Summary of Contents for Acces I/O products PCIE-ADIO16-16F
- Page 1 NALOG INPUT NALOG UTPUT IGITAL PCI E XPRESS ARDWARE ANUAL -ADIO16-16F F ODELS AMILY ACCES I/O Products, Inc. +1 858 550 9559 www.ACCESio.com 10623 Roselle Street 800 326 1649 http://accesio.com/PCIe-ADIO16-16F San Diego CA 92121-1506 USA sales@accesio.com MADE IN THE USA...
- Page 2 In Linux or OSX please refer to github.com/accesio/apci. All units are RoHS compliant. 2: I HAPTER NTRODUCTION INCLUDED IN YOUR PACKAGE 1× PCIe-ADIO16-16F Family card Available accessories include: 68-Pin SCSI 18” shielded cable with one-touch C68PS18L latches Screw Terminal Board (mounted on standoffs)
- Page 3 DIO BitIndex 0 32 DIO BitIndex 1 Digital Ground 33 Digital Ground VCCdio / UserVCCdio 34 Watchdog Active All unlisted pins in the above table are analog ground. ACCES I/O Products, Inc. MADE IN THE USA PCIe-ADIO16-16F Family Manual Rev B1...
-
Page 4: Advanced Topics
Digital I/O Secondary Functions.) Once triggered, data will be collected until manually stopped by writing +38 with bit 16 clear (or various resets, etc.). External Start, Single, Synchronous: The digital input secondary function “ADC Start” can be configured to initiate individual ADC Start Events on a selected edge input. ACCES I/O Products, Inc. MADE IN THE USA... -
Page 5: Register Overview
ACCES provided drivers (AIOWDM [for Windows], APCI [for Linux & OSX]), or using any 3 party APIs such as provided with Real-Time OSes. Addresses not explicitly documented are reserved and should not be accessed. ACCES I/O Products, Inc. MADE IN THE USA PCIe-ADIO16-16F Family Manual... - Page 6 Write a 32-bit divisor to the ADC Rate Divisor #2 register to control the speed at which ADC Conversions occur within each scan when running in ADC Scan Start Modes. ACCES I/O Products, Inc. MADE IN THE USA PCIe-ADIO16-16F Family Manual...
- Page 7 In Software ADC Start Mode (ADC Rate Divisor (+10) cleared to zero) the FIFO Count determines how many ADC Conversions (+statuses) are held in the FIFO. Read the ADC FIFO this many times to gather the acquired ADC Data. ACCES I/O Products, Inc. MADE IN THE USA...
- Page 8 If SCAN is set (to 1) AND INx2:0 is non-zero then each “ADC Start” event will acquire channels 0 through INx2:0 at the rate specified in +14. CONFIG: If CONFIG is set then the ADC control bits (D15 through D0 of this register) will be written to the ADAS3022 ACCES I/O Products, Inc. MADE IN THE USA...
- Page 9 Write IRQ Status bits SET to clear the latched IRQ Status bit(s). Typically, code will read +40 and write the value to +40 to clear all detected IRQs and leave the IRQ enables unchanged. Write IRQ Enable bits SET to enable corresponding IRQ sources. ACCES I/O Products, Inc. MADE IN THE USA...
- Page 10 , please consult the various samples (C#, Delphi, and more) to explore how to program the device. The AIOAIO Software Reference Manual.pdf provides reference material covering all AIOAIO Library APIs. A quick reference of the most-applicable functions is provided, below: In Linux or OSX please refer to the documentation at github.com/accesio/apci. ACCES I/O Products, Inc. MADE IN THE USA PCIe-ADIO16-16F Family Manual...
- Page 11 The latest information can always be found on the product page on the website. Here are some useful links: Links to useful downloads ACCES web site https://accesio.com Product web page accesio.com/PCIe-ADIO16-16F This manual accesio.com/MANUALS/PCIe-ADIO16-16F.pdf Install Package (Windows XP->10) accesio.com/files/packages/PCIe-ADIO16-16F Install.exe Linux / OSX github.com/accesio/APCI ACCES I/O Products, Inc. MADE IN THE USA PCIe-ADIO16-16F Family Manual Rev B1...
-
Page 12: Chapter 8: Specifications
WITH THE COMPUTER POWER OFF. ALWAYS TURN specified or intended as evidenced by purchase or sales ACCES I/O Products, Inc. MADE IN THE USA PCIe-ADIO16-16F Family Manual Rev B1... -
Page 13: Terms And Conditions
ACCES, nor the rights of others. ACCES I/O Products, Inc. MADE IN THE USA PCIe-ADIO16-16F Family Manual...
