EN
SIDE DISCHARGING
To attach/remove the side-discharge chute
(sold separately)
NOTICE:
Make sure that the underside of the deck is
clean before using the side-discharge chute.
◾
Remove the grass bag and set the clip selector knob in
the "BAG" position.
◾
Install the side-discharge chute into the mower as
shown in Fig. F.
FULL BAGGING
To attach/remove the grass bag
WARNING:
Under normal usage, the grass bag
material is subject to wear. To reduce the risk of injury,
frequently inspect the grass bag and replace the bag if
there are any signs of wear or deterioration. Use only
grass bags manufactured for this mower.
NOTICE:
Make sure that the underside of the deck is
clean before using the grass bag.
◾
Remove the side-discharge chute and set the clip
selector knob in the "BAG" position.
◾
Install the grass bag into the mower as shown in
Fig. G.
FULL MULCHING (Fig. H)
◾
Remove the grass bag.
◾
Release the rear-discharge door.
◾
Set the clip selector knob in the "MULCH" position.
BAGGING/MULCHING HYBRID (Fig. J)
◾
Attach the grass bag.
◾
Set the clip selector knob in one of the three bagging/
mulching hybrid positions.
NOTE:
As the clip selector knob is moved towards the
"MULCH" position, more grass will be recycled back into
the lawn.
As the clip selector knob is moved toward the "BAG"
position, more grass will be discharged though the rear
discharge into the grass bag.
CUTTING-HEIGHT ADJUSTMENT (Fig. K)
Keep your feet away from the deck when adjusting the
cutting height.
The mower can be set to 8 cutting heights between
25 mm and 105 mm. A marking indicates the selected
cutting height.
12
56 VOLT LITHIUM-ION CORDLESS MOWER — LM2230E-SP
Choose the proper cutting height according to the type
and condition of the grass to be cut.
1. Switch off the mower and wait for the cutting blade
to come to a complete stop.
2. Remove the battery pack.
3. Pull the cutting height adjustment lever out of the
detent and set it to the desired position.
NOTE:
To avoid overloading the motor, avoid setting the
cutting height too low in tall grass. If the motor speed
begins to slow, raise the cutting height.
OPERATION
Always remove the battery pack from the product when
you are assembling parts, making adjustments, cleaning,
or when not in use. Removing the battery pack will
prevent accidental starting that could cause serious
personal injury.
ATTACHING/DETACHING THE BATTERY PACK (Fig. L)
Use only with EGO's battery packs and chargers listed in
Fig. A3.
Refer to corresponding battery packs and chargers
manuals for more details.
Fully charge before first use
1. Raise the battery compartment cover by lifting the
front of the cover.
2. To attach, Align the battery ribs with the mounting
slots and press the battery pack down until you hear
a "click".
To detach, depress the battery-release button and
3.
pull the battery pack out.
4. Close the battery compartment cover.
NOTICE:
Make sure that the latch on the mower snaps
into place and that the battery pack is secured to the
mower before starting operation.
SELECTING BLADE SPEED MODE (Fig. M)
◾
Mode 2 is high blade speed mode for high-lift
performance to improve suction force or cutting
performance.
◾
Mode 1 is the best balance between performance and
runtime.
◾
Mode ECO provides the lowest noise level and longest
runtime from your battery pack.
NOTE:
The blade speed cannot be adjusted during
operation. The change will take effect only after the motor
is stopped and started again.
