Select among mode 2, 1 or ECO by sequentially pressing
the blade speed mode button.
NOTE:
The default blade speed mode is 1.
Blade Speed
M-1 M-2
Indicator
STARTING/STOPPING THE MOWER
The product may be used in rain.
WARNING:
The operation of any lawn mower
can result in foreign objects being thrown into your or
others' eyes, which can damage eyes severely. A lways
wear safety glasses while operating the mower or while
performing any adjustments or repairs on the mower.
NOTICE:
The blade will continue to rotate for a few
seconds after the mower is turned off. Allow the motor/
blade to stop rotating before starting it again. Do not
rapidly turn the mower off and on.
WARNING:
Stop the blade if the lawnmower has to
be tilted for transportation when crossing surfaces other
than grass and when transporting the lawnmower to and
from the area to be mowed.
WARNING:
Do not tilt the lawn mower when starting
switching on the motor, except if the lawn mower has to
be tilted for starting. In this case, do not tilt it more than
absolutely necessary and lift only the part which is away
from the operator.
Before using, always visually inspect to see that the blade
and blade bolt are not worn or damaged. Replace worn or
damaged blade and bolt in sets to preserve balance.
Check for blockage of the cutting blade
◾
To prevent blockage, keep the cutting blade and
mower deck clean. Remove grass clippings, leaves,
dirt and any other accumulated debris before and after
each use.
◾
When blockage happens, stop the mower and remove
the battery pack, then remove any build-up of grass
and leaves on or around the drive shaft and motor fan.
Wipe the mower clean with a damp cloth.
CAUTION:
Do not attempt to override the operation of the
power button and blade rotation trigger.
NOTE:
The motor cannot be started unless the handle is
locked at one of the three operating positions.
To start the mower (Fig. N1 & N2)
1. Attach the battery pack to the mower and close the
battery compartment cover.
2. Press the power button to illuminate the dashboard,
Blade Speed
and the mower status indicator – the blade speed
Mode Button
indicator for mode 1 will light up.
3. Press the blade speed mode button to select the
desired speed.
4. Press and hold the power button.
5. With the power button pressed, pull the blade
rotation trigger to meet the handle and release the
power button.
To stop the mower (Fig. N3)
1. Fully release the blade rotation trigger.
2. The electric brake in the Automatic Braking
Mechanism will stop the blade rotation within
3 seconds of the blade rotation trigger release.
VARIABLE-SPEED SELF-PROPEL SYSTEM (Fig. P)
The mower is equipped with variable-speed, self-propel
capability. This self-propel system is independent from the
blade rotation.
To operate the self-propel system without blade
rotation
1. Press the power button to illuminate the dashboard.
2. Slightly rotate the self-propel speed dial forward
until a click can be heard, then press the self-propel
trigger(s). There are two self-propel triggers, press
either of them to start the self-propel function.
To turn the self-propel off, release the self-propel
trigger.
P-1
LED HEADLIGHTS (Fig. Q)
To turn on the headlights, press the LED headlights
button. The headlights provide bright light in front of the
mower.
To turn off the headlights, press the button again.
56 VOLT LITHIUM-ION CORDLESS MOWER — LM2230E-SP
Self-propel Speed Self-propel
P-2
Dial Trigger
