Summary of Contents for Zhiyun CINEPEER CX50RGB
- Page 1 The following features are available in this PDF document. Quick Keyword Search Enter the keyword in the search box and hit the search button Quick Jump between Chapters Click the title of a specific chapter on the Contents to jump to it *Reading software such as Adobe Reader is needed to support the functions above.
- Page 2 ZHIYUN CINEPEER CX50RGB COB Light User Guide...
- Page 3 Contents Brief■Introduction ■ Brief■Introduction■ ··················· 1 Product■List ■ Product■List■ ······················ 3 Get■to■Know■ZHIYUN■CINEPEER■CX50RGB■COB■Light■ ■ (hereinafter■referred■to■as■“the■light” ) Get■to■Know■ZHIYUN■CINEPEER■CX50RGB■COB■Light■ · ···· 4 Battery■and■Charging ■ Battery■and■Charging■·················· 5 Installing■and■Removing■Reflector■ ■ Installing■the■Reflector■ ················· 7 Removing■the■Reflector■ ················· 7 Installing■and■Removing■dome■diffuser■(hereinafter■ ■ referred■to■as■"dome■diffuser"） Installing■dome■diffuser■················· 8 Removing■dome■diffuser■ ················ 8 Installing■the■Tripod ■...
- Page 4 Firmware■Upgrade ■ Contents Product■Specifications ■ Disclaimer■and■Warnings ■ Reading■Tips■ ····················· 19 Safe■Operation■Instructions■ ··············· 19 Warranty■Card ■ Warranty■Period■ ···················· 20 Warranty■Exclusions■ ·················· 20 Warranty■Claim■Procedure■················ 20 Contact■Card ■...
- Page 5 WARNING This product is not waterproof. Prevent contact with any kind of liquid with the ZHIYUN CINEPEER CX50RGB. Never use the product in the rain or a humid environment. If water accidentally enters the device when using, please stop using it...
- Page 6 Do not expose this product to an environment above 40℃ . Battery safety precautions: ① It is strictly prohibited to use batteries that are not provided by ZHIYUN. If you need to replace the battery, please contact ZHIYUN or designated agents.
- Page 7 Product List Before using this product, please check carefully that all the following items are included in the product package. In case that any item is found missing, please contact ZHIYUN or your local selling agent. Fill Light x1 Reflector x1...
- Page 8 Get■to■Know■ZHIYUN■CINEPEER■CX50RGB■COB■Light■(hereinafter■referred■to■as■ “the■light” ) Get to Know ZHIYUN CINEPEER CX50RGB COB Light Power Button Built-in Battery Adjust Knob Cooling Vent Display Screen Fan Guard Mode Knob Accessory Mount Chip USB-C Port Cooling Vent 1/4''Screw Hole DC Power Supply Port...
- Page 9 Battery■and■Charging Battery and Charging This product features a built-in battery. Before first use, please fully charge the light to activate the battery. To ensure smooth operation of the product, please use the following methods for charging: ① Power via USB adapter: Use the provided USB Type-C charging cable to connect the USB adapter (not provided) and the USB-C power supply port of the light.
- Page 10 Battery■and■Charging ② Power via DC power adapter: Connect the DC power adapter to the DC power supply port and an AC socket to power ZHIYUN CINEPEER CX50RGB. AC Power （100-240V） It is recommended to use a 24V/2.7A DC power adapter to charge the light.
- Page 11 Installing the Reflector Align the reflector mount with the ZHIYUN CINEPEER CX50RGB accessory mount. Install the reflector to the ZHIYUN CINEPEER CX50RGB and rotate the reflector as shown in the image until you hear a click sound. The reflector is then installed.
- Page 12 Installing and Removing dome diffuser (hereinafter referred to as "dome diffuser"） Installing dome diffuser Install the reflector to ZHIYUN CINEPEER CX50RGB. Expand the dome diffuser as shown in the image, and align the opening of the dome diffuser with the reflector.
- Page 13 Installing the Tripod Installing the Tripod Align the 1/4" screw of the tripod with the 1/4" threaded hole at the bottom of the ZHIYUN CINEPEER CX50RGB. Drive the screw firmly to finish the installation. Tripod is not provided.
- Page 14 Using■with■a■Light■Stand Using with a Light Stand Align the 1/4''screw hole at the bottom of the light with the 1/4''screw at the top of the light stand, then mount the light body onto the stand. ② ① Light stand is not provided in the product package.
- Page 15 How■to■Use■ZHIYUN■CINEPEER■CX50RGB DO NOT stare at the chips when the device is operating. The IP rating of the outer case is IP20. Buttons and Knobs Long press the power button+turn the Adjust knob/ Mode knob: Power on (powered by battery) Long press the power button: Power on (powered by...
- Page 16 How to Use ZHIYUN CINEPEER CX50RGB Operation Instruction 1. CCT Mode Settings Single press Mode Knob to switch to CCT mode. Single press or turn the Adjust Knob to adjust brightness. Turn the Mode Knob to adjust color temperature. Dimming range: 0-100% Color temperature adjustment range: 2700K-6500K.
- Page 17 How to Use ZHIYUN CINEPEER CX50RGB 3. RGB Mode Settings Single press Mode knob to switch to RGB mode. Turn the Mode knob to switch to RGB options. Single press or turn the Adjust knob to adjust the value. RGB adjustment range: 0-100% Dimming range: 0-100% ���%...
- Page 18 How to Use ZHIYUN CINEPEER CX50RGB 5. Menu Settings Single press Mode knob to switch to Menu. Turn the Mode knob to switch to language/Bluetooth reset, Turn the Adjust knob to adjust the chosen option. Finally, press the Adjust knob once to confirm.
- Page 19 Firmware■Upgrade You can use “Zhiyun Led Tools” or “ZY Vega” to perform the ZHIYUN CINEPEER CX50RGB firmware upgrade. Method 1: 1. Visit the official website of ZHIYUN (www.zhiyun-tech.com), go to the CX50RGB product page, click "Download", find the Zhiyun Led Tools and the firmware and download.
- Page 20 Firmware■Upgrade Method 2: The firmware of the CX50RGB can be upgraded using the "ZY Vega" app. For more detailed instructions, please visit the ZHIYUN official website at www.zhiyun-tech.com and watch the related video tutorials for the CX50RGB. ① When using Method 1 for the upgrade, please wait until the screen displays that the upgrade is finished, then you can plug out the USB Type-C cable.
- Page 21 Product■Specifications Product Model： PLX109 Input Power Battery Capacity 4500mAh/66.6Wh Dimming Range 0-100% Color Temperature 2700K-6500K Range 0° -360° CRI ≈ 95 CRI/TLCI TLCI ≈ 96 Illuminance (maximum power, 1130(lux) Lab Data1 without reflector) Illuminance (maximum power, 4140(lux) Lab Data2 with reflector) R Illuminance 178(lux) G Illuminance...
- Page 22 Product■Specifications Operation Temperature -10℃ -40℃ Charging Ambient 0℃ -40℃ Temperature Light Fixture/Bluetooth- Control Methods Connected APP Cooling Method Active Cooling Product Size (without 152.6*57.1*94mm W*D*H reflector) Product Net Weight (without standard 597g reflector) Lab Data 1: The data is collected in the following conditions: No reflectors, 25℃ temperature, indoor illuminance lower than 0.1lux, test distance 1m, and the color temperature is set at 4300K with 100% brightness.
- Page 23 Guilin Zhishen Information Technology Co., Ltd (hereinafter referred to as "ZHIYUN") reserves all rights for final explanation of this instruction and other documents related to this product. The information is subject to update without notice.
- Page 24 1. Customers are entitled to replacement or free repair service in case of quality deficits found in the product within 15 days upon receipt of the product. 2. Customers are entitled to free repair service from ZHIYUN for any product proven defective in material or workmanship that results in product failure during normal consumer usage and conditions within the valid warranty period, which is 12 months counting from the date of selling.
- Page 25 Warranty■Card Customer Information Customer Name: Phone Number: Address: Sales Information Sales date: Product Serial Number: Distributor Name: Distributor’ s Contact Number: First Maintenance Record Service Date: Repairman Signature: Cause of Problem: Service Result: □ Solved □ Unsolved □ Refunded/Replaced...
- Page 26 Contact Card Website Weibo Vimeo Google+ Facebook Facebook (Zhiyun Support) (Zhiyun Tech) Youku Youtube WeChat Instagram...
- Page 27 E-mail: info@zhiyun-tech.com Address: 09 Huangtong Road, Tieshan Industrial Zone, Qixing District, Guilin, 541004, Guangxi, China For full product information, please visit ZHIYUN's official website: Content on www.zhiyun-tech.com is subject to update without notice. ZHIYUN ™ is a trademark of ZHISHEN All product names or brands referred to hereunder may be trademarks or registered trademarks of their respective holders.
- Page 28 Contact Card FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
