- Page 2 • • 10623 Roselle Street, San Diego, CA 92121 (858) 550-9559 FAX (858) 550-7322 • contactus@accesio.com www.accesio.com MODELS PCIe-DIO-120, PCIe-DIO-96, and PCIe-DIO-72 Digital I/O Card USER MANUAL FILE: PCIe-DIO-120.B1...
- Page 3 ACCES, nor the rights of others. IBM PC, PC/XT, and PC/AT are registered trademarks of the International Business Machines Corporation. Printed in USA. Copyright by ACCES I/O Products Inc, 10623 Roselle Street, San Diego, CA 92121. All rights reserved. WARNING!! ALWAYS CONNECT AND DISCONNECT YOUR FIELD CABLING WITH THE COMPUTER POWER OFF.
- Page 4 Other than the above, no other warranty, expressed or implied, shall apply to any and all such equipment furnished or sold by ACCES. Manual PCIe-DIO-120/96/72...
-
Page 5: Table Of Contents
Table 6-2: Control Register Bit Assignments ............13 Base Address +1C (read/write) DIO Buffer Enable / Disable (tri-state) ....13 Chapter 6: Connector Pin Assignments ..............14 Table 6-1: Connector Pin Assignments ..............14 Chapter 7: Specifications ................... 15 Manual PCIe-DIO-120/96/72... -
Page 6: Chapter 1: Introduction
Chapter 1: Introduction The PCIe-DIO-120 series are x1 lane PCI Express (PCIe) boards with 120, 96, or 72 digital I/O lines designed for use in a variety of Digital I/O (DIO) applications. They use the high speed PCIe bus to transfer digital data to and from the board. The FPGA based DIO emulates 8255 compatible chips in mode 0, making it easy to program. -
Page 7: Bias Resistors
OPTO-22, Gordos, Potter & Brumfield, Western Reserve Controls, etc. module mounting racks. Every second conductor of the flat cables is grounded to minimize crosstalk between signals. If needed for external circuits, VCCIO power is available on each I/O connector at pin 49. Figure 1-1: Block Diagram Manual PCIe-DIO-120/96/72... -
Page 8: Ordering Guide
Optional Accessories 6’ ribbon cable with strain relieved 50 pin female connectors CAB50F-6 STB-120CH Large screw terminal board for PCIe-DIO-120 installed in T-Box STB-96CH Large screw terminal board for PCIe-DIO-96 installed in T-Box STB-72CH Large screw terminal board for PCIe-DIO-72 installed in T-Box 6’... -
Page 9: Chapter 2: Installation
Caution! * ESD A single static discharge can damage your card and cause premature failure! Please follow all reasonable precautions to prevent a static discharge such as grounding yourself by touching any grounded surface prior to touching the card. Manual PCIe-DIO-120/96/72... -
Page 10: Hardware Installation
(depending on the operating system) and automatically finish installing the drivers. Run one of the provided sample programs that was copied to the newly created card directory (from the CD or downloaded from the product page) to test and validate your installation. Manual PCIe-DIO-120/96/72... -
Page 11: Chapter 3: Hardware Details
The foregoing are the only manual setups necessary to use these cards. Input/Output selection is done via software, by writing to the GROUP Control Registers as described in the Programming section of this manual. Figure 3-1: Option Selection Map Manual PCIe-DIO-120/96/72... -
Page 12: Chapter 4: Address Selection
If you want to determine the base address and IRQ yourself, use the following information. The Vendor ID for these cards is 494F. (ASCII for "IO") The Device ID for the 72 is 0C6A. The Device ID for the 96 is 0C71. The Device ID for the 120 is 0C79. Manual PCIe-DIO-120/96/72... -
Page 13: Chapter 5: Programming
PC Group 4 Read/Write Base Address +13 Control Port 4 Write Only Base Address +1C DIO Buffer Enable Read/Write Base Address +1E Clear/Disable Interrupts Write Only Base Address +1F Clear/Enable Interrupts Write Only Table 6-1: Address Registry Table Manual PCIe-DIO-120/96/72... -
Page 14: Base Address +1C (Read/Write) Dio Buffer Enable / Disable (Tri-State)
0. To re-enable the DIO buffers, write a zero to bit 0. When buffers are disabled the pins are tri-stated and biased by the state of the pull up or down configuration jumpers. A read of bit 0 returns the enable / disable status. Manual PCIe-DIO-120/96/72... -
Page 15: Chapter 6: Connector Pin Assignments
Port A PA6 Port A PA5 Port A PA4 Port A PA3 Port A PA2 Port A PA1 Port A PA0 Fused VCCIO Table 6-1: Connector Pin Assignments * This line is an I/O port and also a User Interrupt. Manual PCIe-DIO-120/96/72... -
Page 16: Chapter 7: Specifications
≤ 0.45V Low Outputs ≥ 1.2V High Outputs Environmental Operating Temperature 0° to 70°C optional -40° to +85°C Storage Temperature -55° to +150°C Humidity 5% to 95% RH, w/o condensation length – 10.5" Height - 4.2" seated Card Dimensions Manual PCIe-DIO-120/96/72... - Page 17 If you experience any problems with this manual or just want to give us some feedback, please email us at: manuals@accesio.com. Please detail any errors you find and include your mailing address so that we can send you any manual updates. 10623 Roselle Street, San Diego CA 92121 Tel. (858)550-9559 FAX (858)550-7322 www.accesio.com Manual PCIe-DIO-120/96/72...
