E s p r i t DC S m a r t S e r i e s In s t a l l a t i o n G u i d e
Thanks for choosing our Esprit DC Smart Series ceiling fan.
We strongly recommend that you read this manual carefully before installation.
Models Parameters (Fan Only):
MDCE135 M
Esprit DC 1320mm 5 ABS Blade WIFI & Remote Control Ceiling Fan Only Matt Black
MDCE135 W
Esprit DC 1320mm 5 ABS Blade WIFI & Remote Control Ceiling Fan Only Matt White
Part List:
Qty 1x Motor assembly
Qty 1x Instruction manual
Qty 1x Mounting bracket
Qty 1x Remote & Receiver
Application
Flat Surface / Ceiling
How to Assemble
Fg.1
Secure the
bracket
to the ceiling using screws and provided.
Ensure screws are tightened on the bracket.
E: sales@martecltd.com.au | P: 02 8778 7500
www.martecaustralia.com.au
Slope Ceiling up to 15°
Qty 1x Bottom cover
Qty 1x Screw kit
Qty 5x Blades
Corrugated Ceiling
Fg.2
Apex Ceiling
Wire to main as illustrated.
Advertisement
Related Manuals for Martec Esprit DC Smart Series
Summary of Contents for Martec Esprit DC Smart Series
- Page 1 E s p r i t DC S m a r t S e r i e s In s t a l l a t i o n G u i d e Thanks for choosing our Esprit DC Smart Series ceiling fan.
- Page 2 WARNING Installation MUST carry out by a qualified and licensed electrician. How to Install Blades Fg.3 Install the blades to the bottom of the motor. Tighten and secure blade with screw and washer provided. Repeat this procedure until all blades are installed.
- Page 3 WARNING Installation MUST carry out by a qualified and licensed electrician. How to Install Fg.6 After wiring is completed, attach the canopy to the hanger bracket by pushing upwards and twisting anti-clockwise. Tighten screws and ensure canopy is not touching the ball joint. How to Install Boteom cap Fg.7 Install the shade cover as illustrated.
- Page 4 Fan Only Model 220-240V/AC 50/60Hz SUPPLY 220-240V/AC 50/60Hz SUPPLY ACL ACN ACL ACN TO AC POWER TO AC POWER To The Fan Motor To The Fan Light To The Fan Motor...
