Brink Flair 225 Installation Regulations

Hide thumbs Also See for Flair 225:

Advertisement

Quick Links

Download this manual
Installation regulations
Flair 225
English

Advertisement

loading
Need help?

Need help?

Do you have a question about the Flair 225 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Brink Flair 225

Summary of Contents for Brink Flair 225

  • Page 1 Installation regulations Flair 225 English...
  • Page 3 Children may not play with the appliance. If you need a new power cable, always order the replacement from Brink Climate Systems B.V. To prevent dangerous situations, a damaged mains connection must only...
  • Page 4 Contents 1 Scope of delivery ......5 11.4 Connecting CO₂ sensor(s) ... . . 41 1.1 Scope of delivery .
  • Page 5 1. Heat recovery appliance 2. Wall mounting bracket consisting of: ▪ 1x mounting bracket ▪ ▪ 2x protective caps ▪ ▪ 2x rubber strip ▪ ▪ 2x rubber rings ▪ 3. Waterless P-trap 4. Installation instructions Flair 225 617261-D Brink / 5...
  • Page 6 These installation instructions describe both the standard Flair 225 and the Flair with (Plus) PCB. The Flair 225 is available in Left-hand and Right-hand versions; it is not possible to convert the left and right- hand models into one another.
  • Page 7 In practice the value may differ by 1dB(A) through measurement tolerances. Note The stated value in the circles below indicate the capacity (in Watt) per fan. Resistance of duct system [Pa] Flow rate [m Flair 225 617261-D Brink / 7...
  • Page 8 3.2 Connections and dimensions The Flair 225 appliance is available in a left-hand and right-hand version. Left-hand version: ▪ The “warm” connections supply air (1) and Extract air (3) are on the left-hand side of the appliance. ▪ ▪ The condensate discharge is located at the right-hand side on the bottom of the appliance.
  • Page 9 Diameter of all collars is 125 mm - 4.9'' Supply air Electrical connections Exhaust air Siphon connection Sealing cap unused condensate discharge connection Extract Do not remove! Outdoor air Extract air filter Supply air filter Flair 225 617261-D Brink / 9...
  • Page 10 Relay output (X19) ) Temperature sensor 24 volt connector (X18) Supply filter eBus connector (X17) Exhaust fan 24 volt connector (X16) Siphon / P-trap Modbus/ Internalbus connector (X15) Supply ventilator Multiple switch connector (X14) Brink / 10 Flair 225 617261-D...
  • Page 11 There are several options for external control : ▪ 4-way switch ( ® Connecting 4 position switch -> page 37 ), ▪ ▪ Brink Touch Control ( → Connecting Touch Control -> page 39 ) ▪ ▪ CO sensor(s) ( ®...
  • Page 12 WiFi signal. 1 = For example a Flair 325 appliance with mounted Basic pcb 2 = Optional Plus pcb mounting plate 3 = Optional Plus pcb 4 = Optional Plus pcb cover Brink / 12 Flair 225 617261-D...
  • Page 13 5.2 Placing the appliance The Flair 225 appliance can be mounted onto a wall with the supplied mounting bracket. For a vibration-free installation, the appliance must be mounted to a solid wall with a minimum mass of 170 kg/m (16lbs/cf) .
  • Page 14 5.3 Connecting the condensate discharge The condensate discharge line for the Flair 225 is located in the bottom panel. The condensate is discharged through the drainpipe. The P-trap (with built-in air vent) is supplied separately with the appliance and must be fitted by the installer below the appliance (bayonet connection).
  • Page 15 The location of the supply valves must be chosen in such a way to prevent fouling and drafts. We recommend using Brink supply valves. Ensure that air can flow from supply to exhaust diffusers, by means of undercut doors (minimum gap 2cm, 3/4'') or air transfer grilles between rooms.
  • Page 16 1 = Flair appliance right-hand version (place level) 2 = Preferred location outdoor air inlet 3 = Sewer vent 4 = Preferred location Exhaust air outlet; Use Brink insulated ventilation roof terminal 5 = Thermally insulated ducts 6 = Condensate discharge...
  • Page 17 For connecting an eBus accessory, use the 2-pole detachable (green) connector X17 located at the rear of PCB. The eBus protocol can be used to connect: ▪ Brink Air Control ( ® ). ▪ ▪ Brink Touch Control ( →...
  • Page 18 See ® Electrical diagram -> page 35 for correct connections and correct settings of the jumpers on the PCB. For more information and the correct modBus settings, please consult the Modbus manual on the website. Brink / 18 Flair 225 617261-D...
  • Page 19 = Secondairy appliances (For example a Flair appliance type 4-0); connect max. of 10 appliances via Internal Bus. All Flair 225 appliances have the same air flow rate as the appliance that is set as "Primary". The fault messages of all appliances are shown on the display of the Primary appliance and shown on the display of the relevant appliance.
  • Page 20 * Filter message and fault message are located in the same place on the display; fault display has a higher priority, and so will always be shown first even when there is an active filter message! Brink / 20 Flair 225 617261-D...
  • Page 21 "Cleaning filter" ( ® Cleaning filters -> page 30 ) for more information. This symbol is shown if a fault has occurred in the appliance; see chapter Faults ( Storingsanalyse ) for more information. Flair 225 617261-D Brink / 21...
  • Page 22 This appliance is set as Primary appliance if a number of appliances are connected (cascade) Appliance is set as secondary appliance; a maximum of 9 appliances can be connected to a Primary appliance. Control via eBus for example Brink Touch Control . Control via ModBus or Internal Bus. Bypass boost is active.
  • Page 23 Zone Symbol on display Description Internet connection/Network connection Signal strength USB connection active. 11:07 Current set time of the device. 02.01.2020 Current date. Flair 225 617261-D Brink / 23...
  • Page 24 - after which it will go back to it's prior flow (flow 1 or 0). ▪ If the display is set as "manual" 4 position switch; The appliance will keep running in the selected mode until ▪ another mode is chosen. Brink / 24 Flair 225 617261-D...
  • Page 25 1 and 3 depending on the measured PPM values: for a connected humidity sensor the air flow will be switched to mode 3 when this is needed. Flair 225 617261-D Brink / 25...
  • Page 26 Changes can be carried out in the settings menu. Warning Incorrect settings affect the performance of the appliance. Changes of settings not described in this manul require consultation with Brink Climate Systems B.V. 7.4 Factory settings Note A factory reset does no reset the filter message.
  • Page 27 Contact the installer when a locking fault occurs. 1. Supply fan defective Note A locking fault will not be resolved by resetting the power supply of the appliance; first the fault has to be solved. Flair 225 617261-D Brink / 27...
  • Page 28 Check wiring to touchscreen; replace wiring general fault message visible when if damaged; replace touchscreen if fault still occurs replace using service tool UWA2-B Fault is automatically reset when voltage is again put back on appliance.. Brink / 28 Flair 225 617261-D...
  • Page 29 Brink Air Control Check wiring to accessories/ Brink Air Control message and other Check accessories/ Brink Air Control and replace if defective accessories do If there is still a fault after this: Take voltage from appliance not work. and replace basic pcb UWA2-B...
  • Page 30 ▪ 9.2 Maintenance P-trap Danger Disconnect the power supply when working on the appliance. The P-trap must be removed, cleaned and reinstalled at least once a year. (For example a Flair appliance type 4-0). Brink / 30 Flair 225 617261-D...
  • Page 31 Installer maintenance includes cleaning the heat exchanger, internal preheater and fans. Dependent on the conditions, this must done about once every three years. Remove the power supply by pulling out the plug. Open the filter door. Remove the two filters. Remove the front cover. Flair 225 617261-D Brink / 31...
  • Page 32 Clean the heat exchanger only by rinsing it with warm water (max. 45°C) and common detergent. Then rinse with warm water. Take EPS assembly, with which the fan is inserted into the appliance, out of the appliance. Brink / 32 Flair 225 617261-D...
  • Page 33 Rotate the fan as indicated below. Tilt and remove the fan partly out of the appliance, disconnect both fan cables. Take the fan out of the appliance. Repeat steps 6 to 9 for the other fan in the appliance. Flair 225 617261-D Brink / 33...
  • Page 34 Reset the timer of the filter message by setting to zero in the settings menu at step number 4.3. After resetting the timer of the filter message the appliance returns to the main menu and the appliance is ready for use. Brink / 34 Flair 225 617261-D...
  • Page 35 10 Electrical diagram Flair 225 617261-D Brink / 35...
  • Page 36 = USB stick for updating software (not supplied with appliance) X18 = 24V (max 5VA) = Service connector X19 = Signal output = Laptop with installed Brink service tool (not supplied) (Plus) pcb = Touchscreen on appliance = Valve motor bypass valve...
  • Page 37 C = Modular cable: Note: For the modular cable that is used, the “tab” of both modular connectors must be mounted facing the mark on the modular cable. Wire colors C1 - C6 may vary dependent on the type of modular cable used. Flair 225 617261-D Brink / 37...
  • Page 38 = Modular cable: Note: For the modular cable that is used, the “tab” of both modular connectors must be mounted facing the mark on the modular cable. Wire colors C1 - C6 may vary dependent on the type of modular cable used. Brink / 38 Flair 225 617261-D...
  • Page 39 F = Position of green eBus socket at rear of appliance PCB Warning The combined use of the accessories: Touch Control, additional preheater and postheater is not possible due to the voltage limit of the eBus system. Flair 225 617261-D Brink / 39...
  • Page 40 4 = The cable that comes with RH sensor 5 = RH (humidity) sensor 6 = Duct from dwelling To switch on and set the sensitivity of the humidity sensor, go to step number 7.1 and 7.2 in the settings menu Brink / 40 Flair 225 617261-D...
  • Page 41 CO measurements or based on a time program. Two different sets are available for this. Manual operation with the aid of an extra Flair 225 617261-D Brink / 41...
  • Page 42 A = Zone valve demand-driven ventilation C1 = brown B = Power 24 VDC C2 = blue C = Brink Air Control C3 = green/yellow D = Valve motor zone valve C5 = white E = EBus connection X17 on Flair appliance...
  • Page 43 4 = Temperature sensor C3 = green/yellow C4 = black 5 = PCB type UVP1 C5 = white 6 = Airflow direction 7 = Dipswitch setting Flair postheater (For example a Flair appliance type 4-0) Flair 225 617261-D Brink / 43...
  • Page 44 4 = Temperature sensor C3 = green/yellow C4 = black 5 = PCB type UVP1 C5 = white 6 = Airflow direction 7 = Dipswitch setting Flair preheater (For example a Flair appliance type 4-0) Brink / 44 Flair 225 617261-D...
  • Page 45 25°C, 77°F 15.0°C / 40.0 °, 59°F / 104°FC 11.4 Mode valve 10 volt control Closed Open / Closed Relay output 1/Relay output 2/ 11.5 Valve control Relay output 1 Analogue output 1/Analogue output 2 Flair 225 617261-D Brink / 45...
  • Page 46 Note Appliance type, serial number and year of production are stated on the identification plate behind the plastic front panel on the appliance. Example Appliance type Flair 225 (Plus) Serial number 428000220201 Year of production 2024 Part...
  • Page 47 12.2 Service articles Flair 225 617261-D Brink / 47...
  • Page 48 The power cable is fitted with a circuit board connector. When replacing it, always order a replacement mains cable from Brink. To prevent dangerous situations, a damaged mains connection can only be replaced by a qualified expert. Brink / 48 Flair 225 617261-D...
  • Page 49 13 Settings 13.1 Setting values standard appliance Flair 225-appliance without (Plus) pcb. Step Factory Description Setting range Comment settings Flow rate Air flow rate setting 0 40 m³/h 0 or adjustable between 40 m³/h and 225 m³/h (23CFM) (23-133CFM) (never higher than step no. 1.2) Air flow rate setting 1 50 m³/h...
  • Page 50 0 / 9 (0=Primary; 1 t/m 9 = Repeater 1 t/m repeater 9) Central heating + heat recovery 12.1 Status On / Off Network 13.1 Set up WiFi network 13.2 Sign up Brink Home Enter password Brink / 50 Flair 225 617261-D...
  • Page 51 Yes / No Signal output 16.1 Signal output External Off / Only filter condition / Only fault condition / Connector X19 contact 24V Filter and fault condition/ 24V Standby 17.1 Switch off appliance Yes / No Flair 225 617261-D Brink / 51...
  • Page 52 13.2 Setting values appliance with (Plus) pcb The below setting values are for a Flair 225-appliance with (Plus) pcb. Step Description Factory settings Setting range Comment Switch contacts Make or break contact 1 Make Make / Break Switch contact control 1...
  • Page 53 15.0°C / 40.0 °C, 59°F / 104°F 11.4 Mode valve 24 volt control Closed Open / Closed 11.5 Valve control Relay output 1 Relay output 1/ Relay output 2/ Analogue output 1/ Analogue output 2 Flair 225 617261-D Brink / 53...
  • Page 54 14 Conformity declaration This declaration of conformity is issued under the sole responsibility of the manufacturer. Manufacturer: Brink Climate Systems B.V. Postbus 11 Address: NL-7950 AA, Staphorst, The Netherlands Product: Flair 225 The product described above complies with the following directives: ¨...
  • Page 55 15 ERP values Technical information sheet Flair 225 in accordance with Ecodesign (ErP), no. 1254/2014 (Annex IV) Manufacturer: Brink Climate Systems B.V. Model: Flair 225 Climate Type of control SEC Value in Annual Annual heating zone kWh/m²/a Class electricity saved (AHS) in...
  • Page 56 A+ (Most efficient) SEC < -42 -42 ≤ SEC < -34 -34 ≤ SEC < -26 -26 ≤ SEC < -23 -23 ≤ SEC < -20 G (Least efficient) -20 ≤ SEC < -10 Brink / 56 Flair 225 617261-D...
  • Page 57 1. Dispose of packaging made of cardboard, recyclable plastics and synthetic filler materials in an environmentally compatible manner through appropriate recycling systems or a recycling center. 2. Please observe the applicable national and local regulations. Flair 225 617261-D Brink / 57...
  • Page 60 Brink Climate Systems B.V. Wethouder Wassebaliestraat 8, NL-7951SN Staphorst T: +31 (0) 522 46 99 44 E. info@brinkclimatesystems.nl www.brinkclimatesystems.nl...
