- Page 1 EYES P200 FULL NDI. NO COMPROMISES. USER MANUAL PART 1...
-
Page 2: Table Of Contents
Contents IMPORTANT INFORMATION ................................4 WHAT’S IN THE BOX ..................................5 Overview ......................................5 Features ......................................5 Camera Diagrams ....................................6 Remote Controller ....................................7 System Configuration ..................................8 Obtain Video Signal ...................................8 Audio IN / OUT ....................................9 Camera Control Methods and System Configurations ........................9 Use the Infrared Remote Controller ..............................9 Use RS-232 (VISCA) ....................................9 Use RS-422(VISCA) / RS485 (PELCO P/D) ............................ - Page 3 Before operating the unit, please read this manual thoroughly and retain it for future reference. Copyright Copyright 2019 BirdDog Australia all rights reserved. No part of this manual may be copied, reproduced, translated, or distrib- uted in any form or by any means without prior consent in writing from our company.
-
Page 4: Important Information
IMPORTANT INFORMATION • Do not aim the camera lens at the strong light such as sun or incandescent lamp. The strong light can cause fatal Legal Notice damage to the camera. Attention: Maintenance Precautions: To ensure account security, please change the password af- ter your first login. -
Page 5: What's In The Box
This user guide is suitable for the following models: Note: The camera color may be in white or black per the item that is purchased. BirdDog Eyes P200 1x BirdDog Eyes P200 Features • Resolution: Up to 1080P60, 1080i59.94 1x IR Remote Controller • NDI... -
Page 6: Camera Diagrams
Camera Diagrams IR Selec t Audio OUT Video Forma t Audio IN CVBS RS232 HDMI DC 12V 3G-SDI RS422 12V DC Power Port HDMI Port (HDMI 1.4) Connect the supplied DC power adaptor and cord. 10. CVBS Video Output USB 2.0 Port For firmware upgrade only 11. -
Page 7: Remote Controller
Remote Controller Power MENU POWER • Power ON the camera to turn the camera in operation status. • Power OFF the camera to turn the camera in standby CAMERA SELECT status. • When the camera is powered OFF, the camera turns to the back and would be on standby mode. -
Page 8: System Configuration
System Configuration Connection Power When the camera is connected to a computer and joystick • Use only the DC power adaptor (JEITA type4) supplied keyboard with a VISCA cable (cross type, RS-232), you can with the unit. Do not use any other DC power adaptor. operate the camera with the computer and the joystick key- board. -
Page 9: Audio In / Out
Camera Control Methods and Camera Initial setting status Information Information of the camera initial setting status will display for System Configurations 5 seconds. Camera PELCO ID for RS-485 control This unit has multiple ways of controlling the camera and various system configuration capabilities using optional Camera ID for IR Remote Controller products. - Page 10 RS232 Connection 10. Use extension cables included RJ45 to RS422/232 Phoe- Set RS232 control method on Bottom Dip Switch. nix terminal contact adaptor to make RS232 connection for your control device. Set Baud Rate on Bottom Dip Switch to the same as Baud Rate setting on the keyboard you are using.
-
Page 11: Use Rs422(Visca) / Rs485 (Pelco P/D)
Use RS422(VISCA) / RS485 (PELCO P/D) How to make RS422 connection and RS422 Daisy Chain multiple cameras connection with SONY controller as You can use RS422/485 port connect to optional controllers, below: such as joystick control keyboard, control PC station, to op- erate the camera. -
Page 12: Pelco P/D Keyboard Rs485 Connection
PELCO P/D Keyboard RS485 Connection 12. Or you can use CAT5/6 T-568B Standard Ethernet cable direct connect between the camera and the controller to make RS422 connection by following the pin definition NOTE: Use RS422 ports for RS485 connection. Only use below: TX+ and TX- for RS485 connection. -
Page 13: Operating Multiple Cameras
Or you can use CAT5/6 T-568B Standard Ethernet cable between the camera and the joystick controller. • direct connect between the camera and the controller to make RS485 connection by following the pin definition You cannot use the RS-232 connections while you are us- •... -
Page 14: Dip Switch Settings
Controlling via VISCA over IP Bit 7~8 RS-232/RS-422 Baud Rate Connect the network port on the camera to the network • switch. VISCA Address Set the IP address and other network information appro- • priately to communicate on your network Connect the VISCA over IP-compatible controller to the •... -
Page 15: Adjusting And Setting With Menus
Adjusting and Setting with Menus NOTE: In some product models, only use “←” button on the infrared remote controller to change the value. To confirm About On-Screen Menus the value, you can use either “→” button or HOME button. You can change various settings, such as shooting conditions Control Button and system setup of the camera, while observing menus dis- played on a connected computer screen. -
Page 16: White Balance Menu
EXPOSURE MENU: IRIS PRI available only when the AE mode is set to “Full Auto.” The initial setting is “Auto Slow Shutter Off.” EXPOSURE MODE IRIS PRI WHITE BALANCE IRIS F1.6 S. SHUTTER LIMIT: When the subject becomes dark, the PICTURE 1 GAIN LIMIT 21.4dB... -
Page 17: Picture1 Menu
PICTURE1 Menu Push Trigger), assuming that a white subject, in correct light- ing conditions, and occupying more than 1/2 of the image, is submitted to the camera. One Push White Balance data is PICTURE 1 MENU lost when the power is turned off. If the power is turned off, EXPOSURE SHARPNESS reset One Push White Balance. -
Page 18: Picture2 Menu
PICTURE2 Menu PAN TILT ZOOM Menu PICTURE 2 MENU PAN TILT ZOOM MENU EXPOSURE DIGITAL ZOOM EXPOSURE CHROMA WHITE BALANCE ZOOM RATIO OSD WHITE BALANCE HLC MODE PICTURE 1 BACKLIGHT COM. PICTURE 1 AF SEN PICTURE 2 MF SPEED PICTURE 2 STABILIZER PAN TILT ZOOM NEAR LIMIT... -
Page 19: System Menu
SYSTEM Menu The video formats that you can select from are: 10 8 0 P : 6 0/ 59.94 / 5 0/ 3 0/ 2 9.9 7/ 2 5,10 8 0 I : 6 0/ 59.94 / 5 0, SYSTEM MENU 720P:60/59.94/50/30/25 EXPOSURE PELCO ID... -
Page 20: Operating Multiple Cameras With The Infrared Remote Controller
Operating Multiple Cameras with you change the direction of the camera while checking the picture on the screen. In such a case, press the 2 (REV) button the Infrared Remote Controller while holding down the L/R DIRECTION SET button. Arrow Button Movement of the Camera Setting MENU... -
Page 21: Storing The Camera Settings In Memory - The Presetting Feature
Storing the Camera Settings in Recalling the stored settings: Press any of the POSITION buttons, 1] to [6], in which you have stored the settings. Memory — the Presetting Feature CAMERA SELECT Memory (Preset) Using the preset function, 6 sets of camera shooting condi- Press a POSITION button tions can be stored and recalled. -
Page 22: Dimensions
Dimensions Unit: mm 139.8 178.75 94.9... - Page 24 WELCOME TO THE FUTURE. bird-dog.tv hello@bi rd-dog.tv...
