Axeon HYDRO RO Series Quick Start Manual

QUICK START GUIDE
MEMBRANE INSTALLATION
1
Remove 2 Philips screws from
the bottom of the unit.
4
Disconnect tubing connected to
membrane housing cap. Remove
the caps using the included wrench,
turning counterclockwise.
7
Reinstall both membrane housing
caps and reconnect tubing.
FILTER INSTALLATION
9
Match the filter label color to head
label color and align the filter key.
2
Slowly lift the cover up vertically.
5
Lubricate each membrane's O-ring
with food grade silicone before
inserting them into the housing.
8
Center the membrane housings
and wiring. Then reinstall cover
and 2 Philips screws.
10
1
2
Slide the filter up into the head
vertically and then rotate the filter
to the right. Repeat for all 3 filters.
3
Be careful not to pull the wires attached
to the cover. Rotate the cover and place
it in front of the system.
6
Make sure each membrane is
fully seated in the housing.
MOUNTING THE SYSTEM
11
Mount RO SYSTEM with a minimum 6
inches of clearance between the ground
and bottom of the filter. Use mounting guide
on page 25 of manual for hole alignment.
Mount pump to wall using mounting
guideline on page 26 (optional).
