How■to■Use■ZHIYUN■CINEPEER■CQ5■
Motors circled in red are free to move in line with the movement of the gimbal
handle while motors circled in grey are locked.
Pan Follow Mode (PF)
The tilt and roll axis motors are
locked and the pan axis follows the
movement of the gimbal handle.
Push the joystick up/down and left/
right to control the tilt axis and pan
axis.
Lock Mode (L)
The three motors are all locked and
won't follow the movement of the
gimbal handle. Push the joystick up/
down and left/right to control the tilt
axis and pan axis.
Gimbal Mode Description
Tilt Axis
Tilt Axis
Roll Axis
Pan Axis
Roll Axis
Pan Axis
16
