Nauticam N105VR-F Instruction Manual

For nikkor af-s vr micro nikkor 105mm f2.8g if-ed

Current as of 8/22/2022

INSTRUCTION MANUAL

For N105VR-F for Nikkor AF-S VR

micro Nikkor 105mm F2.8G IF-ED

PN# 19122

This manual applies to product shipped

from September, 2022, serial number from

A534114 onwards;

FORWORD

Thank you for your purchase of a NAUTICAM

product.

At NAUTICAM, we pride ourselves in the ability to

recognize the requirements of professional as well

as amateur underwater photographers and fulfill

them through the innovative designs of our

products. We strive to achieve a high level of user-

friendliness by allowing stress-free installation and

easy operation of all important functions of the

camera.

Each product is individually inspected and water

pressure tested to ensure optimum quality.

Please read this manual carefully before using the

product, this will maximize its performance as well

as its lifetime.

Table of Contents

Need help?

Do you have a question about the N105VR-F and is the answer not in the manual?

Page 1 A534114 onwards; FORWORD Thank you for your purchase of a NAUTICAM product. At NAUTICAM, we pride ourselves in the ability to recognize the requirements of professional as well as amateur underwater photographers and fulfill them through the innovative designs of our products.
Page 2 NAUTICAM does not hold responsibility for damage, of any nature, to any equipment used with and/or placed within our products. NAUTICAM accepts no liability for any loss of captured images or the inability to capture images even if it is due to the malfunctioning of our products.
Page 3 IDENTIFICATION OF PARTS Plastic C-ring N105VR-F Focus Gear Spare Rubber grips...
Page 4 For Old version of 19122 (A534114 before), the rubber ring on the lens should be removed before insert the plastic C-ring. 2 Insert the N105VR-F Focus Gear on the plastic C-ring until it reaches the flange of the plastic C-ring.
Page 5 CONTROL THE GEAR 1. The N105VR-F Focus Gear can be controlled by zoom/focus knob of the housing. After mount the camera and lens (with gear installed) on the housing, confirm that the zoom/focus knob operates correctly.
Page 6 SPECIFICATIONS #19122 N105VR-F for Nikkor AF-S VR micro Nikkor 105mm F2.8G IF-ED Dimensions: DIA102.0mm × 77.8mm Type: Focus gear Nikkor AF-S VR micro Nikkor Compatible lens: 105mm F2.8G IF-ED Remark: Nauticam supports only e-manuals. Please download corresponding product manuals on google drive https://bit.ly/Nauticammanual, or contact us for e-...
