Maxon Enduro SM-6000 Series Programming Manual

Hide thumbs Also See for Enduro SM-6000 Series:

Advertisement

Quick Links

Download this manual
PROGRAMMING
MANUAL
For the
SM-6000 Enduro
Series Radios
TecNet International Inc. , 11535 West 83rd Terrace, Lenexa, KS, 66214 - Phone: 913-859-9515 - Fax: 913-859-9550
Part Number: 680-110-0025
August 2002
Rev C

Advertisement

loading
Need help?

Need help?

Do you have a question about the Enduro SM-6000 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Maxon Enduro SM-6000 Series

Summary of Contents for Maxon Enduro SM-6000 Series

  • Page 1 PROGRAMMING MANUAL For the SM-6000 Enduro Series Radios TecNet International Inc. , 11535 West 83rd Terrace, Lenexa, KS, 66214 - Phone: 913-859-9515 - Fax: 913-859-9550 Part Number: 680-110-0025 August 2002 Rev C...
  • Page 2 ACC-961 PROGRAMMING MANUAL This manual is intended for use by qualified technicians and includes information pertaining to the ACC-961 Pro- gramming Software and the SM-6000 Enduro Series operation.
  • Page 3 COPYRIGHT© 2001 First Edition, October 2001 All Rights Reserved. No part of this book may be reproduced, stored in a retrieval system, or transmitted by any form or by any means, electronically, mechanically, photocopying, recording, or otherwise, except as may be expressly permitted by the applicable copyright statues or in writing.
  • Page 4 ACC-961 Personality Programmer TABLE OF CONTENTS INTRODUCTION ............1 System Requirements .
  • Page 5 ACC-961 Personality Programmer LIST OF FIGURES Figure 1. 25-pin to 25-pin RS-232 Serial Communications Cable....2 Figure 2. 25-pin to 9-pin RS-232 Serial Communications Cable....2 Figure 3.
  • Page 6 INTRODUCTION The ACC-961 programming software is used in conjunction with the ACC-2006 Interface Module and enables the parameters of Maxon’s SM-6000 radio to be read, modified, programmed and printed. The ACC-961 Software Assembly contains the following items: 1 disk which includes programming software and setup program...
  • Page 7 ACC-961 Personality Programmer HARDWARE INSTALLATION Installing The Hardware Installing the ACC-2006 Make sure that your computer is turned off. Locate the serial communications port on the computer. This port will usually be located at the rear of the com- puter. However, since this is dependent upon the design of your computer refer to the computer operator’s manual for directions.
  • Page 8 ACC-961 Personality Programmer Once located, insert the RS-232 Serial Communications Cable into the appropriate serial port on the computer. Connect the other end of the cable to the DB-25 connector on the ACC-2006 Interface Module. (Refer to “Figure 6. Computer Input Side” on page 4). Connecting the SM-6000 Connect the SM-6000 Programming Cable to the radio and insert the other end of the cable into the jack labeled “Mobile”, located on the ACC-2006 Interface Module.
  • Page 9 ACC-961 Personality Programmer SPKR - SPKR + Figure 5. Side View Outputs for testing include TX Audio, RX High & RX Low Figure 6. Computer Input Side DB-25 connector for connecting to computer MOBILE EXT. SPKR PORTABLE Figure 7. Radio Hookup Side Connections for mobile and portable connections.
  • Page 10 3. Close the information box by either pressing return or clicking on the “OK” button. 4. The program will automatically install the ACC-961 program in the following directory: C:\Program Files\Maxon\ACC-961 Radio Programmer Uninstalling The Software If you have already installed a previous version of the ACC-961, you must uninstall the previous version before installing any new versions.
  • Page 11 ACC-961 Personality Programmer GETTING STARTED Starting The ACC-961 In order to use this program, you must be familiar with standard Windows® 95 procedures. Before starting the program, ensure that the “Mobile” and “PGM Mobile” silver buttons on top of the ACC-2006 Interface Module are in the DOWN position and the “Mobile PTT”...
  • Page 12 ACC-961 Personality Programmer Reading a Personality • Note: When reading or writing to the radio, the display may go blank on the radio. This is normal since the computer now has control of the radio. 1. Connect radio and programmer. (See “HARDWARE INSTALLATION” on page 2.) 2.
  • Page 13 ACC-961 Personality Programmer CREATING A PERSONALITY New Personality 1. Creating a personality starts by pressing the New Personality Button (Refer to “New Personality: Creates a new personality.” on page 11) or by selecting New Personality from the Personality Options menu(Refer to “New Personality: Creates new personality.
  • Page 14 ACC-961 Personality Programmer Creating a New System The ACC-961 personality programmer supports creating up to 200 conventional and LTR systems. 1. To add a new system to the personality, click on the NEW CONV SYSTEM (See “New Conventional System: Creates a new conventional system.” on page 11) or the NEW LTR SYSTEM (See “New LTR System: Creates a new trunked system.”...
  • Page 15 ACC-961 Personality Programmer MENU BAR Figure 10: Menu Bar The menu bar is provided to allow easy navigation from anywhere within the program. The menu bar consists of pull down menus that allow the user to go directly from one function to another. Options can be selected by using the Alt- key combinations listed.
  • Page 16 ACC-961 Personality Programmer ICON BAR Figure 11: Icon Bar The Icon Bar allows easy access to the most used functions of the Personality Programmer. New Personality: Creates a new personality. • Note: this will overwrite the current personality, if one is loaded. Save Personality: Saves current personality.
  • Page 17 ACC-961 Personality Programmer TAB DESCRIPTIONS Radio Wide Parameters that affect the entire radio will be found in the Radio Wide Tab. Volume Settings Volume settings allow you to provide a specified operating range for volume levels for your customers. The volume settings for both alerts and voice range from 0 to 15.
  • Page 18 ACC-961 Personality Programmer Conventional Scan Type Used only in Conventional operation. This will determine what channels will be scanned and whether the radio will be able to transmit back to a calling station. Talk Back Scan: Talk Back Scan will scan for carrier on every channel in the dealer programmable scan list.
  • Page 19 ACC-961 Personality Programmer Various Timers TX Time-out Time (sec.)/TX Inhibit Time (sec.): (TX Time-out Timer Default 65s, TX Inhibit Default 5s)TX Inhibit Time and TX Time-out time work together. TX Time-out time controls how long the user may continuously transmit the radio before the radio automatically disengages the RF power amp. If dealer programmed, the radio will issue a beep 5 seconds before it will automatically shut off the RF PA.
  • Page 20 ACC-961 Personality Programmer Call Missed: Call Missed simply logs all valid calls the radio user misses. The call missed feature can be used to log both non-scan and scanned calls and functions independent of system selection. Missed con- ventional squelch calls will not be cataloged. Only CTCSS, DCS, TT calls will be cataloged. The call missed feature will log up to eight missed calls.
  • Page 21 ACC-961 Personality Programmer DCS: This receive and transmit squelch option uses sub-audible digitally coded numbers. During receive operation, not only is sufficient signal strength required to unmute the radio, but the pro- grammed DCS code must be present as well. This allows for many people to use a system without intruding on one another.
  • Page 22 ACC-961 Personality Programmer LTR System Tab System Features Auto Group Scan: This LTR scan feature is identical to manual group scan. The only difference is that the SCAN button need not be pressed in order to activate the feature. The user simply selects any group in the system and the radio will immediately begin scanning the repeater for the selected group's ID and those ID's in the system's scan list.
  • Page 23 ACC-961 Personality Programmer Repeaters Tab In the repeater setup page you may enter receive and transmit frequencies for each repeater in your system. Note that each RX/TX pair is associated with a repeater number. Each repeater field also supports channel spacing and power level settings.
  • Page 24 ACC-961 Personality Programmer REPEATER OPERATION A combination of two SM-6000 series radios can be used to form a conventional repeater. One radio will be the receiving radio and one will be the transmitting radio. Special programming is required for these radios to interact as a repeater.
  • Page 25 ACC-961 Personality Programmer The next screen will be the Repeater Setup Screen as shown below. Figure 13: Repeater Setup Screen Receiver Repeater Setup 1. Click on Receiver 2. Enter the receiving frequency of the repeater. 3. Set the Channel Spacing (S) for standard (25KHz) channel spacing and (N) for narrow (12.5KHz) channel spacing.
  • Page 26 ACC-961 Personality Programmer Transmitting Repeater Setup 1. Click on Transmitter. The following screen will be displayed: Figure 14: Transmitter Repeater Setup 2. Enter the Transmitting Frequency. 3. Select the Transmit Power. (L) low power, (H) high power. 4. Select the type of signaling to be used. (Default will be the same as used in the receiver setup.) 5.
  • Page 27 ACC-961 Personality Programmer INDEX Priority Group, System, 14 Hub Disable, 13 Two Tone, 16 TX, 16 ACC-2006, 2 Channel Spacing, 16 Icon Bar, 11 Alerts, 13 Data Only, 16 Ignition Enable, 13 Beeps, 13 Freq, 16 In Scan List, 18 Button Key Chirps, 13 Power Setting, 16 In System Scan List, 15, 17...
  • Page 28 ACC-961 Personality Programmer System IDs, 17 Write to Radio, 10 RX Block High ID, 17 New Personality, 10, 11 Priority ID, 17 RX Block Low ID, 17 Talk Around ID, 17 Opening a Personality, 6 System Requirements, 1 System Scan, 12 System Scan Speed, 17 Personality Options, 10 Polarity, 12...
