ASSEMBLY INSTRUCTIONS
HNZSL2015
BASE SIZE: 2.020m x 1.520m

Advertisement

loading
Need help?

Need help?

Do you have a question about the HNZSL2015 and is the answer not in the manual?

Questions and answers

Summary of Contents for Duratuf HNZSL2015

  • Page 1 ASSEMBLY INSTRUCTIONS HNZSL2015 BASE SIZE: 2.020m x 1.520m...
  • Page 2 CHECK OUT OUR ASSEMBLY VIDEO...
  • Page 3 CONGRATULATIONS ON PURCHASING A DURATUF SENTRY SHED. BEFORE YOU BEGIN THE ASSEMBLY PLEASE NOTE SOME IMPORTANT POINTS: BEFORE YOU START: • Read all instructions carefully • Identify all parts and check quantities against parts list • Select a level site •...
  • Page 4 HNZSL2015 PARTS LIST CLADDING + FLASHING + HARDWARE PACK 1 DESCRIPTION DIAGRAM CHECKED Front Wall - 1.890m Back Wall - 1.850m Side Wall - 1.850m Roof - 1.720m Door Sheet Narrow - 1.850m Door Sides - 1.850m Door Jamb - 1.890m Door Brace - 1.160m...
  • Page 5 HNZSL2015 PARTS LIST PACK 2 TIMBER PACK DESCRIPTION DIAGRAM Front/Back Bottom Plates - H4 (Green) 2.020 m Back Top Plate - H1 (Red) 2.020 m Front Top Plate - H1 (Red) 2.020 m Side Wall Bottom Plates - H4 (Green) 1.520m -...
  • Page 6 PARTS LOCATION Roof Sheets Barge Flashing Spouting Back Wall Sheets Top Plate Side Top Plate Back Top Plate Front Front Wall Sheet Door Brace Hinge Door Sheets Door Jambs Side Wall Sheets Padbolt Support Bottom Plate Side Door Top/Bottom Front Wall Sheet Door Side Flashing Bottom Plate Front QUICK OVERVIEW...
  • Page 7 FOUNDATION No doubt by now you will have decided what sort of base you are putting down. Please read the section that applies to your situation. If you choose to pour a concrete base you will need to decide whether you wish to raise the base plate of your shed. This allows the cladding to protrude below the surface of the concrete and ensures a water tight pad.
  • Page 8 ASSEMBLE DOOR SELECT: 2 x 1.850 m Door Sheets (Narrow) 2 x 0.945 m Door Top/Bottom Flashings 2 x 1.850 m Door Side Flashings 3 x Hinges 1 x Padbolt Support Flashing 2 x 1.160 m Door Brace Flashings 54 x Rivets fig.3 STEP 1: NARROW PANS...
  • Page 9 ASSEMBLE SIDE PANELS IMPORTANT—IF YOU CHOOSE TO RAISE YOUR TIMBER SELECT: BASE PLATE –READ THE FOLLOWING; 6 x 1850 Wall Sheets For sheds with Raised Base Plate option only (see page 7), deduct 2 x 1.520 Top Plates (Red) 30mm from measurement shown between Top and Bottom Plates on 2 x 1.520 Bottom Plates (Green) all wall panels, so cladding protrudes 20mm below bottom plate 72 x 30mm Galv Clouts...
  • Page 10 ASSEMBLE BACK PANEL IMPORTANT—IF YOU CHOOSE TO RAISE YOUR TIMBER SELECT: BASE PLATE –READ THE FOLLOWING; 4 x 1.850m Wall Sheets For sheds with Raised Base Plate option only (see page 7), deduct 1 x 2.020 m Top Plate (Red) 30mm from measurement shown between Top and Bottom Plates on 1 x 2.020 m Bottom Plate (Green) all wall panels, so cladding protrudes 20mm below bottom plate...
  • Page 11 ASSEMBLE FRONT PANEL IMPORTANT—IF YOU CHOOSE TO RAISE YOUR TIMBER SELECT: BASE PLATE –READ THE FOLLOWING; 2 x 1.890 Wall Sheets For sheds with Raised Base Plate option only (see page 7), deduct 1 x 2.020 Top Plate (Red) 30mm from measurement shown between Top and Bottom Plates on 1 x 2.020 Bottom Plate (Green) all wall panels, so cladding protrudes 20mm below bottom plate 2 x 1.890 Door Jamb Flashings...
  • Page 12 WALL PANEL ASSEMBLY SELECT: 4 x Pre-made Wall Panels 40mm X 2 SIDE 12 x 40mm Screws OVERLAPS 4 x 75mm Screws BACK 16 x Rivets TOP PLATE BACK WALL STEP 1: BOTTOM PLATE • Stand the Back Panel and the Side Panel SIDE up using someone to support the panels 40mm X 2...
  • Page 13 ROOF ASSEMBLY IMPORTANT SELECT: Use 50mm Clouts only on outside ribs covered by Barge flashings. Predrill holes us- 4 x 1.720 m Roof Sheets ing a 3.5mm drill bit. Use Roofing Screws on all other ribs. 1 x 2.055 m Spouting Ensure screws are not overtightened as this can damage the seals and cause the 2 x 1.720 m Barges shed to leak.
  • Page 14 Secure your shed using Treated Timber Pegs or a Bolt Down Kit TIMBER PEGS—WOODEN FLOOR • The optional Duratuf Timber Peg Down Kit includes six H5 treated timber pegs that can be hammered into the ground and then attached to the Base Plate with stainless steel screws.
  • Page 16 25 YEAR WARRANTY Riverlea Group Ltd warrant that the cladding used in the manufacture of the Sentry shed will not rust within 25 years from the date of purchase. Any liability for product failure that may arise will be limited to repair or replacement of the defective product and will only apply for the benefit of the original purchaser.
