- Page 1 4K WiFi PTZ Camera USER MANUAL...
- Page 3 FCC NOTICE (Class A) This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifi- cations or changes to this equipment.
- Page 4 USER MANUAL TABLE OF CONTENTS Safety Precautions What’s in the Box Product Connections About the Product Product Description Technical Specifications Wireless Function Remote Control Setup Guide Installation Connections and Configuration Web Configuration Panel Network Setup AI Tracking from BirdUI OSD Menu Overview Camera Dimensions Troubleshooting Warranty...
- Page 5 USER MANUAL SAFETY PRECAUTIONS WHAT’S IN THE BOX • During the installation and operation, all electrical safety regulations of the country 1x PTZ Camera and region of use must be strictly observed. • Please use the power adapter that comes standard with this product.
- Page 6 4K UHD Wireless Transmission X4 Ultra utilizes the latest generation X4 Ultra includes a WiFi 6 2x2 MIMO Trans- High-Quality 1/1.8 UHD CMOS sensor deliver- mitter capable of robust and long range ing 4K UHD images (3840x2160), it is also wireless connectivity.
- Page 7 USER MANUAL PRODUCT DESCRIPTION 12 13 Name Name Lens Antenna Connectors Power & Standby indicator Reset Key Display (e-ink) Power Key (long press ON/OFF) LAN / PoE + Audio Out (3.5mm) USB-C Audio In (3.5mm) 3G-SDI Connector DC 12V HDMI Tally Light RS 232 Rear Tally Light - Silicon Number...
- Page 8 USER MANUAL TECHNICAL SPECIFICATIONS...
- Page 9 USER MANUAL WIRELESS FUNCTIONS (The WiFi 6 Receiver box is an optional accessory) The camera can be automatically paired with the receiver box. There are two methods to connect the receiver box to your local network. Connected by Network Cable Connected by Switch/Router...
- Page 10 USER MANUAL REMOTE CONTROL KEY DESCRIPTION Standby/Power On Key Press to toggle Power status (ON/Standby). 2. Number Keys Set and recall presets. 3. * Key Use in combination with other keys. 4. PRESET Key Set preset: press [PRESET] + Number key (0-9). 5.
- Page 11 2160p30 birddog-n4m3 192.168.100.104 192.168.100.104 2160p30 birddog-n4m3 Step 4: For more settings, please visit the BirdUI Web configuration page. BirdDog PTZ Device Mode: Encode X4 Ultra Source Status: Streaming NDI Not Connected Ethernet Status: System Wi-Fi Network Wi-Fi Status: Connected Utilization BD-Office 2.4GHz...
- Page 12 USER MANUAL INSTALLATION Wall Mount Ceiling Mount...
- Page 13 USER MANUAL CONNECTIONS & CONFIGURATION BASIC CONNECTIONS BASIC CONFIGURATION Power First off, you’ll have to decide on how you are NDI® Tools going to power the camera. You have three NDI® Tools is a free suite of applications choices. You can use PoE+ (Power over Ether- designed to introduce you to the world of IP net) or, if your network doesn’t support PoE+, video and is available at:...
- Page 14 USER MANUAL 5.1 Using RS-232 (VISCA) HDMI Video Signal You can use the RS-232 port to connect to SDI Video Signal optional controllers, such as a joystick key- board controller, or PC control software, to operate the camera, perform pan, tilt and zoom operations, and to recall Preset positions using the control buttons.
- Page 15 WEB CONFIGURATION PANEL BirdDog.tv RESTART REBOOT BirdDog cameras have a web interface (also 2. In the displayed window, type the default known as BirdUI) that is displayed by your password ‘birddog’ (all lower case) and click computer browser and can be used to the OK button.
- Page 16 DHCP Timeout, Fallback IP address, Fallback Subnet Mask You can set the timeout period during which the X4 Ultra will look for a DHCP IP address. After this period, the camera will default to the designated fallback IP address.
- Page 17 USER MANUAL 7.2 Wi-Fi Network Configuration BirdDog PTZ Device Mode: Encode Source Status: Streaming NDI X4 Ultra Wi-Fi Network Ethernet Network Wi-Fi Configuration Method STATIC DHCP SSID: IP Address 192.168.100.5 Custom Subnet Mask 255.255.255.0 BirdDog Office 2.4GHz Gateway Address 192.168.100.1...
- Page 18 Time to return to the starting point after losing the target. BirdDog.tv X4 Ultra AI Tracking User Guide 2. Go to CamControl > AI Tracking and select Presenter Mode. The X4 Ultra camera offers two AI tracking modes: Presenter (human-detection) tracking • Options: and Zone tracking. You can switch between 1.
- Page 19 USER MANUAL • Additional Settings: ◦ Target Retention Time: Time the camera waits before returning to the home position after losing the target (default: 6 seconds, up to 15 seconds). ◦ Auto Zoom: Adjusts zoom automatical- ly if enabled. ◦ Auto Tilt: Moves the camera vertically when enabled.
- Page 20 USER MANUAL AI TRACKING FROM BirdUI (ZoneTracking) BirdDog PTZ Device Mode: Encode X4 Ultra Source Status: Streaming NDI Camera Control AI Tracking Preset Exposure White Balance Picture Colour Matrix Advanced AI Tracking PTZ Control Zoom Dashboard Mode PRESENTER ZONE TELE...
- Page 21 USER MANUAL OSD MENU OVERVIEW Exposure settings control how much light the MENU camera captures, directly affecting the image’s brightness, contrast, and detail visibili- Exposure ty in both well-lit and low-light environments. Color • Mode (Auto/Manual/SAE/AAE/Bright): Image Determines how exposure is adjusted P/T/Z based on the scene.
- Page 22 USER MANUAL determines how the camera mea- higher values increase noise. sures the light across the frame. ▪ DRC (1 to 8): Manually adjusts ▪ Average: Measures overall light dynamic range for balanced con- across the frame; good for trast in high-contrast scenes. evenly lit scenes.
- Page 23 USER MANUAL 2. COLOR ▪ Color Temp (2500K to 8000K): COLOR Adjusts to warm (lower values) or cool (higher values) lighting. Use WB Mode Auto lower values for warm light sources RG Tuning and higher for daylight or blue-tint- BG Tuning ed light.
- Page 24 USER MANUAL • between the darkest and brightest parts of 4. P/T/Z (Pan, Tilt, Zoom) the image. Use higher values for dramatic effects, lower values for flatter images. P/T/Z • Sharpness (0 to 11): Defines the edge SpeedByZoom clarity of objects in the frame. High values AF-Zone Front enhance detail but may introduce noise.
- Page 25 USER MANUAL • Digital Zoom (Off/2x/4x/8x/16x): Allows General system settings and video output digital zooming up to 16x, but may reduce configurations. image quality at higher levels. • Language (e.g., EN): Sets the interface • Call Preset Speed (1 to 24): Sets the speed language.
- Page 26 USER MANUAL Configures remote control protocols and 7. TRACKING CONFIG network settings. Note that the camera will always respond to VISCA-IP and NDI proto- TRACKING CONFIG cols. Tracking • Protocol (VISCA/PELCO-D/PELCO-P/Au- Tracking Mode Presenter to): Sets the communication protocol used Figure Size Full for camera control.
- Page 27 USER MANUAL CAMERA DIMENSIONS Ø 140 5-M3 Ø 5.1 1/4”-20UNC...
- Page 28 The default IP address is: 192.168.100.100; • The monitor shows no image The default password is: ‘birddog’. 1. Ensure that the camera power supply is connected, the voltage is normal, and the If you forget the camera IP address or power indicator is always on.
- Page 29 WARRANTY 5 Year Warranty BirdDog P-series and X-series cameras fea- ture a 5 year, global warranty. BirdDog prides itself on delivering the best possible products to customers, but if something was to go wrong, you can rest assured knowing that no matter where in the world you are, BirdDog has your back.
