AX1711
Xtrem skid plate
KTM 250/350 EXCF
What's in the box ?
1 PM01-04-268 - Front fixation 20mm
2 NE01-04-002 - Clamped bolts
2 NE10-01-004 - Alloy spacers
2 NE01-04-003 - EM6F bolts
2 NE01-02-002 - Screws TFHC 6x20mm
2 NE01-10-001 - Screws THF 6x30mm
1 NE04-01-218 - Sticker
The paper instructions may be limitless, a tutorial video is available online
to help you.
The pictures below might show different components but their function is
the same. This does not impact the assembly of the skid plate.
Approximate time of assembly: 5 minutes.
A skid plate is made to protect the vital components of your bike and does not have
a « life warranty ». However, production default may happen and we cover it during
the first year of use.
In case of premature breakage, please write to contact@axpracing.com
Assembling
instructions
Advertisement
Related Manuals for aXp RACING AX1711
Summary of Contents for aXp RACING AX1711
- Page 1 Assembling AX1711 instructions Xtrem skid plate KTM 250/350 EXCF What’s in the box ? 1 PM01-04-268 - Front fixation 20mm 2 NE01-04-002 - Clamped bolts 2 NE10-01-004 - Alloy spacers 2 NE01-04-003 - EM6F bolts 2 NE01-02-002 - Screws TFHC 6x20mm...
