Modification Instruction
MI_2090: Installation energy optimisation board
iVario 2-XS, iVario Pro 2-S
Standard
1
MI_2090: Installation energy optimisation board
High voltages when connecting to the mains power
Danger to life due to high voltage.
Disconnect from the power supply.
n
Make sure the cooking system is disconnected from the power.
n
Electric shock from incorrect connection
There is a danger to life if the wires are incorrectly connected.
Connect the wires correctly according to their colour coding.
Sharp edges on the housing
Risk of cuts on the housing when working in the electrical compartment.
Wear protective gloves.
DANGER
DANGER
CAUTION
2020 / 90
45 minutes
16.10.2024
1 / 16

Advertisement

loading
Need help?

Need help?

Do you have a question about the iVario 2-XS and is the answer not in the manual?

Questions and answers

Related Manuals for Rational iVario 2-XS

Summary of Contents for Rational iVario 2-XS

  • Page 1 2020 / 90 Modification Instruction MI_2090: Installation energy optimisation board iVario 2-XS, iVario Pro 2-S 45 minutes Standard 16.10.2024 MI_2090: Installation energy optimisation board DANGER High voltages when connecting to the mains power Danger to life due to high voltage.
  • Page 2 1 | MI_2090: Installation energy optimisation board Overview Parts included in the energy optimization conversion kit for the and : Energy optimisation conversion kit, article number: 87.01.813S Energy optimisation board Mount energy optimisation board 3 x through clamps 4 mm² grey Cable trunk W59 Terminal block 6 mm yellow-green...
  • Page 3 1 | MI_2090: Installation energy optimisation board Mounting the cable gland The cable gland is required for the subsequent cable of the energy optimisation control. The cooking system is disconnected from the power. The cable gland is ready for use. Open the electrical compartment, as described in the original installation manual for the cooking systems iVario / iVario Pro in section Opening the electrical compartment .
  • Page 4 1 | MI_2090: Installation energy optimisation board Installing clamps 1. Place the yellow-green terminal block on the blue N-terminal in the cook- ing system. Attach the end plate below the three through clamps and as- semble them bundled onto the yellow-green terminal block. NOTICE Note that the end plate serves to separate the three through clamps and the terminal block.
  • Page 5 1 | MI_2090: Installation energy optimisation board Installing the energy optimisation board NOTICE Damage to the cable trunk and the control panel when removing the control panel The control panel is connected to the installation compartment by a cable trunk. Remove the control panel carefully in order not to damage the cable trunk.
  • Page 6 1 | MI_2090: Installation energy optimisation board 2. Place the board in the mounting slots (1) and place the board on the board retaining clips (2). 3. For cooking system size install the mount with 4 board retaining clips on the underside of the I/O board carrier.
  • Page 7 1 | MI_2090: Installation energy optimisation board 4. For cooking system size install the mount with 4 board retaining clips on the top of the I/O board carriers. 5. Insert the cables of the cable trunk W32 and screw them together: Wire colour Connector terminal 6T3 on the contactor...
  • Page 8 1 | MI_2090: Installation energy optimisation board Wire colour Connector terminal White Black Purple Grey Brown Orange Blue Yellow/green 6. Use the cable trunk W59 to connect connection X429 on the energy op- timisation board to connection X29 on the I/O board. 7.
  • Page 9 1 | MI_2090: Installation energy optimisation board 8. Close the electrical compartment, as described in the original installation manual iVario / iVario Pro in section Closing the electrical compartment . >> The energy optimisation board is installed. 9 / 16...
  • Page 10 1 | MI_2090: Installation energy optimisation board Activating the energy optimisation option The cable gland for the energy optimisation board is installed. The energy optimisation board is installed. 1. Switch the cooking system on. Go to the service level. 2. Open the Options page under the Service settings (1). 3.
  • Page 11 1 | MI_2090: Installation energy optimisation board Connection to an external energy optimisation OPTION Energy optimising D PE 1. Option energy optimising appliance Request for heat output of Request on B1 Request on B2 cooking system 50 % 230 V 100 % 230 V 230 V...
  • Page 12 1 | MI_2090: Installation energy optimisation board Optimization: 50 % or 100 % Heating output approved Feedback on C1 Feedback on C2 by the energy optimiser 50 % 230 V 100 % 230 V 230 V Optimization: 0 % or 100 % Heating output approved Feedback on C1 Feedback on C2...
  • Page 13 1 | MI_2090: Installation energy optimisation board NOTICE To ensure optimal cooking results, do not reduce the heating for more than 10 seconds per minute. 13 / 16...
