Summary of Contents for Brink Flair 450 Enthalpy
- Page 1 Installation regulations Flair 450/600 Enthalpy English...
- Page 3 Children may not play with the appliance. If you need a new power cable, always order the replacement from Brink Climate Systems B.V. To prevent dangerous situations, a damaged mains connection must only...
-
Page 4: Table Of Contents
5.2 Placing the appliance....15 15 ERP values Flair 450 Enthalpy....58 5.3 Connecting air ducts. -
Page 5: Scope Of Delivery
▪ 2x protective caps ▪ ▪ 2x rubber strip ▪ ▪ 3x rubber rings ▪ ▪ 1x washer ▪ 3. Documentation set consisting of: ▪ 1x short installation instructions ▪ ▪ 1x occupant's instructions ▪ Flair 450/600 Enthalpy 617561-A Brink / 5... -
Page 6: General
▪ ▪ Constant flow control ▪ The Flair 450/600 Enthalpy is available in two types: ▪ the "Flair 450 Enthalpy" ▪ ▪ the “Flair 600 Enthalpy” ▪ For al the Flair 450/600 Enthalpy there is an optional Plus PCB available with more functions/ connection possibilities (>... -
Page 7: Technical Specifications
3 Technical specifications 3.1 Technical information Flair 450 Enthalpy Flair 450 (Plus) Supply voltage [V/Hz] 230V/50Hz Dimensions (w x h x d) [mm] 850 x 800 x 660 Duct diameter [mm] ø200 Weight [kg] 57,5 Filter class ISO Coarse 60% (ISO ePM1.0 50% for the air supply optional) Fan setting (factory setting) Factory setting [m³/h]... -
Page 8: Technical Information Flair 600 Enthalpy
42.5 51.0 52.0 53.5 56.5 Duct ‘To dwelling’ [db(A)] 43.5 53.0 53.5 60.5 61.5 62.0 66.6 *) Duct noise including end correction In practice the value may differ by 1dB(A) through measurement tolerances. Brink / 8 Flair 450/600 Enthalpy 617561-A... - Page 9 Resistance of duct Note: system [Pa] The stated value in the circle is the capacity (in Watt) per fan. Flow rate [m Flair 450/600 Enthalpy 617561-A Brink / 9...
-
Page 10: Connections And Dimensions
All dimensions in millimeters. Diameter of all collars is 200 mm Supply air Exhaust air Extract air Outdoor air Electrical connections Sealing cap Sealing cap Extract air filter Supply air filter Mounting bracket Brink / 10 Flair 450/600 Enthalpy 617561-A... - Page 11 All dimensions in millimeters. Diameter of all collars is 200 mm To dwelling Exhaust air Extract air Outdoor air Electrical connections Sealing cap Sealing cap Extract air filter Supply air filter Mounting bracket Flair 450/600 Enthalpy 617561-A Brink / 11...
-
Page 12: Exploded View Of Appliance
Signal output (X19) ) Temperature sensor (2x) 24 volt connector (X18) Supply filter eBus connector (X17) Exhaust fan 24 volt connector (X16) Sealing cap Modbus/ internal bus connector (X15) Supply fan Multiple switch connector (X14) Brink / 12 Flair 450/600 Enthalpy 617561-A... -
Page 13: Operation
Connecting multi-position switch with filter indication -> page 38, Connecting multi- ▪ position switch -> page 37 ), ▪ Brink Air Control ( ® Connecting Air Control -> page 43 ) ▪ ▪ CO sensor(s) ( ® Connecting CO₂ sensor(s) ->... -
Page 14: Frost Protection
WiFi signal. 1 = For example a Flair 325 appliance with mounted Basic pcb 2 = Optional Plus pcb mounting plate 3 = Optional Plus pcb 4 = Optional Plus pcb cover Brink / 14 Flair 450/600 Enthalpy 617561-A... -
Page 15: Installation
▪ Make sure there is a free space of at least 70 cm at the front of the appliance and a free headroom of 1.8 m. ▪ ▪ Make sure there is a free space of at least 25 cm above the appliance, for connecting the appliance and any ▪ necessary servicing of the circuit board. Flair 450/600 Enthalpy 617561-A Brink / 15... -
Page 16: Connecting Air Ducts
The location of the input valves must be chosen in such a way to prevent fouling and drafts. We recommend using Brink Climate Systems B.V. input valves. When using flexible mufflers, account must be taken during the installation that these may need to be replaced after a period of time. -
Page 17: Electrical Connections
1 = Flair 450/600 Enthalpy right-hand version (place level) 2 = Preferred ventilation air supply 3 = Sewer release 4 = Preferred location of ventilation air discharge; Use Brink insulated ventilation roof sleeve 5 = Thermally insulated piping 6 = Sound absorber(s) 7 = Duct to and from house 5.4 Electrical connections... -
Page 18: Connecting An Ebus Accessory
For connecting an eBus accessory, use the 2-pole detachable (green) connector X17 located at the rear of PCB. The eBus protocol can be used to connect: ▪ Brink Air Control ( ® Connecting Air Control -> page 43 ). - Page 19 Electrical diagram -> page 35 for correct connections and correct settings of the jumpers on the PCB. For more information and the correct modBus settings, please consult the Modbus manual on the website. Flair 450/600 Enthalpy 617561-A Brink / 19...
-
Page 20: Coupling Appliances Using Internal Bus
"Master". The fault messages of all appliances will be shown on the display of the master appliance as well as on the display of the relevant appliance. When using a Brink Air Control or the BrinkHome, always connect this to the Master. -
Page 21: Display
* Filter message and fault message are located in the same place on the display; fault display has a higher priority, and so will always be shown first even when there is an active filter message! Flair 450/600 Enthalpy 617561-A Brink / 21... -
Page 22: Display Layout
-> page 30 ) for more information. This symbol is shown if a fault has occurred in the appliance; see chapter Faults ( Storingsanalyse Fault analysis -> page 28 ) for more information. Brink / 22 Flair 450/600 Enthalpy 617561-A... - Page 23 This appliance is set as Primary appliance if a number of appliances are connected (cascade) Appliance is set as secondary appliance; a maximum of 9 appliances can be connected to a Primary appliance. Control via eBus for example Brink Air Control . Control via ModBus or internal Bus. Bypass boost is active.
- Page 24 Zone Symbol on display Description Internet connection/Network connection Signal strength USB connection active. 11:07 Current set time of the device. 02.01.2020 Current date. Brink / 24 Flair 450/600 Enthalpy 617561-A...
-
Page 25: Display Information
- after which it will go back to it's prior flow (flow 1 or 0). ▪ If the display is set as "manual" 4 position switch; The appliance will keep running in the selected mode until ▪ another mode is chosen. Flair 450/600 Enthalpy 617561-A Brink / 25... -
Page 26: Setting To Work
1 and 3 depending on the measured PPM values: for a connected humidity sensor the air flow will be switched to mode 3 when this is switched on. Brink / 26 Flair 450/600 Enthalpy 617561-A... -
Page 27: Other Settings For Installer
Changes can be carried out in the settings menu. Warning Incorrect settings affect the performance of the appliance. Changes of settings not described in this manul require consultation with Brink Climate Systems B.V. 7.4 Factory settings Flair 450/600 Enthalpy 617561-A... -
Page 28: Fault
Replace NTC sensor or replace wiring E111 E1400 RHT sensor 1 defective; No humidity Check wiring general message / USB control Replace RHT sensor or replace wiring/ insert USB transceiver transceiver removed Brink / 28 Flair 450/600 Enthalpy 617561-A... - Page 29 Brink Air Control Check wiring to accessories/ Brink Air Control message and other Check accessories/ Brink Air Control and replace if defective accessories do If there is still a fault after this: Take voltage from appliance not work. and replace basic pcb UWA2-B...
-
Page 30: Maintenance
▪ Go to step number 4.2 in the settings menu to manually start the filter wizard and follow the instructions. ▪ Direct reset of Filter message timer: ▪ Go to step number 4.3 in the settings menu to reset the filter timer directly without opening the filter wizard. ▪ Brink / 30 Flair 450/600 Enthalpy 617561-A... -
Page 31: Maintenance Installer
Installer maintenance includes cleaning the heat exchanger, internal preheater and fans. Dependent on the conditions, this must done about once every three years. Remove the power supply by pulling out the plug. Open the filter door. Remove the two filters. Remove the front cover. Flair 450/600 Enthalpy 617561-A Brink / 31... - Page 32 Clean the heat exchanger only by rinsing it with warm water (max. 45°C) and common detergent. Then rinse with warm water. Take EPS assembly, with which the fan is inserted into the appliance, out of the appliance. Brink / 32 Flair 450/600 Enthalpy 617561-A...
- Page 33 Turn the fan a quarter of a revolution in the appliance. Tilt the fan in such a way that this can be taken out of the EPS assembly; disconnect both fan cables from the fan. Now take the fan out of the appliance. Flair 450/600 Enthalpy 617561-A Brink / 33...
- Page 34 Reset the timer of the filter message by setting the timer back to zero in the settings menu at step number 4.3. After resetting the timer of the filter message the appliance returns to the main menu and the appliance is once again ready for use. Brink / 34 Flair 450/600 Enthalpy 617561-A...
-
Page 35: Electrical Diagram
10 Electrical diagram Flair 450/600 Enthalpy 617561-A Brink / 35... - Page 36 USB stick for updating software (not supplied with appliance) X18 = 24V (max 5VA) Service connector X19 = Signal output Laptop with installed Brink service tool (not supplied) (Plus) pcb Touchscreen on appliance Valve motor bypass valve X03 = 24V...
-
Page 37: Electrical Connections Accessories
It is best to use a 4-way switch with filter indication; always install an RJ12 connector in combination with a 6- core modular cable. When using a 3-way switch without filter indication always install an RJ11 connector in combination with a 4-core modular cable. Flair 450/600 Enthalpy 617561-A Brink / 37... -
Page 38: Connecting Multi-Position Switch With Filter
For the modular cable that is used, the “tab” of both modular connectors must be mounted facing the mark on the modular cable. Wire colors C1 - C6 may vary dependent on the type of modular cable used. Brink / 38 Flair 450/600 Enthalpy 617561-A... -
Page 39: Connecting Wireless Remote Control (Without Filter Indication)
For the modular cable that is used, the “tab” of both modular connectors must be mounted facing the mark on the modular cable. Wire colors C1 - C6 may vary dependent on the type of modular cable used. Flair 450/600 Enthalpy 617561-A Brink / 39... -
Page 40: Connecting Extra Multi-Position Switch With Filter Indication
For the modular cable that is used, the “tab” of both modular connectors must be mounted facing the mark on the modular cable. Wire colors C1 - C6 may vary dependent on the type of modular cable used. Brink / 40 Flair 450/600 Enthalpy 617561-A... -
Page 41: Connecting Extra Multiple-Position Switch With Filter Indication
For the modular cable that is used, the “tab” of both modular connectors must be mounted facing the mark on the modular cable. Wire colors C1 - C6 may vary dependent on the type of modular cable used. Flair 450/600 Enthalpy 617561-A Brink / 41... -
Page 42: Connection Wireless Controllers & Sensors
11.1.5 Connection wireless controllers & sensors Brink product range consists of various wireless remote controls and sensors that are able to communicate with a heat recovery unit appliance through a USB tranceiver. (HRU). This range consists of the 5 following types of wireless controllers/sensor (A-E). -
Page 43: Connecting Air Control
E = Position green eBus connector to rear of control Warning The combined use of the three accessories: air control, additional preheater and postheater is not possible due to the voltage limit of the eBus system. Flair 450/600 Enthalpy 617561-A Brink / 43... -
Page 44: Connecting Humidity Sensor
E = RH (humidity) sensor F = Duct from dwelling Note To switch on and set the sensitivity of the humidity sensor, go to step number 7.1 and 7.2 in the settings menu Brink / 44 Flair 450/600 Enthalpy 617561-A... -
Page 45: Connecting Co₂ Sensor(S)
6.1 in the settings menu ; in order to set the minimum and maximum PPM value of the CO sensor(s) set, if necessary, the right values following step numbers 6.2 to 6.9. Flair 450/600 Enthalpy 617561-A Brink / 45... -
Page 46: Connecting Postheater
F = Airflow direction G = Dipswitch setting Flair postheater Note If a post-heater is used, set at least 75m³/h at Parameter step 1.1 to prevent overheating. (For example a Flair 325 appliance type 4-0) Brink / 46 Flair 450/600 Enthalpy 617561-A... -
Page 47: Connecting Preheater
D = Temperature sensor C3 = green/yellow C4 = black E = PCB type UVP1 C5 = white F = Airflow direction G = Dipswitch setting Flair preheater (For example a Flair 325 appliance type 4-0) Flair 450/600 Enthalpy 617561-A Brink / 47... -
Page 48: Connecting Geo-Heat Exchanger
Switch temperature 2 25°C 15.0°C / 40.0 °C 11.4 Mode valve 10 volt control Closed Open / Closed Relay output 1/Relay output 2/ 11.5 Valve control Relay output 1 Analogue output 1/Analogue output 2 Brink / 48 Flair 450/600 Enthalpy 617561-A... -
Page 49: Service Parts
Appliance type, serial number and year of production are stated on the identification plate behind the plastic front panel on the appliance. Example Appliance type Flair 450/600 Enthalpy (Plus) Serial number 432000241201 Year of production 2024 Part Article code 533037 Quantity 12.2 Service articles Flair 450/600 Enthalpy 617561-A Brink / 49... - Page 50 Article description Article code Front panel complete Flair 450 532828 Front panel complete Flair 600 532826 Filters (2 items) ISO Coarse 60% 532821 Brink / 50 Flair 450/600 Enthalpy 617561-A...
- Page 51 The power cable is fitted with a circuit board connector. When replacing it, always order a replacement mains cable from Brink. To prevent dangerous situations, a damaged mains connection can only be replaced by a qualified expert. Flair 450/600 Enthalpy 617561-A Brink / 51...
-
Page 52: Settings
Bypass temperature “from 10°C 7 °C / 15 °C outside” Bypass hysteresis 2 °C 0 °C / 5 °C Mode Bypass boost On / Off Fan setting selection Bypass 0 / 3 boost Brink / 52 Flair 450/600 Enthalpy 617561-A... - Page 53 -2 = least sensitive Cascade 0 / 9 Appliance setting 0 (Master) (0=Master; 1 t/m 9 = Slave 1 t/m Slave 9) Central heating + heat recovery 12.1 Status On / Off Network Flair 450/600 Enthalpy 617561-A Brink / 53...
- Page 54 Step Factory Description Setting range Comment settings 13.1 Set up WiFi network 13.2 Sign up Brink Home Enter password IP address Default gateway Subnet Mask Primary DNS 13.3 Secundary DNS Name Home Module Destination Server-IP Destination Server-port Change destination server 13.4...
-
Page 55: Setting Values Appliance With (Plus) Pcb
Fan runs at absolute minimum Fan at setting 1 Fan at setting 2 Fan at setting 3 Fan at step 0 Fan according to multi-position switch Fan runs at absolute maximum No exhaust fan control Flair 450/600 Enthalpy 617561-A Brink / 55... - Page 56 25 °C 15.0°C / 40.0 °C 11.4 Mode valve 24 volt control Closed Open / Closed 11.5 Valve control Relay output 1 Relay output 1/ Relay output 2/ Analogue output 1/ Analogue output 2 Brink / 56 Flair 450/600 Enthalpy 617561-A...
-
Page 57: Conformity Declaration
14 Conformity declaration Manufacturer: Brink Climate Systems B.V. P.O. Box 11 Address: NL-7950 AA, Staphorst, The Netherlands Product: Heat recovery appliance type: Flair 450 Enthalpy Flair 600 Enthalpy The product described above complies with the following directives: ¨ 2014/30/EU (OJEU L 96/79; 29-03-2014) (OJEU L 96/357;... -
Page 58: Erp Values Flair 450 Enthalpy
External 1.30% Position dirty filter On the display of the appliance / on the multiple switch (LED) / on the Brink Air Control. Attention! For optimal energy efficiency and a proper operation, a regular filter inspection, indication: cleaning or replacement is necessary. - Page 59 A+ (Most efficient) SEC < -42 -42 ≤ SEC < -34 -34 ≤ SEC < -26 -26 ≤ SEC < -23 -23 ≤ SEC < -20 E (Least efficient) -20 ≤ SEC < -10 Flair 450/600 Enthalpy 617561-A Brink / 59...
-
Page 60: Erp Values Flair 600 Enthalpy
External 1.00% Position dirty filter On the display of the appliance / on the multiple switch (LED) / on the Brink Air Control. Attention! For optimal energy efficiency and a proper operation, a regular filter inspection, indication: cleaning or replacement is necessary. - Page 61 A+ (Most efficient) SEC < -42 -42 ≤ SEC < -34 -34 ≤ SEC < -26 -26 ≤ SEC < -23 -23 ≤ SEC < -20 E (Least efficient) -20 ≤ SEC < -10 Flair 450/600 Enthalpy 617561-A Brink / 61...
-
Page 62: Recycling And Disposal
1. Dispose of packaging made of cardboard, recyclable plastics and synthetic filler materials in an environmentally compatible manner through appropriate recycling systems or a recycling center. 2. Please observe the applicable national and local regulations. Brink / 62 Flair 450/600 Enthalpy 617561-A... - Page 63 Flair 450/600 Enthalpy 617561-A Brink / 63...
- Page 64 Brink Climate Systems B.V. Wethouder Wassebaliestraat 8, NL-7951SN Staphorst T: +31 (0) 522 46 99 44 E. info@brinkclimatesystems.nl www.brinkclimatesystems.nl...
