AEG BPK848330T User Manual

AEG BPK848330T User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
BPK848330T
USER
MANUAL
EN
User Manual
Oven

Advertisement

loading
Need help?

Need help?

Do you have a question about the BPK848330T and is the answer not in the manual?

Questions and answers

Related Manuals for AEG BPK848330T

Summary of Contents for AEG BPK848330T

  • Page 1 BPK848330T User Manual Oven USER MANUAL...
  • Page 2 FOR PERFECT RESULTS Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler – features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it.
  • Page 3 SAFETY INFORMATION 9. ADDITIONAL FUNCTIONS....... 23 12.2 How to manage: Error codes..32 12.3 Service data.........33 9.1 How to save: Favourites....23 9.2 Automatic switch-off.......23 13. ENERGY EFFICIENCY......34 9.3 Cooling fan........23 13.1 Product Information and Product 10. HINTS AND TIPS........24 Information Sheet........
  • Page 4 SAFETY INFORMATION Children should be supervised to ensure that they do not • play with the appliance and mobile devices with My AEG Kitchen. Keep all packaging away from children and dispose of it • appropriately. WARNING: The appliance and its accessible parts become •...
  • Page 5 SAFETY INSTRUCTIONS WARNING: The appliance and its accessible parts become • hot during use. Care should be taken to avoid touching heating elements or the surface of the appliance cavity. Always use oven gloves to remove or insert accessories or •...
  • Page 6 SAFETY INSTRUCTIONS Cabinet depth 550 (550) mm Height of the front of the appliance 594 mm Height of the back of the appliance 576 mm Width of the front of the appliance 595 mm Width of the back of the appliance 559 mm Depth of the appliance 567 mm...
  • Page 7 SAFETY INSTRUCTIONS • The electrical installation must have an isolation device which lets you disconnect the appliance from the mains at all poles. The isolation device must have a contact opening width of minimum 3 mm. • Fully close the appliance door before you connect the mains plug to the mains socket. •...
  • Page 8 SAFETY INSTRUCTIONS • Before maintenance, deactivate the appliance and disconnect the mains plug from the mains socket. • Make sure the appliance is cold. There is the risk that the glass panels can break. • Replace immediately the door glass panels when they are damaged. Contact the Authorised Service Centre.
  • Page 9 PRODUCT DESCRIPTION 2.7 Service • To repair the appliance contact the Authorised Service Centre. • Use original spare parts only. 2.8 Disposal WARNING! Risk of injury or suffocation. • Contact your municipal authority for information on how to dispose of the appliance. •...
  • Page 10 CONTROL PANEL Baking tray For cakes and biscuits. Grill- / Roasting pan To bake and roast or as a pan to collect fat. Food Sensor To measure the temperature inside food. Telescopic runners For inserting and removing trays and wireshelf more easily.
  • Page 11 CONTROL PANEL ON / OFF Press and hold to turn the appliance on and off. Display Shows the current settings of the appliance. Press Move Press and hold Touch the surface with finger‐ Slide fingertip over the sur‐ Touch the surface for 3 sec‐ tip.
  • Page 12 BEFORE FIRST USE The function is on. The function is on. Sound alarm is off. Cooking stops automati‐ cally. Timer indicators The timer The timer starts The timer starts starts after when the appli‐ To set the function: Delayed To cancel when cooking closing the ance reaches...
  • Page 13 To connect the appliance you need: • Wireless network with the Internet connection. • Mobile device connected to the same wireless network. Step 1 Download the mobile app My AEG Kitchen and follow the instructions for the next steps. Step 2 Turn on the appliance.
  • Page 14 DAILY USE 5.5 Initial preheating Preheat the empty oven before the first use. Step 1 Remove all accessories and removable shelf supports from the oven. Step 2 Set the maximum temperature for the function: Let the oven operate for 1 h. Step 3 Set the maximum temperature for the function: Let the oven operate for 15 min.
  • Page 15 DAILY USE 6.2 How to set: Assisted Cooking Every dish in this submenu has a recommended function and temperature. You can adjust the time and the temperature. For some of the dishes you can also cook with: • Weight Automatic •...
  • Page 16 DAILY USE Heating function Application To bake and roast food on one shelf position. Conventional Cooking To bake pizza. To make intensive browning and a crispy bottom. Pizza Function To bake cakes with crispy bottom and to preserve food. Bottom Heat SPECIALS Heating function Application...
  • Page 17 CLOCK FUNCTIONS Heating function Application To prepare tender, succulent roasts. Slow Cooking To keep food warm. Keep Warm This function is designed to save energy during cooking. When you use this function, the temperature in the cavity may differ from the set temper‐ ature.
  • Page 18 CLOCK FUNCTIONS Clock function Application Reminder To set a countdown. Maximum is 23 h 59 min. This function has no ef‐ fect on the operation of the appliance. Start Criteria Comment The timer starts when you turn it on. The timer starts after closing the door. The timer starts when cooking starts.
  • Page 19 CLOCK FUNCTIONS How to choose cooking start / end option Step 3 Press: Step 4 Press: Start Criteria / End Action. Step 5 Choose the preferred: Start Criteria / End Action. Step 6 Press: or . How to delay start and end of cooking Step 1 Press: Step 2...
  • Page 20 USING THE ACCESSORIES How to set extra time Step 1 Press: Step 2 Choose the value on the slider or press one of the preferred time icons to set the time. Step 3 Press: How to change timer settings Step 1 Choose the value on the slider or press the preferred time value to change the timer value.
  • Page 21 USING THE ACCESSORIES Baking tray / Deep pan: Push the tray between the guide bars of the shelf support. 8.2 Food Sensor Food Sensor - measures the temperature inside the food. You can use it with every heating function. There are two temperatures to be set: The oven temperature: minimum 120 °C.
  • Page 22 USING THE ACCESSORIES Insert the tip of Food Sensor into the centre Insert the tip of Food Sensor exactly in the centre of meat, fish, in the thickest part if possible. of the casserole. Food Sensor should be stabi‐ Make sure that at least 3/4 of Food Sensor is lized in one place during baking.
  • Page 23 ADDITIONAL FUNCTIONS 9. ADDITIONAL FUNCTIONS 9.1 How to save: Favourites You can save your favourite settings, such as the heating function, the cooking time, the temperature or the cleaning function. You can save 3 favourite settings. Step 1 Turn on the appliance. Step 2 Select the preferred setting.
  • Page 24 HINTS AND TIPS 10. HINTS AND TIPS 10.1 Cooking recommendations The temperature and cooking times in the tables are guidelines only. They depend on the recipes and the quality and quantity of the ingredients used. Your appliance may bake or roast differently to the appliance you had before. The hints below show recommended settings for temperature, cooking time and shelf position for specific types of the food.
  • Page 25 HINTS AND TIPS (°C) (min) Tartlets, 8 baking tray or dripping 15 - 25 pieces 10.3 Moist Fan Baking - recommended accessories Use the dark and non-reflective tins and containers. They have better heat absorption than the light colour and reflective dishes. Ramekins Pizza pan Baking dish...
  • Page 26 HINTS AND TIPS °C Short bread Conventional Cook‐ 25 - 35 Baking on one level - biscuits Use the third shelf position. °C Small cakes, 20 per tray, True Fan Cooking 20 - 30 preheat the empty oven Small cakes, 20 per tray, Conventional Cooking 20 - 30 preheat the empty oven...
  • Page 27 CARE AND CLEANING Toast Grill 1 - 2 Beef steak, turn halfway Grill 24 - 30 through 11. CARE AND CLEANING WARNING! Refer to Safety chapters. 11.1 Notes on cleaning Clean the front of the appliance only with a microfibre cloth with warm water and a mild detergent.
  • Page 28 CARE AND CLEANING Step 1 Turn off the oven and wait until it is cold. Step 2 Pull the front of the shelf sup‐ port away from the side wall. Step 3 Pull the rear end of the shelf support away from the side wall and remove it.
  • Page 29 CARE AND CLEANING When the cleaning starts, the lamp is off and the cooling fan works at a higher speed. - press to stop the cleaning before it is completed. Do not use the oven until the door lock symbol disappears from the display. When the cleaning ends: Turn off the oven and wait Clean the cavity with a soft...
  • Page 30 CARE AND CLEANING Step 4 Hold the door trim (B) on the top edge of the door at the two sides and push inwards to release the clip seal. Step 5 Pull the door trim to the front to remove it. Step 6 Hold the door glass panels on their top edge one by one and...
  • Page 31 TROUBLESHOOTING Step 2 Clean the glass cover. Step 3 Replace the lamp with a suitable 300 °C heat-resistant lamp. Step 4 Install the glass cover. Side lamp 12. TROUBLESHOOTING WARNING! Refer to Safety chapters. 12.1 What to do if... The appliance does not turn on or does not heat up Possible cause Remedy The appliance is not connected to an electrical...
  • Page 32 TROUBLESHOOTING Components Description Remedy The lamp is burnt out. Replace the lamp, for details refer to "Care and Cleaning" chapter, How to replace: Lamp. Power cut always stops cleaning. Repeat cleaning if it's interrupted by power failure. Problems with Wi-Fi signal Possible cause Remedy Trouble with wireless network signal.
  • Page 33 TROUBLESHOOTING Code and description Remedy C3 - the door is not fully closed during Pyrolyt‐ Close the door. ic Cleaning. F111 - Food Sensor is not correctly inserted Fully plug Food Sensor into the socket. into the socket. F240, F439 - the touch fields on the display do Clean the surface of the display.
  • Page 34 ENERGY EFFICIENCY 13. ENERGY EFFICIENCY 13.1 Product Information and Product Information Sheet Supplier's name Model identification BPK848330T 944188737 Energy Efficiency Index 61.2 Energy efficiency class Energy consumption with a standard load, conventional 1.09 kWh/cycle mode Energy consumption with a standard load, fan-forced 0.52 kWh/cycle...
  • Page 35 MENU STRUCTURE The fan and lamp continue to operate. When you turn off the appliance, the display shows the residual heat. You can use that heat to keep the food warm. When the cooking duration is longer than 30 min, reduce the appliance temperature to minimum 3 - 10 min before the end of cooking.
  • Page 36 MENU STRUCTURE Submenu Application Pyrolytic cleaning, nor‐ Duration: 1 h 30 min. Pyrolytic cleaning, in‐ Duration: 3 h. tense Cleaning Reminder Reminds you when to clean the oven. 14.3 Submenu for: Options Submenu Application Light Turns the lamp on and off. Lamp Icon visible Lamp icon appears on the screen.
  • Page 37 MENU STRUCTURE Submenu Description Auto Remote Operation To start remote operation automatically after pressing START. Option visible only after you turn on: Wi-Fi. Forget Network To disable current network from auto connection with the appliance. 14.5 Submenu for: Setup Submenu Description Language Sets the appliance language.
  • Page 38 IT'S EASY! Submenu Description Reset All Settings Restores factory settings. Reset all popups Restores all pop-ups to the original settings. 15. IT'S EASY! Before the first use you have to set: Language Display Brightness Buzzer Volume Time of Day Familiarize yourself with the basic icons on the control panel and the display: Menu / Informa‐...
  • Page 39 IT'S EASY! Get to know how to cook quickly Use the automatic programmes to prepare a dish quickly with the default settings: Assisted Step 1 Step 2 Step 3 Step 4 Cooking Choose the Press: Press: Press: Assis‐ dish. ted Cooking. Use quick functions to set the cooking time or change the cooking function Quick timer settings Step 1...
  • Page 40 www.aeg.com/shop...
