- Page 1 • • 10623 Roselle Street, San Diego, CA 92121 (858) 550-9559 FAX (858) 550-7322 • contactus@accesio.com www.accesio.com MODEL ETH-IDIO-16 FAMILY ETH-IDIO-16, ETH-IDIO-8, ETH-IDO-16, & ETH-II-16 ETHERNET ISOLATED DIGITAL INPUT / FET OUTPUT MODULES USER MANUAL...
- Page 2 ACCES, nor the rights of others. Printed in USA. Copyright© by ACCES I/O Products Inc, 10623 Roselle Street, San Diego, CA 92121. All rights reserved.
-
Page 3: Table Of Contents
Chapter 6: Connector Pin Assignments ....................14 Chapter 7: Specifications ........................... 16 Isolated Inputs ..........................16 Solid State FET Outputs ....................... 16 Bus Type ............................... 16 Environmental............................ 16 Power ..............................16 Power Options (External Power required) ................16 Customer Comments ..........................17 Manual ETH-IDIO-16 B1... -
Page 4: Chapter 1: Introduction
Driving Indicator Lights or Recorders Functional Description The ETH-IDIO-16 Series (4, 8 and 16 channels) is an ideal solution for adding portable, easy-to-install, isolated input and solid state output digital I/O capabilities to any Ethernet network. It is excellent for controlling external relays, driving indicator lights, fuel pumps, high voltage control and more. -
Page 5: Oem Eth/104 Form Factor
The ETH-IDIO-16 is designed to be used in rugged industrial environments but is small enough to fit nicely onto any desk or testing station. Its board is PC/104 sized (3.550 by 3.775 inches) and ships inside a steel powder-coated enclosure with an anti-skid bottom. -
Page 6: Ordering Guide
Ordering Guide • ETH-IDIO-16 16 isolated digital inputs and 16 FETs in enclosure with breakout board • ETH-IDIO-8 8 isolated digital inputs and 8 FETs in enclosure with breakout board • ETH-IDO-16 16 relays in enclosure with breakout board •... -
Page 7: Optional Accessories
STB-50 screw terminal boards on a DIN rail DIN-rail mounting adapter plate for affixing any • MP104-DIN ETH/104 module to a DIN-rail • PWR-ACDC-5V External 5 VDC power supply *Note: Ribbon cables carry significantly less current than discrete wires. Manual ETH-IDIO-16 B1... -
Page 8: Chapter 2: Installation
If necessary you can reset the module to the factory default networking configuration by briefly shorting the OPT1 jumper position while power is applied. (You may need to open the device' enclosure to reach the OPT1 jumper). Manual ETH-IDIO-16 B1... -
Page 9: Chapter 3: Hardware Details
For faster response to changing inputs, remove the filter jumpers for the affected channels. The LED on the front of the board is used to indicate power when on steady, and activity / communication on the Ethernet lines when flickering. Manual ETH-IDIO-16 B1... -
Page 10: Dc Power Jack
50 and 34 Pin Box Headers These headers have standard 0.100" spacing between pins and are keyed to prevent improper connections. It can be used with standard IDC type ribbon cables, or the included spring cage accessory board. Manual ETH-IDIO-16 B1... -
Page 11: Chapter 4: Ethernet Address Information
For your information, the device listens on port 51936 for normal operation, and listens on 51937 for upgrading onboard firmware should it become necessary. Under very rare circumstances you may need to modify your network settings to allow access to these ports. The firmware supports at most six simultaneous connections during normal operation. Manual ETH-IDIO-16 B1... -
Page 12: Chapter 5: Programming
Writes to input bytes are ignored. AEW_DIO_WriteAll() AEW_DIO_WriteAll() writes to all the DIO. AEW_DIO_ReadAll() AEW_DIO_ReadAll() reads from all the DIO. For a complete AIOETHW.dll API reference please refer to the HTML API reference installed in your software directory. Manual ETH-IDIO-16 B1... -
Page 13: Packet Structure
_Err S>M failed. ERROR_BAD_DEV_TYPE, indicating read from a write-only device or vice versa. Table 5-1: Packet Type Definitions Refer to the ETH API Reference for a complete and detailed DLL API function and packet-level command and control reference. Manual ETH-IDIO-16 B1... -
Page 14: Chapter 6: Connector Pin Assignments
Signal Description Name Iso In xx A Isolated digital input pins, non-polarity sensitive, connect a powered Iso In xx B signal across these pins to read an active input Table 6-2: Input Connector Signal Names and Descriptions Manual ETH-IDIO-16 B1... - Page 15 Figure 6-1: ETH-STB-84 Removable Spring Cage Terminal Board (showing example external device connections) Manual ETH-IDIO-16 B1...
-
Page 16: Chapter 7: Specifications
All FETs ON 5V@115mA typical Power Options (External Power required) No option If you have your own +5 V regulated power supply PWR-ACDC-5V ACCES I/O +5 V regulated power supply Wide input power (7 - 30 V Manual ETH-IDIO-16 B1... -
Page 17: Customer Comments
If you experience any problems with this manual or just want to give us some feedback, please email us at: manuals@accesio.com. Please detail any errors you find, we will reply with manual updates. 10623 Roselle Street, San Diego CA 92121 Tel. (858)550-9559 FAX (858)550-7322 www.accesio.com Manual ETH-IDIO-16 B1...
