Page 1: Qbix-Pro Industrial Embedded System
QBiX-Pro-RPLA1355H-A2 QBiX-Pro-RPLA1335H-A2 QBiX-Pro-RPLA1315EH-A2 QBiX-Pro Industrial Embedded System Quick Start Guide www.gigaipc.com... -
Page 2: Copyright Notice
While reasonable efforts have been made in the preparation of this document to assure its accuracy, GIGAIPC assumes no liabilities resulting from errors or omissions in this document, or from the use of the information contained herein. -
Page 3: Acknowledgement
Core, Atom are trademarks of Intel Corporation ITE is a trademark of Integrated Technology Express, Inc. • • IBM, PC/AT, PS/2, and VGA are trademarks of International Business Machines Corporation. All other product names or trademarks are properties of their respective owners. www.gigaipc.com... -
Page 4: Packing List
SATA Cable (25CRI-070000-S9R) Exsiccator (25g) Thermal pad for Memory (25ST3-200086-T5R) Power Cord : Optional (by region) PSU ADP 19.5V 135W 100-240VAC (25EP4-201352- C1S) If any of these items are missing or damaged, please contact your distributor or sales representative immediately. www.gigaipc.com... -
Page 5: About This Document
(if any), its specifications, dimensions, jumper/ connector settings/definitions, and driver installation instructions (if any), to facilitate users in setting up their product. Users may refer to the GIGAIPC.com for the latest version of this document. www.gigaipc.com... -
Page 6: Safety Precautions
Make sure the device is installed near a power outlet and is easily accessible. 10. Keep this device away from humidity. 11. Place the device on a solid surface during installation to prevent falls 12. Do not cover the openings on the device to ensure optimal heat dissipation. www.gigaipc.com... - Page 7 18. D O N O T L E AV E T H I S D E V I C E I N A N U N C O N T R O L L E D ENVIRONMENT WITH TEMPERATURES BEYOND THE DEVICE’S PERMITTED STORAGE TEMPERATURES (SEE CHAPTER 1) TO PREVENT DAMAGE. www.gigaipc.com...
-
Page 8: Fcc Statement
Skilled person have to pay special attention or take special protection. Only authorized by well trained professional person can access the restrict access location. (2) External metal parts are hot!! Before touching it, special attention or protection is necessary www.gigaipc.com... -
Page 9: Table Of Contents
Safety Precautions ............... 6 FCC Statement ................8 High Temperature Warning ............8 Chapter 1 - Product Specifications Specifications ............... 15 Chapter 2 – QBiX-Pro-RPLA1355H-A2 (QP-1355A-SI) QBiX-Pro-RPLA1335H-A2 (QP-1335A-SI) QBiX-Pro-RPLA1315EH-A2 (QP-1315A-SI) Industrial Embedded System Kit Dimension ..............18 Getting Familiar with Your Unit........19 A) Memory Installation: DDR4 SO-DIMM .... - Page 10 SODIMM1, SODIMM2 (DDR4 SO-DIMM Slot) ....42 3.2.10 LSW (LVDS resolution jumper) ........43 3.2.11 LVDS (LVDS connector) ..........44 3.2.12 BKL_CN (Backlight control header) ....... 45 3.2.13 SPK_OUT (Speaker out connector) ....... 46 3.2.14 FP_AUDIO (Front Audio connector) ......47 www.gigaipc.com...
- Page 11 3.2.28 M2M_CPU (M.2 Slot, 2280 M-key) ....... 61 Chapter 4 – BIOS Introduction ..............63 The Main Menu............. 64 Advanced ..............65 4.3.1 TPM Configuration ............66 4.3.2 CPU Configuration ............68 4.3.3 SATA Configuration ............69 4.3.4 IT8786 Super IO Configuration ........70 www.gigaipc.com...
- Page 12 4.3.10 Digital IO Port Configuration ........76 4.3.11 Tls Auth Configuration ..........77 4.3.12 Intel(R) Ethernet Controller I226-V - 74:56:3C:B4:1E:0E ..................78 4.3.13 Intel(R) Ethernet Controller I226-V - 74:56:3C:B4:1E:0F ..................79 Chipset ................80 Security ................. 81 Boot ................84 Save & Exit ..............85 www.gigaipc.com...
-
Page 13: Chapter 1 - Product Specifications
Chapter 1 Chapter 1 - Product Specifications www.gigaipc.com... - Page 14 52.7 56.7 134.65 www.gigaipc.com...
-
Page 15: Specifications
2 x RJ45 LAN Ports 4 x USB 3.2 Gen 2x1 2 x HDMI Front I/O 1 x Power button with LED 1 x HDD LED 1 x COM Port (RS-232/422/485 & RI/5V/12V) 1 x External Antenna Hole (Optional) www.gigaipc.com... - Page 16 Thermal Pad for Memory x 1 (P/N: 25ST3-200086-T5R) SATA Cable x 1 (P/N: 25CRI-070000-S9R) Power Cord : Optional (by region) PSU ADP 19.5V 135W 100-240VAC x 1 (P/N: 25EP4-201352-C1S) System: System: System: Order 6BQP1355AMR-SI 6BQP1335AMR-SI 6BQP1315AMR-SI Information (Box packing) (Box packing) (Box packing) www.gigaipc.com...
-
Page 17: Chapter 2 - Qbix-Pro-Rpla1355H-A2 (Qp-1355A-Si)
Chapter 2 Chapter 2 – QBiX-Pro-RPLA1355H-A2 (QP-1355A-SI) QBiX-Pro-RPLA1335H-A2 (QP-1335A-SI) QBiX-Pro-RPLA1315EH-A2 (QP-1315A-SI) Industrial Embedded System Kit www.gigaipc.com... -
Page 18: Dimension
Dimension 52.7 56.7 134.65 www.gigaipc.com... -
Page 19: Getting Familiar With Your Unit
1 x Power button with LED [Rear Side] [Right Side] 2 x USB 2.0 2 x Antenna (Optional) 1 x Headphone Jack 2 x COM Ports (COM2 & COM3, RS-232/422/485) 1 x Screw Type DC Jack 1 x GPIO (8-bits) www.gigaipc.com... - Page 20 [Bottom PCB Side] Information Information 1 x M.2 slot 2280 M-key 2 x DDR4 SO-DIMM sockets 1 x M.2 slot 2230 E-key 1 x Mini PCIe slot with SIM Slot support 2.5’’ Hard drive/SSD www.gigaipc.com...
-
Page 21: A) Memory Installation: Ddr4 So-Dimm
A) Memory Installation: DDR4 SO-DIMM www.gigaipc.com... -
Page 22: B) Mini Pcie Card Installation: How To Safely Install The Mini Pcie Card
Remove the screw from the screw Carefully insert the Mini PCIe Card Carefully insert the wireless module into Lock the screw in the middle. the M.2 slot hole (Location : MSO4) into the slot. 鎖入固定於無線模組中央頂端的螺 小心地將無線模組安裝於M.2插槽中。 絲。 Secure the Mini PCIe Card with screw. www.gigaipc.com... -
Page 23: C) M.2 Ssd Installation: How To Safely Install The
Remove the screw from the screw Carefully insert the M.2 SSD into the Carefully insert the wireless module into Lock the screw in the middle. the M.2 slot hole (Location : MSO2) slot, and secure with the screw. 鎖入固定於無線模組中央頂端的螺 小心地將無線模組安裝於M.2插槽中。 絲。 www.gigaipc.com... -
Page 24: D) Wireless Module: How To Safely Install The Module
D) Wireless Module: How to safely install the Module (Wireless Module inclusion may vary based on local distribution) Carefully insert the wireless module into Lock the screw in the middle. the M.2 slot Install the antenna on the left side of the connection wireless module down. www.gigaipc.com... -
Page 25: E) 2.5" Hdd/Ssd Installation: How To Install 2.5" Hdd/Ssd
Third : install 2.5" HDD/SSD (Gold finger of 2.5" HDD/SSD must face down), and secure with 4 screws. Fourth : install the bracket back with 3 screws. Assemble the SATA cable on the SATA connector, and lock the bottom cover. www.gigaipc.com... -
Page 26: Antenna Installation (Antenna Inclusion May Vary Based On Local Distribution)
Antenna Installation (Antenna inclusion may vary based on local distribution) www.gigaipc.com... -
Page 27: Cable Pin-Define
RS-485 DB9 Pin RS-232 Full Duplex Half Duplex TXD- TXD+ RXD+ – RXD- – – – – – – – – – 2. DBP DIO (25CR5-150606-S9R) DBP DIO Pin Pin Name GPIO-output_1 GPIO-input_1 GPIO-output_2 GPIO-input_2 GPIO-output_3 GPIO-input_3 GPIO-output_4 GPIO-input_4 www.gigaipc.com... -
Page 28: Support
Support ● For a list of tested memory, M.2, 2.5’’ SSD, wireless adapters and OS supported, go to: http://www.gigaipc.com ● To download the latest drivers and BIOS updates, go to: http://www. gigaipc.com ● For product support, go to: http://www.gigaipc.com www.gigaipc.com... -
Page 29: Safety And Regulatory Information
At the end of its serviceable life, this product should not be treated as household or general waste. It should be handed over to the applicable collection point for the recycling of electrical and electronic equipment, or returned to the supplier for disposal. www.gigaipc.com... -
Page 30: Chapter 3 - Hardware Information
Chapter 3 Chapter 3 – Hardware Information www.gigaipc.com... -
Page 31: Jumpers And Connectors
Jumpers and Connectors www.gigaipc.com... - Page 32 GPIO_CNT General purpose input / ouput header SYS_PANEL Front panel header DC_IN DC IN 1x4 pin power connector AT_CN AT/ATX mode select jumper COM2, COM3, Serial port header (RS-232/422/485) COM4 FUSB1, FUSB2 USB 2.0 headers ME_DIS ME Disable jumper www.gigaipc.com...
- Page 33 Code Description RI# pin RI#/5V/12V Select jumper for COM1 JCOM1 Port SATA0 SATA 6Gb/s connector SATAPWR SATA power connector M.2 Slot, 2230 E-key MPCIE Mini PCIe slot BATTERY Battery cable connector M2M_CPU M.2 Slot, 2280 M-key www.gigaipc.com...
-
Page 34: Cpu_Fan (Cpu Fan Connector)
3.2.1 CPU_FAN (CPU fan connector) Pin 1 CPU fan Connector Connector PN Vendor 85205-0470N ACES A1250WV-S-04PC JOINT-TECH Connector type 1x4pin header, pitch 1.25mm Pin No. Definition Detect Speed control www.gigaipc.com... -
Page 35: Sys_Fan (System Fan Connector)
3.2.2 SYS_FAN (System fan connector) Pin 1 System fan Connector Connector PN Vendor 85205-0470N ACES A1250WV-S-04PC JOINT-TECH Connector type 1x4pin header, pitch 1.25mm Pin No. Definition Detect Speed control www.gigaipc.com... -
Page 36: Com1 (Serial Port (Rs-232/422/485 & Ri/5V/12V))
3.2.3 COM1 (Serial Port (RS-232/422/485 & RI/5V/12V)) Serial Port connector Connector PN Vendor SM41D1P1122N33N1 FENYING RS-232 RS-422 RS-485 Full Duplex Half Duplex TXD- TXD+ RXD+ – RXD- – – – – – – – – – www.gigaipc.com... -
Page 37: Lan2 (Lan Connector)
Description Yellow On 2.5Gbps data rate Green On 1Gbps data rate 100Mbps data rate Link / Connection/ 10Mbps data rate Speed LED Activity LED Pin No. Definition BI_DA+ Connector PN Vendor BI_DA- RB1-GB-0009 BI_DB+ BI_DB- BI_DC+ BI_DC- BI_DD+ BI_DD- www.gigaipc.com... -
Page 38: Lan1 (Lan Connector)
Description Yellow On 2.5Gbps data rate Green On 1Gbps data rate 100Mbps data rate Link / Connection/ 10Mbps data rate Speed LED Activity LED Pin No. Definition BI_DA+ Connector PN Vendor BI_DA- RB1-GB-0009 BI_DB+ BI_DB- BI_DC+ BI_DC- BI_DD+ BI_DD- www.gigaipc.com... -
Page 39: Hdmi2_21 (Hdmi Connector)
3.2.6 HDMI2_21 (HDMI connector) HDMI 1 HDMI 2 HDMI Connector Connector PN Vendor QJ11191-DFB1-4F FOXCONN Definition Definition HDMI_D2p HDMI_CLKn HDMI_D2n HDMI_D1p HDMI_SCL HDMI_D1n HDMI_SDA HDMI_D0p HDMI_D0n HDMI_HPD HDMI_CLKp www.gigaipc.com... -
Page 40: Usb32_2 (Usb 3.2 Gen 2X1 Connector)
3.2.7 USB32_2 (USB 3.2 Gen 2x1 connector) USB Connector Connector PN Vendor 18-A5950-6A33-A TCONN Definition Definition USB_Dn USB_Dn USB_Dp USB_Dp USB3_RXn USB3_RXn USB3_RXp USB3_RXp USB3_TXn USB3_TXn USB3_TXp USB3_TXp www.gigaipc.com... -
Page 41: Usb32_1 (Usb 3.2 Gen 2X1 Connector)
3.2.8 USB32_1 (USB 3.2 Gen 2x1 connector) USB Connector Connector PN Vendor 18-A5950-6A33-A TCONN Definition Definition USB_Dn USB_Dn USB_Dp USB_Dp USB3_RXn USB3_RXn USB3_RXp USB3_RXp USB3_TXn USB3_TXn USB3_TXp USB3_TXp www.gigaipc.com... -
Page 42: Sodimm1, Sodimm2 (Ddr4 So-Dimm Slot)
3.2.9 SODIMM1, SODIMM2 (DDR4 SO-DIMM Slot) www.gigaipc.com... -
Page 43: Lsw (Lvds Resolution Jumper)
1024 x 600 1600 x 900 18bit 24bit 1280 x 800 1680 x 1050 18bit 24bit 1280 x 960 1600 x 1200 18bit 24bit 1280 x 1024 1920 x 1080 24bit 24bit 1366 x 768 1920 x 1200 18bit 24bit www.gigaipc.com... -
Page 44: Lvds (Lvds Connector)
But below model no need to add. A0~A3 is odd channel 0~3, A4~A7 is even channel. Note: *The LVDS output connector of the unit is CLK2+ only intended to be connected to an UL/IEC/EN CLK1+ approval equipment with fire enclosure. CLK2- CLK1- www.gigaipc.com... -
Page 45: Bkl_Cn (Backlight Control Header)
3.2.12 BKL_CN (Backlight control header) Pin 1 Backlight control header Connector PN Vendor 721-81-05TW00 PINREX A2001WV-05P146 JOINT-TECH Connector type 1x5pin header, pitch 2.0mm Pin No. Definition Backlight Enable www.gigaipc.com... -
Page 46: Spk_Out (Speaker Out Connector)
3.2.13 SPK_OUT (Speaker out connector) Pin 1 Audio Amplifie Connector Connector PN Vendor 721-81-045W00 PINREX A2001WV-04P146 JOINT-TECH Connector type 1x4pin header, pitch 2.0mm Pin No. Definition Speaker Out L+ Speaker Out L- Speaker Out R- Speaker Out R+ www.gigaipc.com... -
Page 47: Fp_Audio (Front Audio Connector)
3.2.14 FP_AUDIO (Front Audio connector) Pin 1 Front Audio Connector Connector PN Vendor 725-81-10TW00 PINREX A2004WV-2X05P46 JOINT-TECH Connector type Pin No. Definition 2x5pin header, pitch 2.0mm MIC_Left MIC_Right Detect LINE_Right MIC_JD Jacksense Detect No Connect LINE_Left www.gigaipc.com... -
Page 48: Gpio_Cnt (General Purpose Input/Output Header)
3.2.15 GPIO_CNT (General Purpose input/output header) Pin 1 GPIO Connector Pin No. Definition SMB_DATA Pin No. Definition Connector PN Vendor GPIO-output_1 725-81-12TW00 PINREX GPIO-input_1 GPIO-output_2 A2004WV-2X06P46 JOINT-TECH GPIO-input_2 Connector type GPIO-output_3 2x6pin header, pitch 2.0mm GPIO-input_3 GPIO-output_4 GPIO-input_4 SMBus Clock www.gigaipc.com... -
Page 49: Sys_Panel (Front Panel Header)
3.2.16 SYS_PANEL (Front panel header) Pin 1 System Panel Header Connector PN Vendor 210-92-05GW5W PINREX Connector type 2x5pin header, pitch 2.54mm Pin No. Definition HDD LED+ Power LED+ HDD LED- Power LED- Power Button+ Reset Button Power Button- No Connect No Pin www.gigaipc.com... -
Page 50: Dc_In (Dc In 1X4 Pin Power Connector)
3.2.17 DC_IN (DC IN 1x4 pin power connector) Pin 1 DC IN connector Connector PN Vendor 753-81-04TW00 PINREX Connector type 1 2 34 1x4pin header, pitch 2.5mm Pin No. Definition Power Power www.gigaipc.com... -
Page 51: At_Cn (At/Atx Mode Select Jumper)
3.2.18 AT_CN (AT/ATX mode select jumper) Pin 1 AT/ATX mode select jumper Connector PN Vendor 220-96-03GB001K PINREX Connector type 1x3pin header, pitch 2.0mm Pin No. Definition AT MODE TXD5 ATX MODE Jumper setting 1-2 Close : AT mode. 2-3 Close : ATX mode.(Default setting) www.gigaipc.com... -
Page 52: Com2, Com3, Com4
Connector PN Vendor 725-81-10TW00 PINREX A2004WV-2X05P46 JOINT-TECH Connector type 2x5pin header, pitch 2.0mm RS-232 RS-422 RS-485 Full Duplex Half Duplex TXD+ TXD- RXD- — RXD+ — — — — — — — — — No Connect — — — — www.gigaipc.com... -
Page 53: Fusb1, Fusb2 (Usb 2.0 Headers)
3.2.20 FUSB1, FUSB2 (USB 2.0 headers) FUSB2 FUSB1 Pin 1 USB 2.0 Header Connector PN Vendor 210-92-05GB04 PINREX PH10R53BAZ009 HORNGTONG Connector type 2x5pin header, pitch 2.54mm Pin No. Definition No Pin No Connect www.gigaipc.com... -
Page 54: Me_Dis (Me Disable Jumper)
3.2.21 ME_DIS (ME Disable jumper) ME Disable Connector Connector PN Vendor 220-96-02GBK1 PINREX Connector type 1x2pin header, pitch 2.0mm ME Disable jumper Enable (Default setting) Disable www.gigaipc.com... -
Page 55: Jcom1 (Ri# Pin Ri#/5V/12V Select Jumper For Com1 Port)
3.2.22 JCOM1 (RI# pin RI#/5V/12V Select jumper for COM1 Port) Pin 1 JCOM1 Jumper Select Connector PN Vendor 220-97-03GB01 PINREX 1-2 Close: 5V (Power COM) PH06N53BAZ000 HORNGTONG Connector type 3-4 Close: RI (Stand COM) 2x3pin header, pitch 2.0mm (Default-Setting) 5-6 Close: 12V (Power COM) www.gigaipc.com... -
Page 56: Sata0 (Sata 6Gb/S Connector)
3.2.23 SATA0 (SATA 6Gb/s connector) SATA Connector Connector PN Vendor WATF-07DBLBA1UW WINWIN Pin No. Definition www.gigaipc.com... -
Page 57: Satapwr (Sata Power Connector)
3.2.24 SATAPWR (SATA power connector) Pin 1 Hard Disk Power Connector Connector PN Vendor 743-81-04TW00 PINREX Connector type 1x4pin header, pitch 2.54mm Pin No. Definition www.gigaipc.com... -
Page 58: M2E (M.2 Slot, 2230 E-Key)
M.2 E Key Connector WLAN_RXp CL_DATA WLAN_RXn CL_CLK CLK_Dp CLK_Dn SUSCLK Pin No. Definition Pin No. Definition CLK_REQ PCIE_RST PCIE_WAKE BT_Disable# USB_Dp WLAN_ USB_Dn DISABLE Pin No. Definition Pin No. Definition Connector PN Vendor APCI0095-P002A LOTES WLAN_TXp 80152-8521 BELLWETHER WLAN_TXn www.gigaipc.com... -
Page 59: Mpcie (Mini Pcie Slot)
Pin No. Definition USB Dn PCIE WAKE 3.3V USB Dp 3.3V 3.3V PCIE Clock SIM PWR Request SIM DATA PCIE Clock n SIM Clock PCIE Clock p SIM Reset 3.3V UIM VPP3 Connector PN Vendor WLAN_ AS0B221-S99Q-7H FOXCONN DISABLE www.gigaipc.com... -
Page 60: Battery (Battery Cable Connector)
3.2.27 BATTERY (Battery cable Connector) Pin 1 Battery cable Connector Connector PN Vendor 85205-0270L ACES A1250WV-S-02PC JOINT-TECH Connector type 1x2pin header, pitch 1.25mm Pin No. Definition 3.3V www.gigaipc.com... -
Page 61: M2M_Cpu (M.2 Slot, 2280 M-Key)
3.3V SATA_TXp PLT_RST PCIE_RXn3 CK_REQ PCIE_RXp3 CLK_n PCIE_WAKE# M2_LED CLK_p PCIE_TXn3 3.3V PCIE_TXp3 3.3V Pin No. Definition Pin No. Definition 3.3V SUSCLK PCIE_RXn2 3.3V M2_SSD_ PCIE_RXp2 3.3V Detect 3.3V PCIE_TXn2 3.3V PCIE_TXp2 PCIE_RXn1 Connector PN Vendor PCIE_RXp1 2E0BC41-C85CM-LH FOXCONN www.gigaipc.com... -
Page 62: Chapter 4 - Bios
Chapter 4 Chapter 4 – BIOS www.gigaipc.com... -
Page 63: Introduction
Execute command or enter the submenu Increase the numeric value or make ＋ changes Decrease the numeric value or make – changes General Help Previous Values Load Optimized Defaults Settings Save changes & Exit the BIOS Setup program Exit the BIOS Setup program www.gigaipc.com... -
Page 64: The Main Menu
ME FW version Shows ME firmware version Set the Date for the system System Date (Format : Week - Month - Day - Year) Set the time for the system System Time (Format : Hour - Minute - Second) www.gigaipc.com... -
Page 65: Advanced
Advanced The Advanced menu is to configure the functions of hardware settings through submenu. Use arrow keys to move among the items, and press <Enter> to access into the related submenu. www.gigaipc.com... -
Page 66: Tpm Configuration
4.3.1 TPM Configuration Use TPM Configuration submenu to choose TPM interface. Item Description PTT : Internal TPM TPM Device dTPM : External TPM (When using External TPM module or having Selection TPM chip on MB)(Default setting) www.gigaipc.com... - Page 67 Item Description Security Device Enabled : Enables TPM feature (Default setting) support Disabled : Disables TPM feature None : No execution will be conducted (Default setting) Pending operation TPM clear : Set to clear data on TPM www.gigaipc.com...
-
Page 68: Cpu Configuration
Enabled : Enables Turbo Mode (Default setting) Turbo Mode Disabled : Disables Turbo Mode Command CPU to enter into low power consumption mode when CPU is under idle mode. C states Enabled : Enables C states (Default setting) Disabled : Disables C states www.gigaipc.com... -
Page 69: Sata Configuration
Intel VMD feature helps you to control and manage NVMe PCIe SSD. / Enable VMD Enabled : Enables Intel VMD feature controller Disabled : Disables Intel VMD feature (Default setting) Serial ATA Port shows 2.5" SATA HDD/SSD information shows M.2 SATA interface SSD information www.gigaipc.com... -
Page 70: It8786 Super Io Configuration
Disabled : if Disabled, displays no configuration for the serial port Serial Port 2 Configuration Device settings : Display the specified Serial Port base I/O address and IRQ COM Port Mode : Serial Port 3 Choose RS-232, RS-422, or RS-485 feature Configuration www.gigaipc.com... -
Page 71: Hardware Monitor
4.3.5 Hardware Monitor Item Description CPU Temperature Shows current CPU temperature System Shows current system temperature Temperature www.gigaipc.com... -
Page 72: S5 Rtc Wake Settings
Enable or Disable System to wake on a specific time. Disabled : Disables system to wake on a specific time (Default Wake system setting) from S5 Fixed Time : Enables system to wake on a specific time (Format : hr : min : sec) www.gigaipc.com... -
Page 73: Network Stack Configuration
Disabled : Disables IPv6 HTTP Support Support Enabled : Enables IPv6 HTTP Support PXE boot wait Wait time in seconds, or use ESC key to abort the PXE boot. time Media detect Number of times the presence of media will be checked. count www.gigaipc.com... -
Page 74: Nvme Configuration
4.3.8 NVMe Configuration NVMe Configuration shows information when your M.2 NVMe PCIe SSD is installed. www.gigaipc.com... -
Page 75: Offboard Sata Controller Configuration
4.3.9 Offboard SATA Controller Configuration www.gigaipc.com... -
Page 76: Digital Io Port Configuration
Enabled : If Digital IO Output value/level is modified in OS, they will be memorized and kept. SOGPO_1 (Pin 1) SOGPI_1 (Pin 2) SOGPO_2 (Pin 3) SOGPI_2 (Pin 4) Configure Digital IO Input or Output values for each pin. SOGPO_3 (Pin 5) SOGPI_3 (Pin 6) SOGPO_4 (Pin 7) SOGPI_4 (Pin 8) www.gigaipc.com... -
Page 77: Tls Auth Configuration
Press [Enter] to configure advanced items : Server CA Configuration : Enroll Cert : 1. Enroll Cert Using File Enroll Cert 2. Cert GUID : Input digit character in 11111111-2222-3333-4444-1234567 890ab format. 3. Commit Changes and Exit 4. Discard Changes and Exit www.gigaipc.com... -
Page 78: Intel(R) Ethernet Controller I226-V - 74:56:3C:b4:1E:0E
4.3.12 Intel(R) Ethernet Controller I226-V - 74:56:3C:B4:1E:0E Shows Intel Ethernet controller information www.gigaipc.com... -
Page 79: Intel(R) Ethernet Controller I226-V - 74:56:3C:b4:1E:0F
4.3.13 Intel(R) Ethernet Controller I226-V - 74:56:3C:B4:1E:0F Shows Intel Ethernet controller information www.gigaipc.com... -
Page 80: Chipset
Enable/Disable Watchdog Timer function Watchdog Timer Enabled : Enables Watchdog Timer function Disabled : Disabled Watchdog Timer function (Default setting) Enable/Disable BIOS Lock function BIOS Lock Enabled : Enables BIOS Lock function (Default setting) Disabled : Disabled BIOS Lock funtion www.gigaipc.com... -
Page 81: Security
To set up Administrator's password Administrator Minimum length : 3 Password Maximum length : 20 To set up User's password User Password Minimum length : 3 Maximum length : 20 Secure Boot Press <Enter> to configure the advanced items www.gigaipc.com... - Page 82 No : Cancel to restore factory settings Reset To Setup Yes : Agree to setup mode Mode No : Cancel to setup mode Enables expert users to modify Secure boot policy variables without Key Management full authentication Press <Enter> to configure the advanced items www.gigaipc.com...
- Page 83 Device Guard ready system variables file system device must not list ’Microsoft MS UEFI CA Key UEFI CA’ Certificate in A u t h o r i z e d S i g n a t u r e database(db) www.gigaipc.com...
-
Page 84: Boot
Enable/Disable Built-in EFI Shell Built-in EFI shell Enabled : Enables Built-in EFI Shell Disabled : Disables Built-in EFI Shell (Default setting) Shows the information of the storage that be installed in the system Boot Option #1 Choose/set the boot priority www.gigaipc.com... -
Page 85: Save & Exit
Yes : Agree to load optimized defaults No : Cancel to load optimized defaults Enable/Disable Me FW image re-flash function Me FW Image Enabled : Enables Me FW image re-flash function Re-Flash Disabled : Disables Me FW image re-flash function (Default setting) www.gigaipc.com...
