QBiP-4200D/ QBiP-4200E/
QBiP-3350B/ QBiP-E3940B/
QBiP-E3940BT

3.5" SBC Boards

User's Manual V1.0
1
www.gigaipc.com
GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QBiP-4200D and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GIGAIPC QBiP-4200D

Summary of Contents for GIGAIPC QBiP-4200D

  • Page 1: Sbc Boards

    QBiP-4200D/ QBiP-4200E/ QBiP-3350B/ QBiP-E3940B/ QBiP-E3940BT 3.5” SBC Boards User’s Manual V1.0 www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 2: Copyright Notice

    GIGAIPC reserves the right to make changes in the product design without notice to its users. www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 3: Acknowledgement

    IBM, PC/AT, PS/2, and VGA are trademarks of International Business Machines Corporation. All other product names or trademarks are properties of their respective owners. www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 4: Packing List

    Quantity QBiP-E3940BT SATA power cable Fanless Heatsink If any of these items are missing or damaged, please contact your distributor or sales representative immediately. www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 5: Assembly Sequence

    Follow the order as shown in picture B to assemble the heatsink 3>. with the suggest torsion. When removing, please reverse (spinning from position 4) to 4>. disassemble the heatsink. www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 6: About This Document

    (if any), to facilitate users in setting up their product. Users may refer to the GIGAIPC.com for the latest version of this document. www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 7: Safety Precautions

    11. Place the device on a solid surface during installation to prevent falls 12. Do not cover the openings on the device to ensure optimal heat www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 8 18. D O N O T L E AV E T H I S D E V I C E I N A N U N C O N T R O L L E D ENVIRONMENT WITH TEMPERATURES BEYOND THE DEVICE’S PERMITTED STORAGE TEMPERATURES (SEE CHAPTER 1) TO PREVENT DAMAGE. www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 9: Fcc Statement

    Ne la remplacer qu’avec le même modèle ou équivalent recommandé par le constructeur. Recycler les batteries usées en accord avec les instructions du fabricant et les directives gouvernementales de recyclage. www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 10: China Rohs Requirements (Cn)

    ○ 及其电子组件 外部信号 ○ ○ ○ ○ ○ ○ 连接器及线材 O： 表示该有毒有害物质在该部件所有均质材料中的含量均在 SJ/T 11363-2006 标准规定的限量要求以下。 X： 表示该有毒有害物质至少在该部件的 某一均质材料中的含量超出 SJ/T 11363-2006 标准规定的限量要求。 备注： 此产品所标示之环保使用期限， 系指在一般正常使用状况下。 www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 11: China Rohs Requirement (En)

    SJ/T 11363-2006-stipulated requirement. Note: The Environment Friendly Use Period as labeled on this product is applicable under normal usage only www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 12: Table Of Contents

    COM1, COM2, COM3, COM4 (Serial port header) ..29 2.2.4 SPK_OUT (Speaker out connector) ........30 2.2.5 JCOM1 (RI# pin RI#/5V/12V Select jumper for COM1 port) ....................31 www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 13 2.2.25 VGA (VGA port) ..............51 2.2.26 CLR_CMOS (Clear CMOS jumper) ........52 Chapter 3 – BIOS Introduction ..............54 The Main Menu..............55 Advanced ................. 56 www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 14 CSM Configuration ............65 3.3.9 Digital IO Port Configuration ........... 66 Chipset ................67 Security ................69 Boot .................. 72 Save & Exit ............... 73 www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 15: Chapter1 - Product Specifications

    Chapter 1 Chapter1 - Product Specifications QBiP-4200D/ QBiP-4200E/ QBiP-3350B/ QBiP-E3940B/ QBiP-E3940BT www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 16 GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 17: Specifications- Qbip-4200D/ Qbip-4200E

    1 x 2242 M.2 M-Key (SATA 6Gb/s) Expansion Slots 1 x Full-size Mini PCIe with SIM slot (PCIe x1 + USB2.0) -- support 3G/4G module www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 18 Non-operating humidity: 0%-95% (non-condensing) ＊ Conditional DC-input 9V support with : (1) SATA_PWR support 5V only (2) LVDS backlight cannot support (3) Total power consumption under 50W www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 19: Specifications- Qbip-3350B

    1 x 2242 M.2 M-Key (SATA 6Gb/s) Expansion Slots 1 x Full-size Mini PCIe with SIM slot (PCIe x1 + USB2.0) -- support 3G/4G module www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 20 Non-operating humidity: 0%-95% (non-condensing) ＊ Conditional DC-input 9V support with : (1) SATA_PWR support 5V only (2) LVDS backlight cannot support (3) Total power consumption under 50W www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 21: Specifications- Qbip-E3940B/ Qbip-E3940Bt

    1 x 2242 M.2 M-Key (SATA 6Gb/s) Expansion Slots 1 x Full-size Mini PCIe with SIM slot (PCIe x1 + USB2.0) -- support 3G module www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 22 95% (non-condensing) ＊ Conditional DC-input 9V support with : (1) SATA_PWR support 5V only (2) LVDS backlight cannot support (3) Total power consumption under 50W www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 23: Chapter 2 - Hardware Information

    Chapter 2 Chapter 2 – Hardware Information www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 24: Jumpers And Connectors

    Jumpers and Connectors www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 25 17 SYS_PANEL Front panel header 18 FUSB2_2 USB 2.0 header 19 MPCIE Mini-PCIe slot 20 M2M M.2 slot, 2242 M-key 21 SIM_CARD 3G/4G SIM Slot www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 26 24 LAN1, LAN2 2 x RJ45 Ports 2 x USB 3.2 Gen 1 25 FUSB30 26 HDMI HDMI connector 27 VGA VGA Port 28 CLR_CMOS Clear CMOS jumper www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 27: Fan (Fan Connector)

    CPU/System FAN Connector PN Vendor 85205-0470N ACES A1250WV-S-04PC JOINT-TECH Connector type 1 2 3 4 1x4pin header, pitch 1.25mm Pin No. Definition Detect Speed Control www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 28: Dc In (Dc In 1X4Pin Power Connector)

    DC IN (DC IN 1x4pin power connector) Pin1 DC in Connector Connector PN Vendor 753-81-04TW00 PINREX Connector type 1x4pin header, pitch 2.5mm Pin No. Definition DCIN DCIN www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 29: Com1, Com2, Com3, Com4 (Serial Port Header)

    – COM2, COM3, COM4 : Support RS-232 only RXD+ – – – – – – – – – No Connect – – – – www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 30: Spk_Out (Speaker Out Connector)

    PINREX A2001WV-04P146 JOINT-TECH Connector type 1x4pin header, pitch 2.0mm Pin No. Definition Speaker Out R+ Speaker Out R- Speaker Out L- Speaker Out L+ www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 31: Jcom1 (Ri# Pin Ri#/5V/12V Select Jumper For Com1 Port)

    PINREX 1-2 Close: PH06N53BAZ000 HORNGTONG 5V (Power COM) Connector type 3-4 Close: 2x3pin header, pitch 2.0mm RI (Stand COM) 5-6 Close: 12V (Power COM) www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 32: Jrs11-Jrs14 (Rs11-14 Select Jumper For Serial Port)

    1T/1R RS-422 Pure RS-232 3T/5R RS-232 (Default) RS-485 Half Duplex 1T/1R RS-485, TX ENABLE Low Active RS-485 Half Duplex 1T/1R RS-485, TX ENABLE High Active www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 33: At_Cn (At/Atx Mode Select Jumper)

    1-2 Close : AT mode. 220-96-03GB01 PINREX 2-3 Close : ATX mode. Connector type (Default setting) 1x3pin header, pitch 2.0mm Pin No. Definition AT MODE Detect ATX MODE www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 34: Lsw (Lvds Resolution Jumper)

    1280 x 960 1600 x 1200 18bit 24bit 1280 x 1024 1920 x 1080 24bit 24bit 1366 x 768 1920 x 1200 18bit 24bit www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 35: Lvds (Lvds Connector)

    Note: *The LVDS output connector CLK2+ CLK1+ of the unit is only intended to be CLK2- connected to an UL/IEC/EN approval CLK1- equipment with fire enclosure. www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 36: Bkl_Cn (Backlight Control Connector)

    2.2.10 BKL_CN (Backlight control connector) Pin1 Backlight control connector Connector PN Vendor 721-81-05TW00 PINREX A2001WV-05P146 JOINT-TECH Connector type 1x5pin header, pitch 2.0mm Pin No. Definition Back Light Enable www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 37: Buzzer (Buzzer Header)

    2.2.11 BUZZER (buzzer header) Pin1 Buzzer Connector PN Vendor 712-71-02TW01 PINREX A1250WV-02P JOINT-TECH Connector type 1x2pin header, pitch 1.25mm Pin No. Definition SPKR www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 38: Battery (Battery Cable Connector)

    2.2.12 BATTERY (Battery cable connector) Pin1 Battery Cable Connector Connector PN Vendor 85205-0270L ACES A1250WV-S-02PC JOINT-TECH Connector type Pin No. Definition 1x2pin header, pitch 1.25mm 3.3V RTC www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 39: Satapw (Sata Power Connector)

    2.2.13 SATAPW (SATA power connector) Pin1 Hard Disk Power Connector Connector PN Vendor 743-81-04TW00 PINREX Connector type 1x4pin header, pitch 2.54mm Pin No. Definition +12V www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 40: Sataiii (Sata 6Gb/S Connector)

    2.2.14 SATAIII (SATA 6Gb/s Connector) Pin1 SATA 6Gb/S Connector Connector PN Vendor WAT3M-07A1G3BU4W WINWIN ABA-SAT-054-S15 LOTES Pin No. Definition www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 41: Fusb2_1, Fusb2_2 (Usb 2.0 Header)

    USB 2.0 Header Connector PN Vendor 210-92-05GB04 PINREX PH10R53BAZ009 HORNGTONG Connector type 9 10 2x5pin header, pitch 2.54mm Pin No. Definition No Pin No Connect www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 42: Gpio_Cnt (General Purpose Input/Output Header)

    PINREX A2004WV-2X06P46 JOINT-TECH Connector type Pin No. Definition 2x6pin header, pitch 2.0mm GPIO-output_1 GPIO-input_1 GPIO-output_2 GPIO-input_2 GPIO-output_3 GPIO-input_3 GPIO-output_4 GPIO-input_4 SMBus Clock SMBus DATA www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 43: Sys_Panel (Front Panel Header)

    2x5pin header, pitch 2.54mm Pin No. Definition HDD LED+ Power LED+ HDD LED- Power LED- Power Button+ Reset Button Power Button- No Connect No Pin www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 44: Mpcie (Mini Pcie Slot)

    PCIE Clock n SIM Clock PCIE Clock p SIM Reset Connector PN Vendor UIM VPP3 AS0B221-S99Q-7H FOXCONN WLAN_DISABLE Reset PCIE RXn 3.3V PCIE RXp SMB Clock www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 45: M2M (M.2 Slot, 2242 M-Key)

    SATA0 TXn 3.3V SATA0 TXp Reset 3.3V 3.3V Pin No. Definition Pin No. Definition 3.3V 3.3V Detect 3.3V 3.3V 3.3V Connector PN Vendor 80159-8521 BELLWETHER www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 46: Sim_Card (3G/4G Sim Slot)

    2.2.20 SIM_CARD (3G/4G SIM Slot) www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 47: Sodimma, Sodimmb (2 X Ddr3L So-Dimm Sockets)

    2.2.21 SODIMMA, SODIMMB (2 x DDR3L SO-DIMM sockets) www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 48: Lan1, Lan2 (Gbe Lan Connectors)

    Orange On 1Gbps data rate Green On 100Mbps data rate 10Mbps data rate Pin No. Definition TX1+ TX1- TX2+ TX2- TX3+ TX3- TX4+ TX4- www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 49: Fusb30 (Usb 3.2 Gen 1 Connector)

    2.2.23 FUSB30 (USB 3.2 Gen 1 connector) USB Connector Pin No. Definition USB3_RX2n USB3_RX2p USB3_TX2n USB3_TX2p Pin No. Definition USB3_RX1n USB3_RX1p USB3_TX1n USB3_TX1p www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 50: Hdmi (Hdmi Connector)

    Pin No. Definition Pin No. Definition Detect Detect TX2p TX2p TX2n TX2n TX1p TX1p TX1n TX1n TX0p TX0p TX0n TX0n CLKp CLKp CLKn CLKn www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 51: Vga (Vga Port)

    2.2.25 VGA (VGA port) D-sub Connector Pin No. Definition Pin No. Definition Green Blue DDCSDA 15 11 HSYNC VSYNC DDCSCL www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 52: Clr_Cmos (Clear Cmos Jumper)

    Normal Operation (Default setting) Close: Clear CMOS data. Connector PN Vendor 210-91-02GBK2 PINREX Pin No. Definition Connector type Clear CMOS 1x2pin header, pitch 2.54mm www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 53: Chapter 3 - Bios

    Chapter 3 Chapter 3 – BIOS www.gigaipc.com...

  • Page 54: Introduction

    Execute command or enter the submenu Increase the numeric value or make ＋ changes Decrease the numeric value or make – changes General Help Previous Values Load Optimized Defaults Settings Save changes & Exit the BIOS Setup program Exit the BIOS Setup program www.gigaipc.com...

  • Page 55: The Main Menu

    TXE FW version Shows ME firmware version Set the Date for the system System Date (Format : Week - Month - Day - Year) Set the time for the system System Time (Format : Hour - Minute - Second) www.gigaipc.com...

  • Page 56: Advanced

    Advanced The Advanced menu is to configure the functions of hardware settings through submenu. Use arrow keys to move among the items, and press <Enter> to access into the related submenu. www.gigaipc.com...

  • Page 57: Tpm Configuration

    3.3.1 TPM Configuration Use TPM Configuration submenu to choose TPM interface. Item Description TPM Device fTPM : Enabled (Default setting), Disabled Selection www.gigaipc.com...
  • Page 58 Item Description Security Device Enabled : Enables TPM feature (Default setting) support Disabled : Disables TPM feature None : No execution will be conducted (Default setting) Pending operation TPM clear : Set to clear data on TPM www.gigaipc.com...

  • Page 59: It8786 Super Io Configuration

    Enabled : Enables allows you to configure the serial port settings Configuration Disabled : if Disabled, displays no configuration for the serial port Serial Port 4 Device settings : Configuration Display the specified Serial Port base I/O address and IRQ www.gigaipc.com...

  • Page 60: Hardware Monitor

    Normal : Fan speed set by BIOS default (Default setting) Control Full Speed : Set Fan operates at full speed CPU temperature Shows current CPU temperature System temperature Shows current system temperature CPU Fan Speed Shows current CPU fan Speed www.gigaipc.com...

  • Page 61: S5 Rtc Wake Settings

    Enable or Disable System to wake on a specific time. Wake system Disabled : Disables system to wake on a specific time (Default setting) from S5 Fixed Time : Enables system to wake on a specific time (Format : hr : min : sec) www.gigaipc.com...

  • Page 62: Cpu Configuration

    Enabled : Enables Turbo Mode (Default setting) Turbo Mode Disabled : Disables Turbo Mode Command CPU to enter into low power consumption mode when CPU is under idle mode. C-states Enabled : Enables C states (Default setting) Disabled : Disables C states www.gigaipc.com...

  • Page 63: Sata Configuration

    Description SATA Mode AHCI : Configures the SATA controllers to AHCI mode. (Default setting) Selection eMMC Information shows eMMC information (This item will only appears in model QBiP-4200D) SATA shows 2.5" SATA HDD/SSD information shows M.2 SATA interface SSD information...

  • Page 64: Ami Graphic Output Protocol Policy

    3.3.7 AMI Graphic Output Protocol Policy Item Description Choose default monitor output when there are more than one monitor plugged Output Select on the motherboard. www.gigaipc.com...

  • Page 65: Csm Configuration

    Item Description CSM Support Never : UEFI Mode only (Default setting) When system is power on, install LAN driver under UEFI mode. LAN EFI driver Disabled : Disables UEFI Network Stack (Default setting) Enabled : Enables UEFI Network Stack www.gigaipc.com...

  • Page 66: Digital Io Port Configuration

    SOGPI_1 (Pin 2) SOGPI_2 (Pin 4) Configure Digital IO Input values for each pin. SOGPI_3 (Pin 6) SOGPI_4 (Pin 8) SOGPO_1 (Pin 1) SOGPO_2 (Pin 3) Configure Digital IO Output values for each pin. SOGPO_3 (Pin 5) SOGPO_4 (Pin 7) www.gigaipc.com...

  • Page 67: Chipset

    Disabled : Disables LVDS Support (Default setting) LVDS Support Enabled : Enables LVDS Support To modified the backlight brightness of the LVDS panel Brightness Level Option items : 10%, 20%, 30%, 40%, 50%, 60%, 70%, 80%, 90%, 100% (Default Setting) www.gigaipc.com...
  • Page 68 Enable/Disable Watchdog Timer function WatchDog Timer Enabled : Enables Watchdog Timer function Disabled : Disabled Watchdog Timer function (Default setting) Enable/Disable BIOS Lock function BIOS Lock Enabled : Enables BIOS Lock function (Default setting) Disabled : Disabled BIOS Lock funtion www.gigaipc.com...

  • Page 69: Security

    To set up Administrator's password Administrator Minimum length : 3 Password Maximum length : 20 To set up User's password User Password Minimum length : 3 Maximum length : 20 Secure Boot Press <Enter> to configure the advanced items www.gigaipc.com...
  • Page 70 Enabled : Enables Secure Boot control function Standard : Standard mode Secure Boot Mode Custom : Custom mode (Default setting) Enables expert users to modify Secure boot policy variables without full Key Management authentication Press <Enter> to configure the advanced items www.gigaipc.com...
  • Page 71 Save NVRAM content of all Secure boot varaiables to the files in root folder variables on a target file system device Item Description Platform Key (PK) Key Exchange Keys Authorized Signatures These items allows you to enroll factory defaults or load Certificates from a file. Forbidden Signatures Authorized TimeStamps OsRecovery Signatures www.gigaipc.com...

  • Page 72: Boot

    Enabled : Enables Full screen LOGO Show on POST screen LOGO Show Disabled : Disables Full screen LOGO Show on POST screen (Default setting) Boot Option #1 Shows the information of the storage that be installed in the system Boot Option #2 Choose/set the boot priority www.gigaipc.com...

  • Page 73: Save & Exit

    Yes : Agree to discard changes and reset and Reset No : Cancel to discard changes and reset Restore/Load default values for all the setup options Restore Defaults Yes : Agree to load optimized defaults No : Cancel to load optimized defaults www.gigaipc.com...
