Teradek User Manual
Prism Flex Mk II Quick Start Guide (2024)
With a flexible I/O and compact, low-SWaP design, Prism Flex Mk II easily fits into any workflow.
Prism Flex Mk II is perfect for placement on a table top, camera-top, or wedged between your video
switcher and audio mixer. Prism Flex Mk II can encode or decode up to 4Kp60 video with stunning
10-bit 4:2:2 image fidelity. The Prism platform supports many common streaming protocols such
as TRT, SRT, MPEG-TS, RTSP/ RTP, and RTMP(S), and can be connected to Teradek's Core Cloud
platform for even more flexibility.
Prism Flex Mk II Quick Start Guide (2024)
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Prism Flex Mk II and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Teradek Prism Flex Mk II

  • Page 1 With a flexible I/O and compact, low-SWaP design, Prism Flex Mk II easily fits into any workflow. Prism Flex Mk II is perfect for placement on a table top, camera-top, or wedged between your video switcher and audio mixer. Prism Flex Mk II can encode or decode up to 4Kp60 video with stunning 10-bit 4:2:2 image fidelity.
  • Page 2 Teradek User Manual TABLE OF CONTENTS...
  • Page 3: What's Included

    Prism Flex’s input connector. Decoder: Turn your monitor on, then connect connect the HDMI (I) or SDI output (L) from your Prism Flex to the monitor’s input connector. Prism Flex Mk II Quick Start Guide (2024) Page 3...
  • Page 4 • Bitrate screen: Displays the current bitrate. Press to edit the bitrate settings • Stream mode screen - Go Live/Begin Streaming • Audio Input screen - Displays the current Audio bitrate. Press to switch from Embedded, analog, or Mixed Prism Flex Mk II Quick Start Guide (2024) Page 4...
  • Page 5: Get Online

    4. Select Client as the WiFi Mode. 5. Click the WiFi scan tab, select an available network, then enter the password. Once connected, the display will list the network Prism Flex is connected to. Prism Flex Mk II Quick Start Guide (2024) Page 5...
  • Page 6: Connect Via Ethernet

    Configure Node 5G/Node II 1. Navigate to the Network menu and select the corresponding Node modem. 2. Select the slot with the SIM you will be using (Slot 1 or Slot 2). Prism Flex Mk II Quick Start Guide (2024) Page 6...
  • Page 7 LTE/4G/3G data bands. With dual SIM slots, you can switch from one provider to another without unplugging the Node II. Only one SIM card can be used at a time. 3. Select Teradek Data Priority or Teradek Data Standard (depending on your SIM and plan) from the Configuration drop-down menu.
  • Page 8 Teradek User Manual 4. Set the Teradek Carrier Mode to Auto Carrier. For Carrier Locking mode, click here. 5. Click Save when you're done. ENCODER/DECODER CONFIGURATION Configure your Prism Flex decoder to receive streams from a Prism Flex encoder. Prism Flex Mk II Quick Start Guide (2024)
  • Page 9 6. Open the Ingest menu, then select MPEG-TS as the ingest mode. 7. Enter the protocol, ensuring the selected protocol matches the Encoder’s protocol configuration (see step 3). Confirm the port is set as the default 9710. Prism Flex Mk II Quick Start Guide (2024) Page 9...
  • Page 10 The Prism App allows you to remotely configure all of Prism Flex’s settings while monitoring your stream’s destination, bitrate, bonding status, and resolution to ensure you maintain a stable stream. The Prism App is available for iOS devices. Prism Flex Mk II Quick Start Guide (2024) Page 10...
  • Page 11 Prism Flex encoders support recording to an SD card, USB drive, or NFS. Each recording is saved with the same resolution and bitrate set in Prism Flex. 1. Insert a compatible SD card into the corresponding slot. 2. Enter the Recording menu, and select Enabled. Prism Flex Mk II Quick Start Guide (2024) Page 11...
  • Page 12 With Core, you can: • Bond multiple Internet connections, increasing your broadcast’s bandwidth and reliability. • Remotely control Teradek encoders, decoders, and bonded systems from anywhere in the world. • Stream to multiple destinations. • Sync your recordings.
  • Page 13 Link with Code: Copy the authorization code generated for your Prism, then follow the instructions provided. 3. Once a connection is established, you can configure Prism from either the Prism UI or Core dashboard. Prism Flex Mk II Quick Start Guide (2024) Page 13...
  • Page 14: Other Resources

    Teradek User Manual OTHER RESOURCES • USER GUIDE ARTICLES: https://guide.teradek.com/m/109577 • PRISM REFERENCE GUIDE PDF: https://teradek.com/pages/downloads#prism Prism Flex Mk II Quick Start Guide (2024) Page 14...
