Installing■and■Balancing
1. Expand the ZHIYUN CINEPEER CQ5 following the figures below.
①
When using, please refer to the figures and pay attention to the rotation
direction of the three axes to avoid damaging the structural limits.
2. Install the smartphone to the phone clamp. Please refer to the figures below
to avoid blocking the cameras. Adjust the position of the phone clamp up or
down so that the phone can remain vertical when stationary.
①
②
① When mounting the smartphone, please make sure that the entire
smartphone is fixed in the phone clamp firmly.
② ZHIYUN CINEPEER CQ5 should have a smartphone mounted on and
balanced before powering on. If no smartphone are detected when
powering on the gimbal, the motor will make a sound and enter standby
mode automatically.
Mounting the Smartphone
②
③
③
4
