cylinder.
Comment
Normal state
Battery low, replace
Locking authorisation OK
Keine Schließberechtigung
No locking authorisation,
because the key is currently
outside of the time zone
Update of authorisation (only
relevant for CLIQ GO systems)
approx. 0.1 seconds.
Acoustic signal Visual signal
-
3 x long 3 x long, green
1 x short 1 x short, green
3 x short 3 x short, red
3 x short short, red - green - red
1 x short green,
1 x short, 1 x long
1 x long green
-
