Assa Abloy NORTON RIXSON 73 Installation Instructions Manual

Model 73 Overhead Concealed Closer
Non-Hold Open and Hold Open
Metal Frame Installation Instructions
WARNING
This product can expose you to lead which is known to the
state of California to cause cancer and birth defects or other
reproductive harm.
For more information go to: www.P65warnings.ca.gov.
Model 73, Center Pivot Hung
Components
(Supplied fasteners shown on page 3)
Cover Plate
70202-(finish)
Pivot Kit
70224KIT- (finish)
Tools Needed
Phillips Flathead
Screwdriver Screwdriver
Copyright © 2021, 2023, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole or in
part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
IS73 Rev 3 04/23
Closer Body
73 LAP or PH73 LAP (ADA)
AND
#7
5/16" 3/8"
Hex
Drill
for Metal
Wrenches
Approved 2024-05-15
READ AND FOLLOW ALL INSTRUCTIONS.
SAVE THESE INSTRUCTIONS.
Arm
70218-(finish)
Optional Hold Open
Assembly (90254)
Level
1/4-20 3/16"
Hammer Drill
for Wood
Track
(90239)
Retrofit Track Spacer and
Screws, Optional (90260)
Not for new installation.
Replacement only.
Consult factory.
Slider
(90253)
Slider Centering
Hub (70219)
Tape
Framing
Measure
Square
Grout
Spreader
Plumb Bob Tool
Non Hold Open
Stop Block (90255)
Pencil
Hammer
