Cal-Royal ALBR9860V Series Installation Instruction

INSTALLATION INSTRUCTION FOR ALBR9860V SERIES
PANIC VERTICAL ROD EXIT DEVICE.
LATCH
RELEASE
CAM
TOP
ROD
GUIDE
2 1/8" BORE IS
REQUIRED WHEN
OUTSIDE
KNOB OR LEVER
G
TRIM IS USED
HORIZONTAL ___,...
ct_ CHASIS �'
/
CHASIS ---­
ASSEMBLY
PULLMAN LATCH
TOP CHASIS
ASSEMBLY
STEEL TOP COVER
TOP ROD
AIN SLIDE
HEAD COVER
STEEL BOTTOM COVER
SURFACE OF DOOR FOR
EXIT DEVICE APPLIED MUST
BE FLUSHED.
MOUNTING
RAIL
�
BEFORE INSTALLING DEVICE, PLEASE CHECK:
1. IF DOOR FITTED AND HUNG.
2. SIZE OF EXIT DEVICE, FUNCTION AND DESIGN ...
2.1. 36"DOORS, CAN BE CUT TO FIT DOORS DOWN TO 30"
2.2. 48"DOORS, CAN BE CUT TO FIT DOORS DOWN TO 36"
2.3. HAND OF DEVICE AGAINST APPLICATION
RIGHT HAND
REVERSE BEVEL
TO CHANGE HAND OF A9860V EXIT DEVICE.
1.REMOVE CHASSIS PINS AND
2.REMOVE LIFT LEVER PIN AND LIFT LEVER.
3.REASSEMBLE LIFT LEVER AT OPPOSITE SIDE, AS SHOWN.
4.REPLACE MAIN SLIDE AND CHASSIS PINS.
MAIN SLIDE
DOGGING
HEX KEY
�
WIDE.
WIDE.
OUT
��
•
� �
MAIN
SLIDE.
___..cHASSIS PIN
RAIL MOUNTING
BRACKET
LEFT HAND
REVERSE BEVEL
LIFT LEVER PIN
DRWG # EDG-4158-10/24-1of2
