QBiP-2314A

3.5" SBC Boards

www.gigaipc.com

GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

Need help?

Do you have a question about the QBi Pro Series and is the answer not in the manual?

Questions and answers

Summary of Contents for GIGAIPC QBi Pro Series

Page 1 QBiP-2314A 3.5” SBC Boards www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Page 2 GIGAIPC reserves the right to make changes in the product design without notice to its users. www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Page 3 IBM, PC/AT, PS/2, and VGA are trademarks of International Business Machines Corporation. All other product names or trademarks are properties of their respective owners. www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Page 4 Item Quantity QBiP-2314A SATA power cable If any of these items are missing or damaged, please contact your distributor or sales representative immediately. www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Page 5 (if any), to facilitate users in setting up their product. Users may refer to the GIGAIPC.com for the latest version of this document. www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Page 6 11. Place the device on a solid surface during installation to prevent falls 12. Do not cover the openings on the device to ensure optimal heat dissipation. www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Page 7 18. D O N O T L E AV E T H I S D E V I C E I N A N U N C O N T R O L L E D ENVIRONMENT WITH TEMPERATURES BEYOND THE DEVICE’S PERMITTED STORAGE TEMPERATURES (SEE CHAPTER 1) TO PREVENT DAMAGE. www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Page 8 Ne la remplacer qu’avec le même modèle ou équivalent recommandé par le constructeur. Recycler les batteries usées en accord avec les instructions du fabricant et les directives gouvernementales de recyclage. www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Page 9 ○ 及其电子组件外部信号 ○ ○ ○ ○ ○ ○ 连接器及线材 O：表示该有毒有害物质在该部件所有均质材料中的含量均在 SJ/T 11363-2006 标准规定的限量要求以下。 X：表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T 11363-2006 标准规定的限量要求。备注：此产品所标示之环保使用期限，系指在一般正常使用状况下。 www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Page 10 SJ/T 11363-2006-stipulated requirement. Note: The Environment Friendly Use Period as labeled on this product is applicable under normal usage only www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Page 11 2.2.7 SODIMM1, SODIMM2 (DDR4 SO-DIMM slot) ....28 2.2.8 SATAPW (SATA power connector) ........29 2.2.9 SATA (SATA 6Gb/s connector) ........30 www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Page 12 TPM Configuration ............50 3.3.2 Super IO Configuration ............ 51 3.3.3 Hardware Monitor ............52 3.3.4 CPU Configuration ............53 3.3.5 Network Stack Configuration ........... 54 www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Page 13 6C) (MAC address may varied based on different mother- board) ................61 Chipset ................62 Security ................63 Boot .................. 66 Save & Exit ............... 67 www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Page 14 Chapter 1 Chapter1 - Product Specifications QBiP-2314A www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Page 15 GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Page 16 1 x COM header (RS-232/422/485 & RI/5V/12V) 1 x Backlight Control header 1 x AT/ATX mode select jumper 1 x GPIO (8-bits) & SMBus header www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Page 17 OS Compatibility Windows 10/11 (x64) Operating temperature: 0°C to 60°C Operating humidity: 0-90% (non-condensing) Operating Properties Non-operating temperature: -40°C to 85°C Non-operating humidity: 0%-95% (non-condensing) www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Page 18 Chapter 2 Chapter 2 – Hardware Information www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Page 19 Jumpers and Connectors www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Page 20 AT/ATX mode select jumper Serial port header COM1, COM2, COM1 : RS-232/422/485 & RI/5V/12V COM3, COM4 COM2 : RS-232/422/485 COM3, COM4 : RS-232 MPCIE Mini PCIE slot www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Page 21 RI pin RI/5V/12V Select jumper for COM1 port BATTERY Battery cable connector CPU_FAN CPU fan connector SYS_FAN System fan connector Embedded Display Port Connector www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Page 22 DDC Clock DDC Clock TX1p TX1p DDC Data DDC Data TX1n TX1n TX0p TX0p Hot Plug Hot Plug Detect Detect TX0n TX0n CLKp CLKp www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Page 23 1Gbps data rate Green On 100Mbps data rate 10Mbps data rate Pin No. Definition Pin No. Definition TX1+ TX3+ TX1- TX3- TX2+ TX4+ TX2- TX4- www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Page 24 USB32_1 (USB 3.2 Gen 2x1 Connector) USB 3.2 Gen 2x1 connector Pin No. Definition Pin No. Definition USB3_RX1n USB3_RX2n USB3_RX1p USB3_RX2p USB3_TX1n USB3_TX2n USB3_TX1p USB3_TX2p www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Page 25 BKL_CN (Backlight Control header) Pin 1 Backlight Control connector Connector PN Vendor 85205-0770N ACES A1250WV-S-07PC JOINT-TECH Connector type 1x7pin header, pitch 1.25mm Pin No. Definition www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Page 26 Vendor A2001WV-04P146 JOINT-TECH Connector type 1x4pin header, pitch 2.0mm Pin No. Definition Speaker Out R+ Speaker Out R- Speaker Out L- Speaker Out L+ www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Page 27 Front panel audio header Connector PN Vendor 725-81-10TW00 PINREX Connector type 2x5pin header, pitch 2.0mm Definition Definition MIC-Left MIC-Right HPOUT_ MIC_JD Right FAUDIO_JD HPOUT_Left 10 HPOUT_JD www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Page 28 2.2.7 SODIMM1, SODIMM2 (DDR4 SO-DIMM slot) www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Page 29 SATAPW (SATA power connector) Pin 1 Hard Disk Power Connector Connector PN Vendor 743-91-045W00 PINREX Connector type 1x4pin header, pitch 2.54mm Pin No. Definition www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Page 30 2.2.9 SATA (SATA 6Gb/s connector) Pin 1 SATA 6Gb/s Connector Pin No. Definition www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Page 31 2.2.10 F_USB2_2 (USB 2.0 header) Pin 1 USB 2.0 header Connector PN Vendor 210-92-05G117 PINREX Connector type 2x5pin header, pitch 2.54mm Pin No. Definition No Pin www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Page 32 2.2.11 F_USB2_1 (USB 2.0 header) Pin 1 USB 2.0 header Connector PN Vendor 210-92-05G117 PINREX Connector type 2x5pin header, pitch 2.54mm Pin No. Definition No Pin www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Page 33 Vendor 725-81-12TW00 PINREX Connector type 2x6pin header, pitch 2.0mm Pin No. Definition GPIO-input_1 GPIO-output_1 GPIO-input_2 GPIO-output_2 GPIO-input_3 GPIO-output_3 GPIO-input_4 GPIO-output_4 SMBus Clock SMBus DATA www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Page 34 2x5pin header, pitch 2.54mm Pin No. Definition HDD LED+ Power LED+ HDD LED- Power LED- Power Button+ Reset Button Power Button- No Connect No Pin www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Page 35 Pin No. Definition TX3p 3.3V 3.3V SUSCLK RX2n 3.3V M2_SSD_ 3.3V Detect RX2p 3.3V 3.3V TX2n TX2p Connector PN Vendor RX1n 2E0BC41-C85CM-LH FOXCONN RX1p TX1n www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Page 36 1-2 Close : AT mode. A2015WV-03P6T JOINT-TECH 2-3 Close : ATX mode. (Default setting) Connector type Pin No. Definition 1x3pin header, pitch 2.0mm AT mode Detect ATX mode www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Page 37 COM3, COM4 : Support RS-232 RXD- — RXD+ — — — — — — — — — No Connect — — RI/5V/12V — — www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Page 38 PCIE_WAKE# 3.3V 1.5V 1.5V PCIE_ SIM_PWR CLKREQ# 3.3V SIM_DATA Connector PN Vendor PCIE_CLKn SIM_CLK PCIE_CLKp SIM_RST AS0B221-S99Q-7H FOXCONN SIM_VPP PCIE_DISABLE PCIRST# PCIE_RXn 3.3V PCIE_RXp www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Page 39 Pin 1 DC IN power connector Connector PN Vendor 753-81-04TW00 PINREX Connector type 1x4pin header, pitch 2.5mm Pin No. Definition POWER IN POWER IN www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Page 40 PCIE_RST 3.3V PCIE_WAKE BT_Disable# USB_Dp 3.3V WLAN_ USB_Dn DISABLE 3.3V 3.3V Pin No. Definition Pin No. Definition Connector PN Vendor 80152-4221 BELLWETHER WLAN_TXp WLAN_TXn www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Page 41 Vendor 222-97-03GBE1 PINREX 1-2 Close: 5V (Power COM) Connector type 2x3pin header, pitch 2.0mm 3-4 Close: RI (Stand COM) 5-6 Close: 12V (Power COM) www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Page 42 2.2.20 Battery (Battery Connector) Pin 1 Battery Connector Pin No. Definition www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Page 43 CPU FAN connector Connector PN Vendor 85205-0470N ACES 4 3 2 1 A1250WV-S-04PC JOINT-TECH Connector type 1x4pin header, pitch 1.25mm Pin No. Definition Detect Speed Control www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Page 44 Pin 1 System FAN connector Connector PN Vendor 85205-0470N ACES A1250WV-S-04PC JOINT-TECH Connector type 1x4pin header, pitch 1.25mm Pin No. Definition Detect Speed Control www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Page 45 EDP_AUX- 1x20pin header, pitch 0.5mm EDP_TX0+ EDP_AUX+ EDP_Detect Hotplug EDP_TX1- Detect Backlight EDP_TX1+ Enable Backlight EDP_TX2- control EDP_TX2+ H1 -> GND H2 -> GND www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Page 46 Chapter 3 Chapter 3 – BIOS www.gigaipc.com...
Page 47 Execute command or enter the submenu Increase the numeric value or make ＋ changes Decrease the numeric value or make – changes General Help Previous Values Load Optimized Defaults Settings Save changes & Exit the BIOS Setup program Exit the BIOS Setup program www.gigaipc.com...
Page 48 Shows the total memory size of the installed memory Set the Date for the system System Date (Format : Week - Month - Day - Year) Set the time for the system System Time (Format : Hour - Minute - Second) www.gigaipc.com...
Page 49 Advanced The Advanced menu is to configure the functions of hardware settings through submenu. Use arrow keys to move among the items, and press <Enter> to access into the related submenu. www.gigaipc.com...
Page 50 Pending operation : Trusted Computing None : No execution will be conducted (Default setting) TPM clear : Set to clear data on TPM Physical Presence Spec Version : Choose PPI spec version Option items : 1.2 or 1.3 (Default setting) www.gigaipc.com...
Page 51 Enabled : Enables allows you to configure the serial port settings Disabled : if Disabled, displays no configuration for the serial port Serial Port 4 Device settings : Configuration Display the specified Serial Port base I/O address and IRQ www.gigaipc.com...
Page 52 Normal : Fan speed set by BIOS default (Default setting) Control Full Speed : Set Fan operates at full speed CPU Temperature Shows current CPU temperature System Shows current system temperature Temperature CPU Fan Speed shows current CPU Fan speed System Fan Speed shows current System Fan speed www.gigaipc.com...
Page 53 Command CPU to enter into low power consumption mode when CPU is under idle mode. Global C-state Enabled : Enables Global C-states Control Control Disabled : Disables Global C-states Control Auto : System will automactically detect (Default setting) Node 0 Shows AMD CPU information Information www.gigaipc.com...
Page 54 Disabled : Disables IPv6 HTTP Support Enabled : Enables IPv6 HTTP Support PXE boot wait time Wait time in seconds, or use ESC key to abort the PXE boot. Media detect count Number of times the presence of media will be checked. www.gigaipc.com...
Page 55 Enable or Disable System to wake on a specific time. Wake system Disabled : Disables system to wake on a specific time (Default setting) from S5 Fixed Time : Enables system to wake on a specific time (Format : hr : min : sec) www.gigaipc.com...
Page 56 3.3.7 NVMe Configuration NVMe Configuration shows information when your M.2 NVMe PCIe SSD is installed. www.gigaipc.com...
Page 57 3.3.8 SATA Configuration SATA Configuration shows information when your SATA interface Storage is installed. www.gigaipc.com...
Page 58 3.3.9 OffBoard SATA Controller Configuration www.gigaipc.com...
Page 59 Enabled : If Digital IO Output value/level is modified in OS, they will be memorized and kept. SOGPI_1 (Pin 1) SOGPO_1 (Pin 2) SOGPI_2 (Pin 3) SOGPO_2 (Pin 4) Configure Digital IO Input or Output values for each pin. SOGPI_3 (Pin 5) SOGPO_3 (Pin 6) SOGPI_4 (Pin 7) SOGPO_4 (Pin 8) www.gigaipc.com...
Page 60 3.3.11 Realtek PCIe GBE Family Controller (MAC : D8:5E:D3:0C:50: 6B) (MAC address may varied based on different motherboard) Shows Realtek Ethernet controller information NOTE：MAC address may varied based on different motherboard 　 www.gigaipc.com...
Page 61 3.3.12 Realtek PCIe GBE Family Controller (MAC : D8:5E:D3:0C:50: 6C) (MAC address may varied based on different motherboard) Shows Realtek Ethernet controller information NOTE：MAC address may varied based on different motherboard 　 www.gigaipc.com...
Page 62 Power off : Do not power on when the power is back (Default setting) Last state : Restore the system to the state before power loss occures Watchdog timer Enable/Disable Watchdog Timer function Value Option item : Disabled : Disabled (Default setting), 30 Seconds, 60 Seconds www.gigaipc.com...
Page 63 To set up Administrator's password Administrator Minimum length : 3 Password Maximum length : 20 To set up User's password User Password Minimum length : 3 Maximum length : 20 Secure Boot Press <Enter> to configure the advanced items www.gigaipc.com...
Page 64 No : Cancel to restore factory settings Reset To Setup Yes : Agree to setup mode Mode No : Cancel to setup mode Enables expert users to modify Secure boot policy variables without Key Management full authentication Press <Enter> to configure the advanced items www.gigaipc.com...
Page 65 'UEFI CA' from database from DB No : Cancel to remove 'UEFI CA' from database Restore DB variables to fac tor y Restore DB defaults defaults Yes : Agree to restore DB defaults No : Cancel to restore DB defaults www.gigaipc.com...
Page 66 Enabled : Enables Full screen LOGO Show on POST screen LOGO Show Disabled : Disables Full screen LOGO Show on POST screen (Default setting) Shows the information of the storage that be installed in the system Boot Option #1 Choose/set the boot priority www.gigaipc.com...
Page 67 Yes : Agree to discard changes and reset and Reset No : Cancel to discard changes and reset Restore/Load default values for all the setup options Restore Defaults Yes : Agree to load optimized defaults No : Cancel to load optimized defaults Boot Override Boot override www.gigaipc.com...
