  • Page 1 Acces PCI-DIO-48 Digital I/O Card Limited Availability Used and in Excellent Condition Open Web Page https://www.artisantg.com/67157-1 A l l t r a d e m a r k s , b r a n d n a m e s , a n d b r a n d s a p p e a r i n g h e r e i n a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s .
  • Page 2 10623 Roselle Street, San Diego, CA 92121 • (858) 550-9559 • FAX (858) 550-7322 contactus@accesio.com • www.accesio.com DIGITAL INPUT/OUTPUT CARD Models PCI-DIO-48H and PCI-DIO-48HS USER MANUAL File: mpci-dio-48H.Be Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 3 ACCES, nor the rights of others. IBM PC, PC/XT, and PC/AT are registered trademarks of the International Business Machines Corporation. Printed in USA. Copyright 1998, 2005 by ACCES I/O Products Inc, 10623 Roselle Street, San Diego, CA 92121. All rights reserved.
  • Page 4 Other than the above, no other warranty, expressed or implied, shall apply to any and all such equipment furnished or sold by ACCES. Manual PCI-DIO-48 H/HS Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 5 Table 6-4: Change-of-State Interrupt Enable Register................17 Chapter 7: Connector Pin Assignments ................19 Table 7-1: Connector Pin Assignments (1-50)..................19 Table 7-2: Connector Pin Assignments (51-100)..................20 Manual PCI-DIO-48 H/HS Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 6 PPI. Further, if a jumper is properly placed on the card the tristate buffers may be enabled/disabled under program control. (See the Option Selection section to follow.) Manual PCI-DIO-48 H/HS Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 7 6.9" Long (176 mm) Environmental: Operating Temperature: 0 degr. to 60 degr. C Storage Temperature: -50 degr. to +120 degr. C Humidity: 0 to 90% RH, non-condensing. Manual PCI-DIO-48 H/HS Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 8 CHANGE GROUP PORT C HI STATE DETECT CONTROL PORT C LO LOGIC CHANGE OF STATE INTERRUPT INTERRUPT ENABLE EXTERNAL INTERRUPT Figure 1-1: Block Diagram Manual PCI-DIO-48 H/HS Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 9 Please follow all reasonable precautions to prevent a static discharge such as grounding yourself by touching any grounded surface prior to touching the card. Manual PCI-DIO-48 H/HS Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 10 Also, proper EMI cabling techniques (cable connect to chassis ground at the aperture, shielded twisted-pair wires, etc) should be used for the input/output wiring. Manual PCI-DIO-48 H/HS Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 11 Interrupt Enable is done via software by writing to a control register in each PPI as described in the PROGRAMMING section of this manual. Figure 3-1: Option Selection Map Manual PCI-DIO-48 H/HS Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 12 The PCI bus supports 64K of I/O address space, so your card’s addresses may be located anywhere in the 0000 to FFFF hex range. Manual PCI-DIO-48 H/HS Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 13 Function: Writes the lower eight bits of value to the hardware port at address. This function returns the value output. Declaration: function OutPortb(byval address as integer, byval value as integer) as integer Manual PCI-DIO-48 H/HS Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 14 This will allow multiple programs to find the same .DLL without having to know where it is located. Just leave off all references to a path in the .GBL file as shown in the sample. Manual PCI-DIO-48 H/HS Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 15 Control Register states. Note that Control Registers are located at base address +3 and base address +7. Bit assignments in each of these Control Registers are as follows: Manual PCI-DIO-48 H/HS Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 16 Note that all data bits except D7 must be the same for the two control bytes Those buffers will now remain enabled until another control byte with data bit D7 high is sent to base address Manual PCI-DIO-48 H/HS Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 17 To set outputs high (1) at Port B and the lower nybble of Port C: 50OUT BASEADDR+1,&HFF'Turn on all Port B bits 60OUT BASEADDR+2,&HF'Turn on all bits of Port C lower nybble Manual PCI-DIO-48 H/HS Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 18 Writing a “one” disables the port; writing a “zero” enables it. This register is latched. To clear the latch, write anything at Base Address+F. Manual PCI-DIO-48 H/HS Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 19 0XXX (where X is ‘don’t care’) to port C Low. To gate the external interrupt ‘off’ configure port C Low as an output (don’t change the value of the most significant bit). To gate the external interrupt ‘on’ configure port C Low as an input. Manual PCI-DIO-48 H/HS Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 20 Group 0 Port A " +5 VDC Ground * This line is an I/O port and also a User Interrupt. Table 7-1: Connector Pin Assignments (1-50) Manual PCI-DIO-48 H/HS Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 21 Group 1 Port A " +5 VDC Ground * This line is an I/O port and also a User Interrupt. Table 7-2: Connector Pin Assignments (51-100) Manual PCI-DIO-48 H/HS Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 22 Please detail any errors you find and include your mailing address so that we can send you any manual updates. 10623 Roselle Street, San Diego CA 92121 Tel. (858)550-9559 FAX (858)550-7322 www.accesio.com Manual PCI-DIO-48 H/HS Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
