Level 1 and Level 2 Flash Sequences (Brown or Orange Wire to V+)
No. Single Color
1 Left/Right
2 Even/Odd
3 Random
4 Cycle Sequence Random
5 Sweep Left/Right
6 Off
Level 1 and Level 2 Flash Rates (Brown or Orange Wire to V+)
No. Flash Rate
(Momentary Yel to V+)
1 Double (Level 2 Default)
2
3
4
5
6 Triple (Level 1 Default)
7
8
9
10
11
12
Flash Sequence (Momentary Yel/Blk to V+)
No.
1 Left/Right - Primary & Secondary
2 Left/Right - Primary Only (Level 1 Default)
3 Left/Right - Secondary Only
4 Left/Right - Primary with Secondary Pops
5 Left/Right - Primary with Secondary Random
6 Even/Odd - Primary & Secondary
7 Even/Odd - Primary Only (Level 2 Default)
8 Even/Odd - Secondary Only
9 Even/Odd - Primary with Secondary Pops
10 Even/Odd - Primary with Secondary Random
11 Random - Primary & Secondary
12 Random - Primary Only
13 Random - Secondary Only
14 Random - Primary with Secondary Pops
15 Random - Primary with Secondary Random
16 Cycle Sequence Random - Primary & Secondary
17 Cycle Sequence Random - Primary Only
18 Cycle Sequence Random - Secondary Only
19 Cycle Sequence Random - Primary with Secondary Pops
20 Cycle Sequence Random - Primary with Secondary Random
21 All on Random - Primary & Secondary
22 Sweep Left/Right - Secondary Only
23 Off - Primary & Secondary
TABLE 1
FPM
65
Triple 70
Quad 70
Quint 70
Double 125
135
Quad 135
Quint 135
Triple Pop 75
Quad Pop 75
Single 185
Cycle N/A
TABLE 2
Multicolor
SAE Compliant CA T13 Compliant
Class 1
Class 1
Class 1
Class 1 Class B
Class 1
Class 1
Class 1
Class 1
Class 1
Class 1
Class 1
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
