- Page 1 HEADER – SECTION TITLE HERE LP–Series LP-700 PICTURED WITH OPTIONAL FRONT PANEL AND 10” FILTER HOUSINGS LP-700 PICTURED WITH OPTIONAL FRONT PANEL REVERSE OSMOSIS SYSTEM USER MANUAL MKT – ??? – ? Page 1 of 35...
- Page 2 HEADER – SECTION 2 TITLE HERE This page is Intentionally left blank MKT–555–B Page 2 of 35...
-
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ............................................5 SAFETY AND PRECAUTIONS ........................................6 PRECAUTIONARY STATEMENTS ......................................6 OPERATING DO’S AND DON’TS ......................................8 FEED WATER AND OPERATION SPECIFICATION ................................9 OPERATING LIMITS ..........................................9 SYSTEM SPECIFICATION CHART ......................................10 COMPONENT IDENTIFICATION ......................................11 LP–350 SYSTEM ........................................... - Page 4 TABLE OF CONTENTS SYSTEM WARRANTY..........................................35 MKT–555–B Page 4 of 35...
-
Page 5: Introduction
INTRODUCTION Your LP–Series Reverse Osmosis System is a durable piece of equipment which, with proper care, will last for many years. This User Manual outlines installation, operation, maintenance and troubleshooting details vital to the sustained performance of your system. If your system is altered at the site of operation, or if the feedwater conditions change, please contact your local dealer or distributor to determine the proper recovery for your application. -
Page 6: Safety And Precautions
SAFETY AND PRECAUTIONS The Safety section of this User Manual outlines the various safety headings used throughout this manual’s text and are enhanced and defined below: CAUTION: INDICATES STATEMENTS THAT ARE USED TO IDENTIFY CONDITIONS OR PRACTICES THAT COULD RESULT IN EQUIPMENT OR OTHER PROPERTY DAMAGE. WARNING: INDICATES STATEMENTS THAT ARE USED TO IDENTIFY CONDITIONS OR PRACTICES THAT COULD RESULT IN INJURY OR LOSS OF LIFE. - Page 7 SAFETY AND PRECAUTIONS DO NOT SHUT DOWN THE SYSTEM FOR EXTENDED PERIODS. IT IS BEST TO RUN THE SYSTEM AS MUCH AS POSSIBLE ON A CONTINUOUS BASIS. ELECTRICAL INSTALLATION SHOULD BE DONE BY QUALIFIED, TRAINED ELECTRICIANS. INSTALLATION SHOULD BE TO LOCAL CODES. MKT–555–B Page 7 of 35...
-
Page 8: Operating Do's And Don'ts
OPERATING DO’S AND DON’TS • Change the cartridge filters regularly. • Monitor the system and keep a daily log. • Run the system as much as possible on a continuous basis. • Adjust the system recovery to the recommended value. •... -
Page 9: Feed Water And Operation Specification
FEED WATER AND OPERATION SPECIFICATIONS Nothing has a greater effect on a reverse osmosis system than the feed water quality. If your system is altered at the site of operation or if the feed water conditions change, please contact your local dealer or distributor to determine the proper recovery for your application. -
Page 10: System Specification Chart
SYSTEM SPECIFICATION CHART MODELS LP–350 LP–500 LP–700 DESIGN Configuration Single Pass Single Pass Single Pass Feedwater Source (ppm) TDS < 500 TDS < 500 TDS < 500 Standard Recovery Rate% FLOW RATES Permeate Flow (gpm / lpm) 0.24 / 0.91 0.35 / 1.31 0.49 / 1.85 Minimum Feed Flow (gpm / lpm) -
Page 11: Component Identification
COMPONENT IDENTIFICATION LP–350 SYSTEM MKT–555–B Page 11 of 35... -
Page 12: Lp-500 System
COMPONENT IDENTIFICATION LP–500 SYSTEM MKT–555–B Page 12 of 35... -
Page 13: Lp-700 System
COMPONENT IDENTIFICATION LP–700 SYSTEM MKT–555–B Page 13 of 35... -
Page 14: Lp-700 With Optional 10" Filter Housings
OPTION, RO, LP-700, HOUSING, FILTER, 10" LP 350 – 700 200658 CARTRIDGE, BLOCK, CARBON, 2.5" X 10", 10 MIC, CBF-25-1010, AXEON LP 350 – 700 200621 CARTRIDGE, DEPTH FILTER, POLYPROPYLENE, 2.5" X 10", 5 MIC, SDF-25-1005, AXEON MKT–555–B Page 14 of 35... -
Page 15: Component Identification Description
COMPONENT IDENTIFICATION DESCRIPTION PRE–FILTRATION LP–Series systems are supplied with a 5–micron sediment filter and a 10 micron carbon block filter. Change the cartridge once a month or when a 10–15 psi differential exists between the two pre–filter gauges. FILTER HOUSINGS The LP–Series comes with two housings one for the 5 micron sediment filter and the second one is for the 10 micron carbon filter. - Page 16 COMPONENT IDENTIFICATION DESCRIPTION PRE–FILTER PRESSURE GAUGES (OPTIONAL) These gauges measure the feed water pressure when it enters and exits the pre-filter. A pressure differential of 10– 15 psi or more between the two pressure gauges indicates EXAMPLE: If the inlet pressure is 60 psi, that the pre-filters require replacement.
-
Page 17: Membrane Information
The claims made may not have been approved for use in all countries. The manufacturer assumes no obligation or liability for the information in this document. AXEON reserves the right to update this information periodically for the purposes of quality and accuracy. -
Page 18: Membrane Performance
MEMBRANE PERFORMANCE LP–Series Reverse Osmosis Systems are designed to produce up to 700 GPD at 77°F (nominal) of permeate water per membrane at 98% rejection under the proper conditions. For example, the LP–700 produces 700 gallons per day of permeate water at the listed operating test conditions. REJECTION The amount of total dissolved solids (TDS) rejected by the membrane is expressed as a percentage. -
Page 19: System Installation
SYSTEM INSTALLATION MOUNTING The free standing system should be bolted down or securely fastened in compliance with local regulation standards. The system comes standard with a rubber bumper kit. Casters and levelers are available, but optional. PLUMBING The membranes and high pressure pumps used on LP–500 systems require a continuous flow of water with a minimum feed pressure of 45 psi. -
Page 20: Holding Tank Connection
SYSTEM INSTALLATION FEED CONCENTRATE *SYSTEM SHOWN WITH OPTIONAL PANEL. DO NOT OPERATE AT A PRESSURE EXCEEDING 100 PSI. Note: The LP–500 system has been designed with an auto–flush restrictor. This restrictor automatically flushes the reverse osmosis system for 30 seconds every time it starts up and 15 seconds once every hour when the system is producing water. -
Page 21: Permeate Connection
SYSTEM INSTALLATION PERMEATE CONNECTION Connect 3/8” tubing from the 3/8” QC bulkhead labeled “PERMEATE” to the final point–of–use (i.e. faucet). Ensure that the permeate water can flow freely with no backpressure. Backpressure can cause irreversible damage to the membrane elements. HOLDING TANK PERMEATE *SYSTEM SHOWN WITH OPTIONAL PANEL. -
Page 22: Membrane Installation
MEMBRANE INSTALLATION Installation and replacing membranes in the pressure vessels is an easy process if you have the proper information and tools at hand. Please refer to the following instructions when removing and replacing membrane elements: ALL PRESSURE GAUGES MUST READ ZERO BEFORE PROCEEDING. BEFORE ATTEMPTING, DISCONNECT THE POWER FROM THE SYSTEM AND BLEED ALL WATER PRESSURE FROM THE SYSTEM. - Page 23 MEMBRANE INSTALLATION LP-350 LP-500 LP-700 MKT–555–B Page 23 of 35...
-
Page 24: System Purging / Initial Start Up
SYSTEM PURGING / INITIAL START UP REPLACING THE MEMBRANE ELEMENT: THE BRINE SEAL MUST BE IN THE CORRECT POSITION FOR EACH PRESSURE VESSEL. THE BRINE SEAL IS A RUBBER SEAL THAT PROTRUDES ON ONE SIDE OF THE MEMBRANE. FOR LP–SERIES REVERSE OSMOSIS SYSTEMS THE BRINE SEAL SHOULD BE ON THE SAME SIDE AS THE PRESSURE VESSEL END CAP. -
Page 25: Lp-500 System
SYSTEM PURGING / INITIAL START UP 3. After 30 minutes, shut down the system and re-direct the permeate line back to final use location (i.e. faucet). 4. Your start up is now complete. Make sure that the system pressures and flows are matching up with that of your specific system model, located on the System Specification (Page 10) of this manual. -
Page 26: Temperature Factor For Membranes
TEMPERATURE FACTOR FOR MEMBRANES A membrane’s stated permeate production rate is based on a water temperature of 77°F degrees Fahrenheit. Temperatures above or below 77°F will increase or decrease the membrane’s production rate. Find the temperature correction factor (TCF) for your water temperature on the table located on the next page. -
Page 27: Temperature Correction Factors
TEMPERATURE CORRECTION FACTORS TEMPERATURE CORRECTION TABLE Temperature Temperature Temperature Temperature Temperature °F (°C) °F (°C) °F (°C) °F (°C) °F (°C) 50.0 (10.0) 1.711 57.2 (14.0) 1.475 64.4 (18.0) 1.276 71.6 (22.0) 1.109 78.8 (26.0) 0.971 50.2 (10.1) 1.705 57.4 (14.1) 1.469 64.6 (18.1) 1.272... - Page 28 OPERATING LOG MKT–555–B Page 28 of 35...
-
Page 29: Troubleshooting
TROUBLESHOOTING SYMPTOMS POSSIBLE CAUSES CORRECTIVE ACTION Low supply pressure Increase inlet pressure Cartridge filters plugged Change filters Low Inlet Pressure Solenoid valve malfunction Replace solenoid valve (LP–500) Leaks Fix any visible leaks Low inlet flow Inspect flow restrictor, clean or replace if necessary Cold feedwater See temperature correction sheet Low Permeate Flow... -
Page 30: Flow Diagram
FLOW DIAGRAM LP–350 SYSTEM MKT–555–B Page 30 of 35... -
Page 31: Lp-500 System
FLOW DIAGRAM LP–500 SYSTEM MKT–555–B Page 31 of 35... -
Page 32: Lp-700 System
FLOW DIAGRAM LP–700 SYSTEM MKT–555–B Page 32 of 35... -
Page 33: Wiring Diagram
WIRING DIAGRAM LP–500 SYSTEM WIRING DIAGRAM MKT–555–B Page 33 of 35... - Page 34 SYSTEM WARRANTY Warranty Terms Subject to the terms and conditions set forth hereinafter, the manufacturer (hereafter “Manufacturer”) warrants to the original purchaser (hereafter the “Customer”) that the systems and products manufactured by the Manufacturer are free from defects in material and in workmanship for twelve (12) months from the Warranty Commencement Date (as defined below) only when used strictly in accordance with the applicable operating instructions and within the range of the operating conditions specified by the Manufacturer for each such product.
- Page 35 SYSTEM WARRANTY been used, or, the product has not been installed, operated and maintained in strict accordance and adherence with the operating documentation and manuals for such product. Any expressed Warranty, or similar representation of performance set forth in the operation documentation for media or resin incorporated into the Manufacturer product shall be void and unenforceable unless the feed water requirements set forth in the operating documentation for such product are unequivocally and strictly adhered to.
