Summary of Contents for Omega OCI302PPTCOM
- Page 1 Designed to Enhance E S T. � 9 8� Installation + User Manual OCI302PPTCOM Induction Cooktop 30cm omegaappliances.com.au V1.0 0824...
- Page 2 User Manual OCI302PPTCOM Contents Welcome Safety Information Installation Instructions �2 Technical Specifications Control Panel Operating Your Cooktop Cooking Guidelines Care & Maintenance Troubleshooting Purchase Details Your Receipt Warranty Information...
- Page 3 It is important that you read through the following user manual thoroughly, in order to familiarise yourself with the installation and operation requirements of your appliance, and to ensure optimum performance. Again, thank you for choosing an Omega appliance and we look forward to being of service to you. Kind Regards,...
- Page 4 Important Safety Instructions Before Using Your Appliance Read Carefully and Keep for Future Reference This manual explains the proper use of your new Omega Induction Cooktop. Please read this manual carefully before Read this manual thoroughly before first use, even if you using the product.
- Page 5 User Manual Safety Information Health Hazard Electrical Connection WARNING: Follow these instructions carefully to avoid potential WARNING: Risk of fire and electrical shock! injury or death. It is important to use your cooktop safely. Follow these instructions carefully to avoid potential electric shock, fire •...
- Page 6 User Manual OCI302PPTCOM Safety Information Before Installation Appliance Use • To avoid a hazard, this appliance must be installed according • The appliance and its accessible parts become hot when to the instructions in this user manual for installation. in use.
- Page 7 User Manual Safety Information Care & Cleaning • Handles of saucepans may be hot to touch. Check saucepan handles do not overhang other cooking zones that are on. Keep handles out of reach of children. Failure to follow this CAUTION: Risk of injury or damage to the cooktop. advice could result in burns and scalds.
- Page 8 User Manual OCI302PPTCOM Safety Information Installation Instructions Disposal of the Appliance Important Safety Instructions • Disconnect the appliance from the mains supply. • IMPORTANT: If your appliance doesn't include a 10 amp power plug. It must be installed by an authorised technician •...
- Page 9 • Ensure that there is adequate flow of air from outside the Model Width (W) Depth (D) cabinetry to the base of the cooktop. • The isolating switch is easily accessible by the customer. OCI302PPTCOM 268mm 500mm • Do not use any kind of silicon sealant to seal the WARNING: appliance against the benchtop.
- Page 10 User Manual OCI302PPTCOM Installation Instructions Ensuring Adequate Ventilation Applying the Fixing Brackets *NOTE: Please refer to your rangehood’s user manual for the The unit should be placed on a stable, smooth surface (such exact minimum clearances from the top of the cooktop surface as the packaging).
- Page 11 User Manual Installation Instructions Electrical Connection If your cooktop doesn't come with a 10 amp power plug, the power supply should be connected in compliance with the relevant standard, or a single-pole circuit breaker. Please refer to the method of connection shown below relevant to your cooktop model. •...
- Page 12 User Manual OCI302PPTCOM Technical Specifications Specifications Chart: OCI302PPTCOM Model Number OCI302PPTCOM Cooktop Finish Black DiaCeram® Ceramic Glass Controls Touch Controls Power Levels 9 Power Levels + Boost Rated Voltage 220–240V~ Rated Frequency 50 Hz or 60 Hz Installed Electric Power...
- Page 13 User Manual Control Panel A. Power Button D. Power Boost Button G. Start / Pause Button B. Power Level Adjustment Controls E. Child Lock Button C. Timer Adjustment / Selector F. Zone Selector ↑...
- Page 14 User Manual OCI302PPTCOM Operating Your Cooktop Introducing Induction Cooking Verifying Compatibility of Cookware This innovative and efficient cooking method is designed to offer To determine if your cookware is compatible with induction safety, advanced functionality, and cost-effectiveness. cooking, you can perform a magnet test. Simply bring a magnet close to the base of the pan.
- Page 15 User Manual Operating Your Cooktop Choosing the Right Cookware • Do not use cookware with jagged edges, coarse or uneven • The FlexZone can not only use griddle plates, you can surfaces, chipped bottoms or a curved base. also utilise larger cookware specially designed for that specific area.
- Page 16 User Manual OCI302PPTCOM Operating Your Cooktop Getting Started with Cooking 1. Power On Touch the ON/OFF symbol for 3 seconds to activate the cooktop. 2. Preparing the Cooking Surface Place an induction compatible pan or pot on the desired cooking zone. Please ensure both the bottom of the pan and the cooktop's surface are clean and dry for optimal cooking performance.
- Page 17 User Manual Operating Your Cooktop When Finished Cooking 1. Switching Off Individual Cooking Zones Press the cooking zone selection symbol to activate it (the number of the selected zone flashes). Press the power control button to gradually adjust the power to 0. 2.
- Page 18 User Manual OCI302PPTCOM Operating Your Cooktop Utilising the Power Boost Function 1. Selecting the Cooking Zone Press the cooking zone selection button to activate it (the digit of the selected zone flashes). 2. Activating Boost Function Then press and hold the Power Boost button key until the power level display shows “P”, which signals that the selected cooking zone is set to maximum power.
- Page 19 User Manual Operating Your Cooktop Using the Timer Function The Auto-off Safety Feature The Timer function can be used in two ways, either as a minute The cooktop includes a safety feature called auto-off safety. minder (kitchen timer), or as a way to automatically turn off This activates when a cooking zone is left unintentionally on.
- Page 20 User Manual OCI302PPTCOM Operating Your Cooktop Using the FlexZones Using the Start / Pause function • This function allows the FlexZone cooking areas to be used Activating Pause as a single large zone or as two independent zones, adapting to diverse cooking requirements.
- Page 21 User Manual Cooking Guidelines Stir-Frying Steps WARNING: Frying Caution • Choose a induction compatible flat-based wok or a large Be cautious when frying, especially with Boost mode, as oil and fats heat up rapidly. At extremely high temperatures, there's a frying pan.
- Page 22 User Manual OCI302PPTCOM Care & Maintenance Care and Cleaning Guide Marks, Blemishes or Spots Solution Warning Everyday soiling on glass (fingerprints, 1. Switch the power to the cooktop off. • When the power to the cooktop is marks, stains left by food or non-sugary switched off, there will be no ‘hot...
- Page 23 User Manual Troubleshooting For Minor Faults Problem Possible Cause Solution The cooktop cannot be powered on. Ensure the cooker is connected to the power, and is switched on. No power is going to the cooktop. Check if there is a power outage in your home or area.
- Page 24 User Manual OCI302PPTCOM Troubleshooting For Minor Faults Problem Possible Cause Solution Pans do not become hot and appears in The induction cooktop cannot detect Use cookware suitable for induction the display. the pan because it may not suitable for cooking. See the section ‘Choosing the induction cooking.
- Page 25 User Manual Troubleshooting Cooktop Fault Codes & Solutions Fault Code Possible Cause Solution Ceramic temperature sensor failure board - disconnected circuit Check the connection or replace the ceramic Ceramic plate temperature sensor failure - short circuit plate temperature sensor Ceramic plate temperature sensor failure Wait for the temperature of the ceramic plate to Sensor with high temperature ceramic plate return to normal.
- Page 26 User Manual OCI302PPTCOM Purchase Details For future reference, please record the following information which can be found on the rating plate and the date of purchase which can be found on your sales invoice. Store Details Store Name Address Telephone...
- Page 27 User Manual Attach your receipt to this page...
- Page 28 User Manual OCI302PPTCOM Warranty Information WARRANTY TERMS AND CONDITIONS In this warranty INDUCTION COOkTOPS ‘acceptable quality’ as referred to in clause 10 of this warranty has the same meaning referred to in the ACL; This document sets out the terms and conditions of the product ‘...
- Page 29 User Manual Warranty Information You will bear the cost of transportation, travel and delivery of For Appliances and services provided by Residentia the Appliance to and from Residentia Group or its ASR. If you Group in Australia, the Appliances come with a guarantee reside outside of the service area, you will bear the cost of: by Residentia Group that cannot be excluded under the travel of an authorised representative;...
- Page 30 User Manual OCI302PPTCOM Notes...
- Page 31 User Manual Notes...
- Page 32 E S T . 1 9 8 1 Designed to Enhance...
