8000 Series Door Closer
Regular, Top Jamb, or Parallel Arms Non-Hold Open
Installation Instructions
WARNING
This product can expose you to lead which is known
to the state of California to cause cancer and birth
defects or other reproductive harm.
For more information go to: www.P65warnings.ca.gov.
Regular Arm
Right Hand Door - RH
Left Hand Reverse - LHR
Left Hand Door - LH
Right Hand Reverse - RHR
To Determine Date Code:
Included Components
Backcheck Valve
Latch Valve
Closer
Body
Regular Arm/
Top Jamb Shoe
Sweep Valve
1618A Parallel
Main Arm
Arm Bracket
Closer Arm
Copyright © 2004, 2017, 2023, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
80-9380-2206-020 Rev 3 11/23
Right Hand Door - RH
Left Hand Reverse - LHR
NOTE: "DA" sufflix (Delayed Action) is an optional feature.
To Determine Hand of Door:
Right Hand
Reverse
LEFT
HAND
DOOR
Date
Code
Power Adjustment Shaft
Pinion Cap
(1639)
Cover
Insert
Connecting Rod
Forearm
Screw
Screw Pack
Approved 2024-05-08
Non-Hold Open
Arm Models
8101, 8301, 8501
Top Jamb Mount
Left Hand Door - LH
Right Hand Reverse - RHR
Left Hand
Reverse
RIGHT
HAND
DOOR
Cover
8301
Clips
Standard Slim
Line Cover
Cover
Insert
Screw
Cutouts
8501
Standard Full
NOTE: Architectural Cover
Cover
CAN NOT be used for doors
swinging over 120° using parallel mount.
READ AND FOLLOW ALL INSTRUCTIONS.
SAVE THESE INSTRUCTIONS.
An incorrectly installed or improperly
adjusted door closer can cause
property damage or personal injury.
These instructions should be
followed to avoid the possibility of
misapplication or misadjustment.
Parallel Arm
Right Hand Door - RH
Left Hand Reverse - LHR
Tools Needed:
Tape
Measure Punch Pencil
and
#7 1/4-20
Safety
Glasses
Drill
for Metal
Standoffs
Cover
Screw
Cover
Screw
8501M Insert Cutouts
Standard
Cover Insert
Metal Cover
Standoff
Left Hand Door - LH
Right Hand Reverse - RHR
Philips Adjustable
Screwdriver Wrench
and
3/16" 9/32" 3/8"
for Either
Nut & Bolt Option
for Wood
Cover
Screw
8501MA
Optional
Architectural
Metal Cover
Standoff
8501A
Optional
Architectural
Plastic Cover
