Axeon HYDRO RO Series Quick Start Manual

QUICK START GUIDE
MEMBRANE INSTALLATION
1
Remove 2 Philips screws from
the bottom of the unit.
4
Disconnect tubing connected to
membrane housing cap. Remove
the caps using the included wrench,
turning counterclockwise.
7
Reinstall both membrane housing
caps and reconnect tubing.
FILTER INSTALLATION
9
Match the filter label color to head
label color and align the filter key.
2
Slowly lift the cover up vertically.
5
Lubricate each membrane's O-ring
with food-grade silicone before
inserting them into the housing.
8
Center the membrane housings
and wiring. Then reinstall cover
and 2 Philips screws.
10
1
2
Slide the filter up into the head
vertically and then rotate the filter
to the right. Repeat for all 3 filters.
3
Be careful not to pull the wires attached
to the cover. Rotate the cover and place
it in front of the system.
6
Make sure each membrane is
fully seated in the housing.
MOUNTING THE SYSTEM
11
Mount RO System with a minimum
6 inches of clearance between the
ground and bottom of the filter. Use
mounting guide on page 23 of
manual for hole alignment.
