R E V V | G E N E R A T O R 1 0 0 R M K 3
MIDI channel 1 has been selected. Simply continue
to press the CH 1 button to get to the channel you
desire. As you press the button you will notice the
other Channel LEDs and Bright LED turn on as you
increase the MIDI channel number. Once you reach
the channel you desire, press the STORE button to
save it to memory.
Simply continue to press the CH 1 button to get to the
channel you desire. As you press the button you will
notice the other Channel LEDs turn on as you increase
the MIDI channel number. Once you reach the channel
you desire, press the STORE button to save it to
memory.
Note: Only 4 LEDs are used, so the MIDI channel
count will be done in values of 4. MIDI channel 1 will be
signified by CH1 CLEAN LED flashing, & as you increase
in number, MIDI channel 4 will be signified by all three
channel LEDS and the bright LED flashing, but once
MIDI channel 5 is selected, only the CH1 CLEAN LED
will flash again. Every time you reach MIDI channel 5, 9,
or 13, the LED cycle will once again start from the CH1
CLEAN LED. So keep count as you select the channel
you desire. If you go past MIDI channel 16, the count
will start at channel 1 again. Once saved to memory,
the Channel LEDs and bright LED will flash very quickly
several times to verify the change has been made &
completed.
MIDI PROGRAM CHANGE
This amplifier can remember up to 128 program settings
of the MIDI controllable functions. To set a program (i.e.
amplifier configuration) to be controlled via MIDI:
1. Set the amplifier to the configuration you intend to
save to a program number. (Ex: Ch: 3, Aggression
level: 2, Fat: ON, Master Volume: 2, FX Loop: OFF,
etc)
2. Once the amplifier is configured as you would like,
press the store button. The Store LED will flash &
the amplifier will wait now for a command through
its MIDI IN jack.
3. Send a program change command from your MIDI
Pedal or other equipment with the correct channel
& program number you intend to have the amplifier.
save the current configuration to.
4. Once the command is received, the amplifier will
save the current amp configuration to that program
16
number. The Store LED will flash 3 times & turn off
verifying that the command has been received &
saved.
Now, anytime you send that program number to the amplifier
from your MIDI pedal or other external equipment, the amplifier
will switch to that saved configuration. This will allow for any
configuration of your settings to be recalled with any MIDI device.
MIDI CONTROLLABLE FUNCTIONS
The amplifier functions that can be controlled via MIDI
are as follows:
Channel Selection (1-3)
Wide Mode (Ch1
3 Drive Levels (Ch2)
3 Aggression Levels (Channel 3)
Bright function (All Channels)
Cut function (Channel 3)
Fat function (Channel 3)
FX Loop in/out
Master Volume 1 & 2
Reverb
Noise Gate
Pre-Post
40 Mute
Two Notes Embedded Functions
These functions can be set & controlled in a MIDI
program change setting, where one program change
command will call up a configuration of the above
settings, or continuous controller commands, where
a CC command will switch any one of the functions
listed above, independent from any of the others. The
CC command functions are great for things like instant
access buttons on foot pedals etc.
CONTINUOUS CONTROLLER (CC)
To use CC commands, the amplifier Functions have
all been given a designated number & on or off
setting. When using & selecting a function the number
associated with the function must be used & then the
setting of the function (on or off) must also be sent.
Most MIDI equipment (pedals etc) allows you to select
a CC number & then designate whether it be turned to
on or off. (Consult the external equipment instruction
manual).
The following commands & their CC numbers need
only be sent an ON command (0-63) as they are used
to switch between channels & aggression levels which
cannot be turned off, only changed to a different channel
or level, on & off commands sent will produce the same
result.The following 2 commands will switch to the
41
channel & then toggle through the aggression levels
with each use of the command using the footswitch to
switch to the channel & toggle through the aggression
levels. This command will also respond to an on & off
command with the same result:
Function CC Number Hex value)
Ch. 1 13 - (0x0D)
Ch. 1 wide 14 - (0x0E)
Ch. 2 low Drive 15 - (0x0F)
Ch. 2 med Drive 16 - (0x10)
Ch. 2 high Drive 17 - (0x11)
Ch. 3 low aggression 18 - (0x12)
Ch. 3 med aggression 19 - (0x13)
Ch. 3 high aggression 20 - (0x14)
The following command will switch to the channel &
then toggle through the aggression levels with each
use of the command like using the footswitch to
switch to the channel & toggle through the aggression
levels. This command will also respond to an on & off
command with the same result:
Ch. 3+ aggression toggle 24 – (0x18)
42
R E V V | G E N E R A T O R 1 0 0 R M K 3
The following commands control functions that are
turned on & off. These functions require an off (0-63)
& on (64-127) command (byte) to be sent with the CC
number to either turn them on or off.
If you are trying to use them & are not getting them
to respond, chances are you are sending the wrong
command byte ( 0-63 is OFF & 64-127 is ON).
(Consult the Peripheral's instruction manual)
Function CC Number Hex value)
Noise Gate 26 – (0x1A)
Masters 27 – (0x1B)
Fat 28 – (0x1C)
Bright 29 – (0x1D)
Mute 30 – (0x1E)
Reverb 31 – (0x1F)
Pre-Post 33 – (0x21)
Cut 34 – (0x22)
FX Loop 35 – (0x23)
Two Notes Power Amp 36 – (0x24)
Two Notes Reverb 37 – (0x25)
Two Notes Noise Gate 38 – (0x26)
Two Notes Twin Tracker 39 – (0x27)
Two Notes EQ 40 – (0x28)
Two Notes EQ R 41 – (0x29)
Two Notes Mute 42 – (0x2A)
